QSFP-100G-ELR4-Dual Rate 100G QSFP28 LAN WDM DML SMF 1310nm 20km LC with DDM Compatible for Cisco
QSFP-100G-ELR4-Dual Rate 100G QSFP28 LAN WDM DML SMF 1310nm 20km LC with DDM Compatible for Cisco
QSFP-100G-ELR4-Dual Rate 100G QSFP28 LAN WDM DML SMF 1310nm 20km LC with DDM Compatible for Cisco
QSFP-100G-ELR4-Dual Rate 100G QSFP28 LAN WDM DML SMF 1310nm 20km LC with DDM Compatible for Cisco
QSFP-100G-ELR4-Dual Rate 100G QSFP28 LAN WDM DML SMF 1310nm 20km LC with DDM Compatible for Cisco
QSFP-100G-ELR4-Dual Rate 100G QSFP28 LAN WDM DML SMF 1310nm 20km LC with DDM Compatible for Cisco
QSFP-100G-ELR4-Dual Rate 100G QSFP28 LAN WDM DML SMF 1310nm 20km LC with DDM Compatible for Cisco
QSFP-100G-ELR4-Dual Rate 100G QSFP28 LAN WDM DML SMF 1310nm 20km LC with DDM Compatible for Cisco
QSFP-100G-ELR4-Dual Rate 100G QSFP28 LAN WDM DML SMF 1310nm 20km LC with DDM Compatible for Cisco
QSFP-100G-ELR4-Dual Rate 100G QSFP28 LAN WDM DML SMF 1310nm 20km LC with DDM Compatible for Cisco
Specifications
Brand Name :
NuFiber
Model Number :
QSFP-100G-ELR4-Dual Rate
Certification :
CE FCC Rohs
Place of Origin :
China
MOQ :
1 piece
Payment Terms :
L/C, T/T, Western Union,Credit Card
Supply Ability :
10,000 pcs per month
Delivery Time :
Within 1-3 work days
Packaging Details :
4pcs/plastic plate
Data Rate :
100Gb/s
Wavelength :
1310nm
Distance :
20km
Connector :
LC
DDM :
Support
Fiber Type :
SMF
Power Supply :
3.3V
Working Temperature :
0~70℃
Warranty :
1 year
Compatibility :
Huawei, Cisco, HP, H3C...
Description

QSFP-100G-ELR4-Dual Rate 100G QSFP28 LAN WDM DML SMF 1310nm 20km LC with DDM Compatible for Cisco

(QSFP-100G-ELR4-Dual Rate)

Features

  • Supports multi-rate (100GBASE 100GE and OTU4);
  • From 103.1Gb/s to 111.8Gb/s aggregate;
  • Lane bit rate 25.78 Gb/s 100GE, 27.95 Gb/s OTU4;
  • Up to 20km transmission on SMF;
  • LAN WDM EML laser and PIN receiver;
  • High speed I/O electrical interface (CAUI-4);
  • I2C interface with integrated Digital Diagnostic monitoring;
  • QSFP28 MSA package with duplex LC connector;
  • Single +3.3V power supply;
  • Support HW TX_DIS and RX_LOS for telecom application;
  • Maximum power consumption 3.5 W;
  • Operating case temperature: 0 to +70 °C;
  • Compliant to IEEE 802.3bm, SFF-8665 and SFF-8679;
  • Complies with EU Directive 2011/65/EU (RoHS 6/6).

Applications

  • 100GBASE-LR4

Optical Parameters

Parameter Symbol Min. Typical Max. Unit Notes
Storage Temperature TS -40 - +85 °C
Supply Voltage VCC -0.5 - +4.0 V
Operating Relative Humidity RH - - +85 %

Recommended Operating Conditions

Parameter Symbol Min. Typical Max. Unit Notes
Operating Case Temperature TC 0 - +70 °C
Power Supply Voltage VCC 3.13 3.3 3.47 V
Power Supply Current ICC - - 1.1 A
Maximum Power Dissipation PD - - 3.5 W
Aggregate Bit Rate BRAVE - 103.125 - Gb/s
Lane Bit Rate BRLANE - 25.78 27.952 Gb/s
Transmission Distance TD - 20 km Over SMF


Ordering information

Part No.

 Data Rate Laser Fiber Type Distance Optical Interface Temp(°C) DDMI
QSFP-100G-ELR4-Dual Rate

103.1Gbps

111.8Gbps

1310nm LWDM

DML

 SMF 20km LC 0~70 Y

Products Show

QSFP-100G-ELR4-Dual Rate 100G QSFP28 LAN WDM DML SMF 1310nm 20km LC with DDM Compatible for CiscoQSFP-100G-ELR4-Dual Rate 100G QSFP28 LAN WDM DML SMF 1310nm 20km LC with DDM Compatible for CiscoQSFP-100G-ELR4-Dual Rate 100G QSFP28 LAN WDM DML SMF 1310nm 20km LC with DDM Compatible for CiscoQSFP-100G-ELR4-Dual Rate 100G QSFP28 LAN WDM DML SMF 1310nm 20km LC with DDM Compatible for CiscoQSFP-100G-ELR4-Dual Rate 100G QSFP28 LAN WDM DML SMF 1310nm 20km LC with DDM Compatible for Cisco

Applications:

QSFP-100G-ELR4-Dual Rate 100G QSFP28 LAN WDM DML SMF 1310nm 20km LC with DDM Compatible for Cisco

QSFP-100G-ELR4-Dual Rate 100G QSFP28 LAN WDM DML SMF 1310nm 20km LC with DDM Compatible for Cisco

Packaging & Shipping

QSFP-100G-ELR4-Dual Rate 100G QSFP28 LAN WDM DML SMF 1310nm 20km LC with DDM Compatible for Cisco

QSFP-100G-ELR4-Dual Rate 100G QSFP28 LAN WDM DML SMF 1310nm 20km LC with DDM Compatible for Cisco
