QSFP 40G SR 150M Optical Transceiver Module For Metro Network
QSFP 40G SR 150M Optical Transceiver Module For Metro Network
QSFP 40G SR 150M Optical Transceiver Module For Metro Network
QSFP 40G SR 150M Optical Transceiver Module For Metro Network
QSFP 40G SR 150M Optical Transceiver Module For Metro Network
QSFP 40G SR 150M Optical Transceiver Module For Metro Network
QSFP 40G SR 150M Optical Transceiver Module For Metro Network
QSFP 40G SR 150M Optical Transceiver Module For Metro Network
QSFP 40G SR 150M Optical Transceiver Module For Metro Network
QSFP 40G SR 150M Optical Transceiver Module For Metro Network
Specifications
Brand Name :
Nufiber
Model Number :
QSFP-40G-SR4
Certification :
CE FCC
Place of Origin :
China
MOQ :
1 piece
Payment Terms :
T/T, Western Union
Supply Ability :
1000 Piece/Week
Delivery Time :
2-3 days
Packaging Details :
10pcs/plastic bag, 200pcs/carton
Data Rate :
40Gb/s
Wavelength :
850nm
Distance :
150m
Connector :
MPO
Fiber Type :
MMF
Power Supply :
3.3V
Operating Temperature :
0~70℃
Warranty :
12 months
Manufacturer :
yes
OEM :
Support
Description

Chinese Manufacture Optical Transceiver Module Qsfp 40g Sr 150m

QSFP-40G-SR QSFP+ 40G 850NM 150M MPO TRANSCEIVER Compatible Cisco Huawei HPE Aruba

Hot Pluggable, MTP/MPO Connector, 850nm, VCSEL, Multimode



Product Description:

This is a parallel 40Gbps Quad Small Form-factor Pluggable (QSFP) optical module that provides increased port density and total system cost savings. The QSFP full-duplex optical module offers 4 independent transmit and receive channels, each capable of 10Gbps operation for an aggregate bandwidth of 40Gbps 100m on OM3 Multimode Fiber (MMF)and 150m on OM4 MMF.

Features:

  • 4 independent full-duplex channels
  • Up to 11.2Gbps per channel bandwidth
  • Aggregate bandwidth of > 40Gbps
  • MTP/MPO optical connector
  • QSFP MSA compliant
  • Digital diagnostic capabilities
  • Capable of over 100m transmission on OM3 Multimode Fiber (MMF)and 150m on OM4 MMF
  • CML compatible electrical I/O
  • Single +3.3V power supply operating
  • TX input and RX output CDR retiming
  • Built-in digital diagnostic functions
  • Temperature range 0°C to 70°C
  • RoHS Compliant Part

Applications:

² Rack to rack

² Data centers

² Metro networks

² Switches and Routers

² Infiniband 4x SDR, DDR, QDR

Ordering Information:

QSFP-40G-SR4 40Gb/s 150m MPO/MTP Connector, Multi mode, 850nm
QSFP-40G-LR4 40Gb/s 10km Duplex LC Connector, Single mode, 1270-1330nm

QSFP-40G-ER4

 40Gb/s 40km Duplex LC Connector, Single mode, 1270-1330nm
QSFP-40G-LR-S 40Gb/s 2km PSM4 MPO Connector, Single mode, 1310nm
QSFP-40G-LR-S 40Gb/s 10km PSM4 MPO Connector, Single mode, 1310nm
QSFP-40G-LX4 40Gb/s 150m Duplex LC Connector, Multi mode(OM3), 1270-1330nm
QSFP-40G-LX4 40Gb/s 2km Duplex LC Connector, Single mode, 1270-1330nm


Products Show

QSFP 40G SR 150M Optical Transceiver Module For Metro NetworkQSFP 40G SR 150M Optical Transceiver Module For Metro NetworkQSFP 40G SR 150M Optical Transceiver Module For Metro NetworkQSFP 40G SR 150M Optical Transceiver Module For Metro Network
QSFP 40G SR 150M Optical Transceiver Module For Metro Network
QSFP 40G SR 150M Optical Transceiver Module For Metro Network

QSFP 40G SR 150M Optical Transceiver Module For Metro Network
QSFP 40G SR 150M Optical Transceiver Module For Metro Network

Packaging & Shipping
QSFP 40G SR 150M Optical Transceiver Module For Metro Network
QSFP 40G SR 150M Optical Transceiver Module For Metro Network
