Rj45 UTP Fiber Ethernet Switch Media Converter 8 Port For IP Access Fiber Ethernet Switch
Rj45 UTP Fiber Ethernet Switch Media Converter 8 Port For IP Access Fiber Ethernet Switch
Rj45 UTP Fiber Ethernet Switch Media Converter 8 Port For IP Access Fiber Ethernet Switch
Rj45 UTP Fiber Ethernet Switch Media Converter 8 Port For IP Access Fiber Ethernet Switch
Specifications
Brand Name :
NuFiber
Model Number :
NF-1008G
Certification :
CE FCC Rohs
Place of Origin :
China
MOQ :
5 piece
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
5,000 pcs per week
Delivery Time :
1-3 work days
Packaging Details :
40pcs/carton, carton size: 55.6*32.8*43.5cm
Product name :
Gigabit ethernet switch
Ports :
8x10/100/1000M RJ45
Speed :
10/100/1000Mbps
Power Supply :
DC5V 1A
OEM&ODM :
Accepted
Material :
Iron Case
Application :
Network,Ethernet,Router
Working Temperature :
0 °C~ +70 °C
Warranty :
1 year
Description

10/100/1000M 8-port Rj45 full UTP Ethernet Switch media converter for IP access

10/100/1000M Full 8-port Rj45 Ethernet Switch

Model: NF-1008G

Rj45 UTP Fiber Ethernet Switch Media Converter 8 Port For IP Access Fiber Ethernet Switch

Description:

The NF-T1008G 8-port Gigabit Ethernet Switch provides you with a high-performance, low-cost, easy-to-use, seamless and standard upgrade to improve old network to 1000Mbps network. Increase the speed of your network server and backbone connections, or make Gigabit to the desktop a reality. Power users in the home, office, work-group, or creative production environment can now move large, bandwidth-intensive files faster.

Key features:

▪ 8-port 10/100/1000M Gigabit Ethernet Desktop Switch

▪ Supports MAC address self-learning and auto MDI/MDIX

▪ Supports IEEE 802.3x flow control for Full Duplex mode and back-pressure for Half Duplex mode

▪ Non-blocking switching architecture that forwards and filters packets at full wire-speed for maximum throughput

▪ Supports MAC address auto-learning and auto-aging

▪ LED indicators for monitoring power, link, activity

▪ External power adapter supply

Technical Specifications:

Standards and Protocols

IEEE802.3, 802.3u, 802.3ab, 802.3x

CSMA/CD, TCP/IP
Basic Function Wire-speed Performance
MAC Address Auto-Learning and Auto-aging
IEEE802.3x flow control for Full-Duplex Mode and back-pressure for Half-Duplex Mode
Back-bound Bandwidth 16Gbps
MAC Address Table 4k
Forwarding Rate

10BASE-T: 14880pps/port

100BASE-TX: 148800pps/port

1000BASE-T: 1488000pps/port
Transmission Method Store-and-Forward
Ports 8 10/100/1000Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX)
Network Media

10Base-T: UTP category 3, 4, 5 cable (maximum 100m)

EIA/TIA-568 100Ù STP (maximum 100m)

100Base-Tx: UTP category 5, 5e cable (maximum 100m)

EIA/TIA-568 100Ù STP (maximum 100m)

1000Base-T: UTP category 5, 5e cable (maximum 100m)
LED Indicators Power, 10/100M, 1000M
Environment Operating Temperature: 0°C~60°C
Storage Temperature: -40°C~70°C
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Power External Power Adapter
Size 140mm*75mm*25mm

Order Information:

Model Description
NF-T108F Media Converter 8*10/100Base-Tx,external power supply.
NF-T1008G Media Converter 8*10/100/1000Base-Tx,external power supply.
NF-T105F Media Converter 5*10/100Base-Tx,external power supply.
NF-T1005G Media Converter 5*10/100/1000Base-Tx,external power supply.

Product show:

Rj45 UTP Fiber Ethernet Switch Media Converter 8 Port For IP Access Fiber Ethernet SwitchRj45 UTP Fiber Ethernet Switch Media Converter 8 Port For IP Access Fiber Ethernet SwitchRj45 UTP Fiber Ethernet Switch Media Converter 8 Port For IP Access Fiber Ethernet SwitchRj45 UTP Fiber Ethernet Switch Media Converter 8 Port For IP Access Fiber Ethernet Switch

Connection Diagram:Rj45 UTP Fiber Ethernet Switch Media Converter 8 Port For IP Access Fiber Ethernet Switch

Factory show:

Rj45 UTP Fiber Ethernet Switch Media Converter 8 Port For IP Access Fiber Ethernet SwitchRj45 UTP Fiber Ethernet Switch Media Converter 8 Port For IP Access Fiber Ethernet SwitchRj45 UTP Fiber Ethernet Switch Media Converter 8 Port For IP Access Fiber Ethernet Switch

Packing & Shipping:

Rj45 UTP Fiber Ethernet Switch Media Converter 8 Port For IP Access Fiber Ethernet Switch

Rj45 UTP Fiber Ethernet Switch Media Converter 8 Port For IP Access Fiber Ethernet Switch

Rj45 UTP Fiber Ethernet Switch Media Converter 8 Port For IP Access Fiber Ethernet Switch
