CE1023 , ISO 13485 Approval
Stent Material: 316L Stainless Steel
Features:
The successful delivery of efficacy and safety through the combination of a proven drug and a reliable polymer
A Proven Drug Over 5 years of proven clinical application experience
Maximum DES Efficacy Effective anti-restenosis and anti-inlammatory properties
A Reliable Polymer / Long-term Safety
1: Advanced polymer-coating technology provides optimally controlled releasing of sirolimus that efficaciously inhibits intimal hyperplasia and restenosis.
2. PBMA/PEVA coating is a widely used biocompatible coating that provides an ideally controlled drug release.
3. Only 6 µm thickness of polymer, thinner coating increases deliverability of stent
Advanced Stent Design / High confidence delivery
1: Proprietary DOUBLE-HELIX stent structure is engineered for outstanding flexibility and conformability.
2: Optimal thickness of stent strut provides favorable balance between radial strength and deliverability
3: 36 mm length makes it easy to achieve full coverage of long lesion.
Technical Parameters:
Stent Material | 316 L Stainless Steel |
Strut Design | Open cell |
Metal to Artery Ratio | 15% |
Recoil | < 2% |
Shortening | <1% |
Strut Thickness | 90µm |
Crossing Profile | 0.9-1.2 mm |
Ordering Information:
Stent Diameter (mm) | Stent Length (mm) | |||||||
12 | 15 | 18 | 21 | 24 | 29 | 33 | 36 | |
2.5 | AP2512 | AP2515 | AP2518 | AP2521 | AP2524 | AP2529 | AP2533 | AP2536 |
2.75 | AP2712 | AP2715 | AP2718 | AP2721 | AP2724 | AP2729 | AP2733 | AP2736 |
3.0 | AP3012 | AP3015 | AP3018 | AP3021 | AP3024 | AP3029 | AP3033 | AP3036 |
3.5 | AP3512 | AP3515 | AP3518 | AP3521 | AP3524 | AP3529 | AP3533 | AP3536 |
4.0 | AP4012 | AP4015 | AP4018 | AP4021 | AP4024 | AP4029 | AP4033 | AP4036 |
Packaging:
1 PCS/Paper Box, 50 PCS/CTN, CTN SIZE: 53*31*45CM, G.W.: 8KG
