Black Gray 8 Port Poe Switch With 1 Gigabit Uplink OEM ODM Supported

Specifications

Brand Name :

NuFiber

Model Number :

NF-PSE5108

Certification :

CE FCC

Place of Origin :

China

MOQ :

1 piece

Payment Terms :

L/C, T/T, Western Union

Supply Ability :

5000pcs per month

Delivery Time :

1-3 work days

Packaging Details :

20pcs/carton, carton size: 452*372*297mm

Material :

Iron Case

Color :

Black, Gray

Data Transfer Rate :

10/100Mbps

POE ports :

Uplink port :

Standard :

IEEE802.3af

Total power :

65Watts

Power Supply :

48VDC

OEM & ODM :

Accepted

Description

10/100M 8 ports POE with 1 Uplink UTP port POE Switch IEEE802.3af 15.4watts

Name: Black Gray 8 Port Poe Switch With 1 Gigabit Uplink OEM ODM Supported
Brand: NuFiber
Price: 1 USD

Description

NF-PSE5108, 8+1 Port 100Mbps PoE Switch, reduces equipment and installation costs by delivering data and power over existing Ethernet cables. This unmanaged switch offers four 100M PoE ports which supply 15.4 watts of power per port for devices such as high power wireless access points, and VoIP telephony systems.

This rack mountable switch features an internal power supply. Auto sensing technology delivers 15.4 watts to 802.3af PoE devices. It reduces energy consumption by up to 75% when the switch is not in use. Boost office efficiency and reduce network congestion with a total switching capacity of 1 Gbps. LED indicators display device status for efficient troubleshooting. This switch comes in a sturdy metal case.

Features
♦ IEEE 802.3af Power over Ethernet PoE compliant

♦ Supports 10/100Mbps fast Ethernet

♦ 8 x 100M bit Auto-MDIX PoE ports

♦ Internal power supply

♦ Provides up to 15.4 watts for PoE

♦ Automatically detects the PoE class level of a Powered Device

♦ 1Gbps bandwidth

♦ Forwarding rate: 100 Mbps / 148,800 pps; 10 Mbps / 14,880 pps

♦ Status LEDs: System Power, PoE, 100 Mbps, and Link / Activity

♦ Full wire-speed non-blocking reception and transmission

♦ Store-and-forward switching method

♦ Back pressure Flow Control for Half-Duplex mode

♦ IEEE 802.3x Flow Control for Full-Duplex mode

♦ Power saving technology powers down unused ports and when a connected device is in standby mode

♦ Plug and Play

♦ Sturdy rack mountable metal case

♦ Easy installation and use , no need to convert by software and network protocol

Specifications

Technology
Network Standards	IEEE 802.3 Ethernet IEEE 802.3u Fast Ethernet IEEE 802.3x Flow Control IEEE 802.3af Power over Ethernet IEEE 802.3at High Power over Ethernet
PoE power	25.5W per port(IEEE802.3at) Wiring:Data & power provided over pairs1/2and 3/6 or 4/5(+)and 7/8(-) Cable:UPT cat.5 or higher
Processing types	Store-and-forward Half-duplex back pressure and IEEE802.3x full- duplex flow control
Performance	Backplane Bandwidth:16 Gbps Network latency:Less than 2ms Address Database Size:1000MAC/System
Power
Input		48VDC input
PoE power consumption		25.5W

Mechanical
Casing	Metal case
Dimension	44022045mm (L x W x H)
Weight	2.76KG
Installation	Rack Mount
Interface
LED Indicators	System: Power, PoE Maximum power Per port: Link, Activity,Speed PoE active, PoE error
Environment Specification
Operating temperature		0-55℃
Storage temperature		-10-70℃
Operating humidity		90% max relative humidity,non-condensing
Storage humidity		90% max relative humidity,non-condensing

Connection Diagram
