1919 Bi-Color COB LED Chip High CRI 90 7W+7W 300mA With Wide Viewing Angle
1919 Bi-Color COB LED Chip High CRI 90 7W+7W 300mA With Wide Viewing Angle
1919 Bi-Color COB LED Chip High CRI 90 7W+7W 300mA With Wide Viewing Angle
1919 Bi-Color COB LED Chip High CRI 90 7W+7W 300mA With Wide Viewing Angle
1919 Bi-Color COB LED Chip High CRI 90 7W+7W 300mA With Wide Viewing Angle
1919 Bi-Color COB LED Chip High CRI 90 7W+7W 300mA With Wide Viewing Angle
1919 Bi-Color COB LED Chip High CRI 90 7W+7W 300mA With Wide Viewing Angle
1919 Bi-Color COB LED Chip High CRI 90 7W+7W 300mA With Wide Viewing Angle
Specifications
Brand Name :
HuanYu Dream
Model Number :
HY-1917D2065-7S5P-14-F3
Certification :
RoHS
Place of Origin :
China
MOQ :
1piece
Price :
Negotiated
Payment Terms :
T/T, Paypal,Ali Pay
Supply Ability :
30000 units per day
Delivery Time :
10-15 Work Days
Packaging Details :
25 pcs/Tray
Product Name :
1919 bi-color COB
Power :
7W+7W
Series :
CW :7S2P WW:7S3P
Warranty :
3 Years
Lifespan :
50000 hours
CRI :
90
Application :
Smart lighting
Color temperature :
2700K/5400K
Description

1919 Bi-color COB Led Chip

1919 Bi-Color COB LED Chip High CRI 90 7W+7W 300mA With Wide Viewing Angle

* Dimension 19.0mm×19.0mm×1.5mm

* CRI: 90

* Wide viewing angle : 120°

* RoHS compliant

* Sulphation corrosion resistance

* Manual Soldering

* The White LED which was fabricated using a blue chip and phosphor

* Pure gold wire 99.99% bonding chips in circular array
* High quality mirror surface aluminum substrate applied

1919 Bi-color COB Led Chip Package Dimension

1919 Bi-Color COB LED Chip High CRI 90 7W+7W 300mA With Wide Viewing Angle

1919 Bi-Color COB LED Chip High CRI 90 7W+7W 300mA With Wide Viewing Angle

1919 Bi-Color COB LED Chip High CRI 90 7W+7W 300mA With Wide Viewing Angle

1919 Bi-color COB Led Chip Details

1919 Bi-Color COB LED Chip High CRI 90 7W+7W 300mA With Wide Viewing Angle

Electrical - Optical Characteristics at Ta=25℃

Type

Symbol

Test condition

 Value

Unit
Min. Typ. Max.
Forward Voltage VF IF=300mA 20 22 24 V
2700K-2900K φ IF=300mA 600 -- 900 Lm
5400K-5700K φ IF=300mA 700 -- 1000 Lm
Viewing Angle 2θ1/2 IF=300mA 120 Deg
Color Rendering Index CRI IF=300mA 90 -- 93 --
Thermal resistance Rth(j-s) IF=300mA -- -- 0.67 ℃/W

Absolute Maximum Ratings at Ta=25℃

Parameter Symbol Rating Units
Power Dissipation Pd 7*2W W
Forward Current IF 300 mA
Peak Forward Current IFP 390 mA
Junction temperature Tj 115 ℃
Solder temperature Ts 350 ℃
Operating Temperature Topr -40 ~ + 85 ℃
Storage Temperature Tstg -40 ~ + 100 ℃

Optica Characteristic curve

1919 Bi-Color COB LED Chip High CRI 90 7W+7W 300mA With Wide Viewing Angle

1919 Bi-Color COB LED Chip High CRI 90 7W+7W 300mA With Wide Viewing Angle

1919 Bi-Color COB LED Chip High CRI 90 7W+7W 300mA With Wide Viewing Angle

1919 Bi-color COB Led Chip Applications

Industry Standard Size Chip-on-Board package provide utmost flexibility to both indoor and outdoor applications

Premium commercial lighting

Industrial lighting

Residential lighting

Special lighting (horticulture, studio lightingfilm &photography lighting)
Great COB LED Chip for down lights, track lights, spot light, flood light, high bay light, low bay light, street light solar street light, yard lights, garden lights, underwater lights, lighthouse, par light, projector light, image light, etc

1919 Bi-Color COB LED Chip High CRI 90 7W+7W 300mA With Wide Viewing Angle

FAQ
Q1: Are you a factory or a trade company?
A: We are the manufacturer specialize in smd and cob led chips since 2013.

Q2: Can I get some samples for tests?
A: Yes, we can offer free samples, so you can have an intuitive understanding about our LED quality and performance. But our clients should pay for the shipping freight themselves.

Q3: What about the lead time?
A: Generally, it will take 3-5 working days for sample and 7-25 working days for mass order.

Q4: Do you accept customized products?
A: Yes, we can offer OEM and ODM service as per your request. Please kindly leave us messages about your requirements, our sales engineer will check the details as soon as possible.

Q5: How many years of warranty of products you offer? And how do you deal with the LED working issues?
A: We offer 3-year warranty by default, and longer warranty can be negotiated. If there is any problem with the product during the warranty, please feel free to contact us.


Q6: How to process the order?
A: 1. Let us know the requirements(size, color, power and quantity) of the products you need.
2. We will send you the quotation and check the stock.
3. We will send you proformer invoice after you confirm the samples.
4. You make the payment after checking the details.
5. We will arrange the delivery and continue to provide you the best service.
