Specifications
Brand Name :
Nufiber
Model Number :
NF-PSE5201A/B
Certification :
CE RoHS FCC
Place of Origin :
China(mainland)
MOQ :
1
Payment Terms :
T/T, Western Union
Supply Ability :
8000piece/month
Delivery Time :
3~4working day after payment
Packaging Details :
Packing Size/per boxes:21mm*15.6mm*5.3mm 40 Boxes / carton or As Your Mind
Product Name :
poe fiber media converter
Type :
SM single fiber
Color :
Black,grey
Distance :
20KM
Dimension :
21mm*15.6mm*5.3mm
Fiber Type :
1fiber port +1rj45 port
Power :
External Power Supply
OEM,DDM :
accept
Warranty :
3years
Description

10/100Mbps POE Media Converter Single Mode Single Fiber SC 20km IEEE802.3af/at

Description

NuFiber’s NF-PSE5201 series Media Converter are 10/100Base T/TX to 100Base FX Power over Ethernet(PoE) devices that serve as Power Sourcing Equipment(PSE).which allows the converter to provide power to IEEE802.3af PoE standard-compliant Powered Devices(PDs) using the twisted pair connection. Power transmitted along with data in one single cable(RJ45) allows you to expand your network where there are no power lines or outlets. Where you wish to devices such as Wifi Aps. IP Cameras or IP Phones.etc.

Features

1,Support 100Mbps half-duplex/full-duplex mode and auto MDI/MDIX;

2,With PoE supported to save power infrastructure cost;
3,,SC connector with single-mode&single-fiber,optic fiber transmission

distance up to 20KM;
4,Support IEEE 802.3u 100Base-TX,IEEE802.3 af/at standard;
5,No storage and forward technology, without delay;
6,Plug and play, no other software and transfer agreement needed;
7,Stand alone unit with mini design;

8,Built-in splicing slot, with magnet and hanger, unique and integrated design, wall-mounted, splicing and desktop installations available, which suits in all kinds of engineering installation.

Spicification

Item Description
Power Power Supply Power Adapter
Voltage Range DC 48V-57V
Consumption <35W (PoE power supply≤30W)
Ethernet Port Ethernet Port LAN port:10/100Mbps
Transmission Distance LAN port: 0-100m
PoE PoE Protocol IEEE802.3af/at
PoE Power Supply End Span
PoE Power Consumption ≤30W
Fiber Port Fiber Port 1*9,SC
Bandwidth 100Mbps
Transmission Distance 20km
Network Standard Compatible with IEEE802.3 10BASE-T, IEEE802.3u 100BASE-TX/FX
LED Status Indicator Power 1 Green light
Ethernet Green light on the RJ 45 Socket
Fiber Link, SD, FED (3 green lights)
Protection ESD Contact discharge 6KV; air discharge 8KV
Lightning Protection Power:2KV
Signal:1KV
Per:IEC61000-4-5
Environmental Working Temperature 0℃~55℃
Storage Temperature -40℃~85℃
Humidity (non-condensing) 0~95%
Mechanical Dimension (L×W×H) 103mm×82mm×25mm
Material Aluminum Alloy
Color Black
Weight 172g
Stability MTBF >30000h

Ordering Information

Model Description Fiber Mode Wavelength Distance Connector
NF-PSE5201C02 10/100Base-Tx to 100Base-FX MMF

TRx:850nm

or TRx:1310nm

 2km SC
NF-PSE5201C20 10/100Base-Tx to 100Base-FX SMF TRx:1310nm 20 km SC
NF-PSE5201C20A/B 10/100Base-Tx to 100Base-FX SMF

Tx:1310nm/Rx1550nm

Tx:1550nm/Rx1310nm

 20 km SC
NF-PSE5201-SFP 10/100Base-Tx to 100Base-FX SFP 850nm/1310nm/1550nm 0~120km LC/SC
