Specifications
Brand Name :
NuFiber
Model Number :
XFP-10G-BX40-SM1270
Certification :
CE FCC Rohs
Place of Origin :
China
MOQ :
1 pair
Payment Terms :
L/C, T/T, Western Union,Credit Card
Supply Ability :
10,000 pcs per month
Delivery Time :
Within 1-3 work days
Packaging Details :
10pcs/plastic bag, 500pcs/carton
Data Rate :
10Gb/s
Wavelength :
1270/1330nm
Distance :
40km
Connector :
LC
DDM :
Support
Fiber Type :
single fiber SM
Power Supply :
3.3V
Working Temperature :
0~70℃
Warranty :
1 year
Compatibility :
Cisco, HP, Huawei, Finisar...
Manufacturer :
Yes
Description

10Gb/s XFP Transceiver XFP-10G-BX40-SM1270 singlefiber SM 40km LC DDM

Description

NuFiber’ XFP-BX40-SM1330/1270 Bi-directional 10Gb/s (XFP) transceivers are compliant with the current XFP Multi-Source Agreement (MSA) Specification. They comply with 10-Gigabit Ethernet 10GBASE-LR/LW per IEEE 802.3ae,SONET OC-192 /SDH and 10G Fibre Channel 1200-SM-LL-L. Digital diagnostics functions are available via a 2-wire serial interface, as specified in the XFP MSA.

Features

  • Supports 9.95Gb/s to 11.3Gb/s bit rates
  • Hot-pluggable XFP footprint
  • Single LC for Bi-directional Transmission
  • Maximum link length of 40km
  • Built-in 1270/1330 WDM
  • Uncooled 1270nm or 1330nm CWDM DFB Laser
  • Power dissipation <2W
  • No Reference Clock required
  • Built-in digital diagnostic functions
  • Temperature range 0°C to 70°C
  • Very low EMI and excellent ESD protection
  • RoHS Compliant Part

Applications

  • 10GBASE-LR/LW Ethernet
  • SONET OC-192 /SDH
  • 1200-SM-LL-L 10G Fibre Channel

Optical Parameters

Parameter Symbol Min Typ Max Unit Ref.
Transmitter
Operating Date Rate BR 9.95 11.3 Gb/s
Bit Error Rate BER 10-12
Maximum Launch Power PMAX -1 +3 dBm 1
Optical Center Wavelength XFP-BX40-SM1270 λ 1260 1270 1280 nm
XFP-BX40-SM1330 1320 1330 1340
Optical Extinction Ratio ER 3.5 dB
Spectral Width Δλ 1 nm
Sidemode Supression ratio SSRmin 30 dB
Rise/Fall Time (20%~80%) Tr/Tf 50 ps
Average Launch power of OFF Transmitter POFF -30 dBm
Tx Jitter Txj Compliant with each standard requirements
Optical Eye Mask IEEE802.3ae 2
Receiver
Operating Date Rate BR 9.95 11.3 Gb/s
Receiver Sensitivity Sen -16 dBm 2
Maximum Input Power PMAX 0 dBm 2
Optical Center Wavelength XFP-BX40-SM1270 λC 1320 1330 1340 nm
XFP-BX40-SM1330 1260 1270 1280
Receiver Reflectance Rrx -27 dB
LOS De-Assert LOSD -17 dBm
LOS Assert LOSA -27 dBm
LOS Hysteresis LOSH 0.5 5 dB

Ordering information

Dual Fiber SFP Transceiver
Part Number Product Description
155Mbp/s SFP Transceiver
FE-SX-MM850 155Mbps, 850nm MM 2km Dual LC, DDM 0°C~+70°C
FE-SX-MM1310 155Mbps, 1310nm MM 2km Dual LC, DDM 0°C~+70°C
FE-LX20-SM1310 155Mbps, 1310nm SM 20km Dual LC, DDM 0°C~+70°C
FE-LX40-SM1310 155Mbps, 1310nm SM 40km Dual LC, DDM 0°C~+70°C
FE-LX80-SM1550 155Mbps, 1550nm SM 80km Dual LC, DDM 0°C~+70°C
FE-LX120-SM1550 155Mbps, 1550nm SM 120km Dual LC, DDM 0°C~+70°C
1.25Gbps SFP Transceiver
GE-SX-MM850 1.25Gbps, 850nm MM 500m Dual LC, DDM 0°C~+70°C
GE-SX-MM1310 1.25gbps, 1310nm MM 2km Dual LC, DDM 0°C~+70°C
GE-LX20-SM1310 1.25Gbps, 1310nm SM 20km Dual LC, DDM 0°C~+70°C
GE-LX40-SM1310 1.25Gbps, 1310nm SM 40km Dual LC, DDM 0°C~+70°C
GE-LX60-SM1550 1.25Gbps, 1550nm SM 60km Dual LC, DDM 0°C~+70°C
GE-LX80-SM1550 1.25Gbps, 1550nm SM 80km Dual LC, DDM 0°C~+70°C
GE-LX120-SM1550 1.25Gbps, 1550nm SM 120km Dual LC, DDM 0°C~+70°C
10Gbps SFP Transceiver
SFP+-10GB-SR 10G SFP+ SR Multi mode dual fiber LC 850nm 300M
SFP+-10GB-LRM 10G SFP+ LRM Multi mode dual fiber LC 1310nm 220M
SFP+-10GB-LR 10G SFP+ LR Single mode dual fiber LC 1310nm 20km
SFP+-10GB-ERM 10G SFP+ER Single mode dual fiber LC 1310nm 40km
SFP+-10GB-ER 10G SFP+ER Single mode dual fiber LC 1550nm 40km
SFP+-10GB-ZR 10G SFP+ZR Single mode dual fiber LC 1550nm 80km
XFP Transceiver
XFP-10G-SR 10G XFP SR Multi mode dual fiber LC 850nm 300M
XFP-10G-LRM 10G XFP LRM Single mode dual fiber LC 1310nm 10kM
XFP-10G-LR 10G XFP LR Single mode dual fiber LC 1310nm 20km
XFP-10G-ER 10G XFP ER Single mode dual fiber LC 1550nm 40km
XFP-10G-ZR 10G XFP ZR Single mode dual fiber LC 1550nm 80km


Products Show

Single Fiber SM Xfp Fiber Transceiver 10Gb/S 40km Telecommunication EquipmentSingle Fiber SM Xfp Fiber Transceiver 10Gb/S 40km Telecommunication EquipmentSingle Fiber SM Xfp Fiber Transceiver 10Gb/S 40km Telecommunication Equipment

Single Fiber SM Xfp Fiber Transceiver 10Gb/S 40km Telecommunication Equipment

Single Fiber SM Xfp Fiber Transceiver 10Gb/S 40km Telecommunication Equipment

Packaging & Shipping

Single Fiber SM Xfp Fiber Transceiver 10Gb/S 40km Telecommunication Equipment

Single Fiber SM Xfp Fiber Transceiver 10Gb/S 40km Telecommunication Equipment

Factory Show

Single Fiber SM Xfp Fiber Transceiver 10Gb/S 40km Telecommunication Equipment
