Specifications
Brand Name :
NuFiber
Model Number :
CWDM-SFP-FE-LX120-1270
Certification :
CE FCC Rohs
Place of Origin :
China
MOQ :
1 piece
Payment Terms :
L/C, T/T, Western Union,Credit Card
Supply Ability :
100,000 pcs per month
Delivery Time :
Within 1-3 work days
Packaging Details :
10pcs/plastic bag, 500pcs/carton
Product Name :
155Mbps SFP Transceiver
Wavelength :
1270~1610nm
Distance :
120KM
Connector :
LC
Packaging :
CWDM SFP
Fiber Type :
Duplex LC SM
Power Supply :
3.3V
Working Temperature :
0-70℃
Manufacturer :
Yes
Compatible :
Cisco Huawei HP Juniper etc...
Warranty :
1 year
Description

155Mb/s 120km CWDM SFP Transceiver Duplex LC 1270nm ~ 1610nm SM DDM

Description

NuFiber’s CWDM-SFP-FE-LX120-XX Transceiver is a high performance, cost effective module which have a duplex LC optics interface. Standard AC coupled CML for high speed signal and LVTTL control and monitor signals. The receiver section uses a PIN receiver and the transmitter uses a 1270nm ~ 1610nm CWDM DFB laser, up to 29dB link budge ensure this module SONET OC-3/SDH STM-1 120km application.

Features

  • Up to 155Mb/s Data Links
  • Hot-Pluggable
  • Duplex LC connector
  • Up to 120km on 9/125μm SMF
  • 1270nm～1610nm CWDM DFB laser transmitter
  • Single +3.3V Power Supply
  • Monitoring Interface Compliant with SFF-8472
  • Maximum Power <1W
  • Industrial /Extended/ Commercial operating temperature range: -40°C to 85°C/-5°C to 85°C/-0°C to 70°C Version available
  • RoHS compliant and Lead Free

Applications

  • SONET OC-3/SDH STM-1
  • Fast Ethernet
  • Other Optical Links

Optical Parameters(TOP = -40 to 85°C, VCC = 3.135 to 3.465 Volts)

Parameter Symbol Min. Typical Max. Unit Note
Transmitter Section:
Center Wavelength λc λ-6 λ λ+7.5 nm
Spectral Width σ 1 nm
Optical Output Power Pout 0 5 dBm 1
Optical Rise/Fall Time tr / tf 500 ps 2
Extinction Ratio ER 10 dB
Generated Jitter (peak to peak) JTXp-p 0.07 UI 3
Generated Jitter (rms) JTXrms 0.07 UI 3
Eye Mask for Optical Output Compliant with G.957(class 1 laser safety)
Receiver Section:
Optical Input Wavelength λc 1260 1620 nm
Receiver Overload Pol -8 dBm 4
RX Sensitivity Sen -34 dBm 4
RX_LOS Assert LOS A -47 dBm
RX_LOS De-assert LOS D -37 dBm
RX_LOS Hysteresis LOS H 0.5 dB
General Specifications:
Data Rate BR 155 Mb/s
Bit Error Rate BER 10-12
Max. Supported Link Length on 9/125μm SMF@155Mb/s LMAX 80 km
Total System Budget LB 29 dB

Ordering Information

Dual Fiber SFP Transceiver
Part Number Product Description
155Mbp/s SFP Transceiver
FE-SX-MM850 155Mbps, 850nm MM 2km Dual LC, DDM 0°C~+70°C
FE-SX-MM1310 155Mbps, 1310nm MM 2km Dual LC, DDM 0°C~+70°C
FE-LX20-SM1310 155Mbps, 1310nm SM 20km Dual LC, DDM 0°C~+70°C
FE-LX40-SM1310 155Mbps, 1310nm SM 40km Dual LC, DDM 0°C~+70°C
FE-LX80-SM1550 155Mbps, 1550nm SM 80km Dual LC, DDM 0°C~+70°C
FE-LX120-SM1550 155Mbps, 1550nm SM 120km Dual LC, DDM 0°C~+70°C
1.25Gbps SFP Transceiver
GE-SX-MM850 1.25Gbps, 850nm MM 500m Dual LC, DDM 0°C~+70°C
GE-SX-MM1310 1.25gbps, 1310nm MM 2km Dual LC, DDM 0°C~+70°C
GE-LX20-SM1310 1.25Gbps, 1310nm SM 20km Dual LC, DDM 0°C~+70°C
GE-LX40-SM1310 1.25Gbps, 1310nm SM 40km Dual LC, DDM 0°C~+70°C
GE-LX60-SM1550 1.25Gbps, 1550nm SM 60km Dual LC, DDM 0°C~+70°C
GE-LX80-SM1550 1.25Gbps, 1550nm SM 80km Dual LC, DDM 0°C~+70°C
GE-LX120-SM1550 1.25Gbps, 1550nm SM 120km Dual LC, DDM 0°C~+70°C
10Gbps SFP Transceiver
SFP+-10GB-SR 10G SFP+ SR Multi mode dual fiber LC 850nm 300M
SFP+-10GB-LRM 10G SFP+ LRM Multi mode dual fiber LC 1310nm 220M
SFP+-10GB-LR 10G SFP+ LR Single mode dual fiber LC 1310nm 20km
SFP+-10GB-ERM 10G SFP+ER Single mode dual fiber LC 1310nm 40km
SFP+-10GB-ER 10G SFP+ER Single mode dual fiber LC 1550nm 40km
SFP+-10GB-ZR 10G SFP+ZR Single mode dual fiber LC 1550nm 80km
SFP+10G40-CWDM 1470 ~1610nm CWDM SFP+ 40km
SFP+10G80-CWDM 1470~1570nm CWDM SFP+ 80km
SFP+10G80-CWDM 1590~1610nm CWDM SFP+ 80km
SFP+10G40-DWDM DWDM SFP+ 40km
SFP+10G80-DWDM DWDM SFP+ 80km
XFP Transceiver
XFP-10G-SR 10G XFP SR Multi mode dual fiber LC 850nm 300M
XFP-10G-LRM 10G XFP LRM Single mode dual fiber LC 1310nm 10kM
XFP-10G-LR 10G XFP LR Single mode dual fiber LC 1310nm 20km
XFP-10G-ER 10G XFP ER Single mode dual fiber LC 1550nm 40km
XFP-10G-ZR 10G XFP ZR Single mode dual fiber LC 1550nm 80km
CWDM DWDM Transceiver
XFP-CWDM-40xx 1470 ~1610nm CWDM XFP 40km
XFP-CWDM-80xx 1470~1570nm CWDM XFP 80km
XFP-CWDM-80xx 1590~1610nm CWDM XFP 80km
XFP-DWDM-40xx DWDM XFP 40km
XFP-DWDM-80xx DWDM XFP 80km
XFP-DWDM-100xx DWDM XFP100km

Products Show

155Mb/S 120km CWDM SFP Transceivers Duplex LC 1270nm 1610nm SM DDM155Mb/S 120km CWDM SFP Transceivers Duplex LC 1270nm 1610nm SM DDM155Mb/S 120km CWDM SFP Transceivers Duplex LC 1270nm 1610nm SM DDM155Mb/S 120km CWDM SFP Transceivers Duplex LC 1270nm 1610nm SM DDM155Mb/S 120km CWDM SFP Transceivers Duplex LC 1270nm 1610nm SM DDM155Mb/S 120km CWDM SFP Transceivers Duplex LC 1270nm 1610nm SM DDM
