Specifications
Brand Name :
UPGOAL
Model Number :
UG-1218
Certification :
CE
Place of Origin :
Jinan City, Shandong Province, China
MOQ :
1 set
Price :
USD 2200-USD 2500 FOB QINGDAO
Payment Terms :
T/T, L/C, Western Union, MoneyGram, D/A
Supply Ability :
210 sets/month
Delivery Time :
Within 7-10 working days
Packaging Details :
One plywood case, 1500*1200*1100mm, 300kg
Effective working area :
1200(X)mm*1800Y)mm*150(Z)mm
Materials :
Square steel tube machine holder, cast iron machine bed，cast aluminum gantry
Working table :
Aluminum alloy T Slot with PVC protection layer
Moving type :
Gantry moving
Guide rail :
Linear round guide rail
Transmission :
Lead ball screw for XYZ-axis
Driving mode :
Stepper motor and driver for XYZ-axis
Spindle motor :
2.2kw water cooling
Spindle speed :
0-24000rpm
Control system :
DSP offline control system
Suitable software :
Artcam, Type3, Ucancam V9,etc
Tool calibration :
Auto
Description

Economic 1218 Acrylic Wood MDF Engraving Cutting Machine with 1200*1800mm Working Area

Application

Industry application: Wood work, Advertising Sign&Mark, Acrylic Cutting, Advertising plate, Led Lamp.

Applicable material: Wood, Aluminum sheet, aluminum composite panel, dual-color plate, Mdf, Cristal plate, artifical marble and other metal and non-metal materials.

Working Method: 3D embossment engraving, 2D engraing and Cutting, Bottom Milling.

Features

1.Cast iron lathe bed. Stable running with less vibration.

2. With Gantry moving type, stable and durable for long time using. Ensure high positioning accuracy.

3.XYZ three axis are with linear round guide rail and block. Ball screws transmission for all axis. Durable running with higher accuracy.

4.Large Power 2.2kw water cooling spindle which is applicable not only for cooper plate, aluminum plate, iron plate engraving but also for wood working. It can cut 20-30mm thickness acrylic by one time cutting. The fine engraving is more smoothy and clear by large power spindle.

5.Dust-Proof desgin for XZ-axis, protect the guide rail and ball screws from the dust&dirt, help to ensure machine working performance.

6.DSP offline control system with USB interface which is completely off from Computer. More Humanized desgin with Simple and Convenient Handle type operation.With pre-calculation rule, fully excavating potentialities of motors. Enable high processing speed, synchronization of Curve and straight line, more perfect curve working and Spindle startup and stop automatically.

7.Rationalized placement of the electronic parts. Optimized heat dissipation effect. Adpot high quality electornic parts, minimizing fault rate, Adopt high flexible cable and imported electronic parts, electrical design of whole machine is complied with the CE standard.

8.With the function of Break-point memory ,power failure resuming and automatic home/origin correction function. The Working can be resumed afer unexpected situations or next day.effectively ensure long time working precision.

9.Working pause, speed adjust, working depth adjust at any time while working. Preview the 2D&3D working result With simulation fucntion. Variable Speed is suitable for varisou materials and industry.

10.Favorable compatibility with various CAM softwares such as Type3/Artcam/Mastercam/Caxa. With intelligent over limit protection fucntion which can stop the mechanical collision due to unproper size given to the design.

Technical parameters

Effective working area 1200(X)mm*1800Y)mm*150(Z)mm
Materials Square steel tube machine holder, cast iron machine bed, cast aluminum gantry
Working table Aluminum alloy T Slot with PVC protection layer
Moving type Gantry moving
Guide rail Linear round guide rail
Transmission Lead ball screw for XYZ-axis
Driving mode Stepper motor and driver for XYZ-axis
Spindle motor 2.2kw water cooling
Spindle speed 0-24000rpm
Inverter Sunfar
Voltage

AC 220V± 10%, 50/60Hz, sinle phase or

AC 380V±10%, 50/60Hz, three phases
Traveling speed >8000mm/min
Engraving speed >6000mm/min
Machine accuracy 0.05mm
Control system PCI NcStudio( for desktop computer, windows XP/7)
Suitable software Artcam, Type3, Ucancam V9,etc
Carving Instructions G code *Uoo *mmg *plt HPGL
Running environment temperature 0-45 ℃
Relative humidity 30%-75%
Tool calibration Auto
Certificate CE

Reference Parts Photos

2.2kw water cooling spindle & aluminum T slot working table

Economic 1218 Acrylic Wood MDF Engraving Cutting Machine with 1200*1800mm Working Area

Economic 1218 Acrylic Wood MDF Engraving Cutting Machine with 1200*1800mm Working Area

Linear round guide rail and lead ball screw transmission for XYZ-axis

Economic 1218 Acrylic Wood MDF Engraving Cutting Machine with 1200*1800mm Working Area

Stepper motor driver & DSP offline control system

Economic 1218 Acrylic Wood MDF Engraving Cutting Machine with 1200*1800mm Working Area

Control cabinet

Economic 1218 Acrylic Wood MDF Engraving Cutting Machine with 1200*1800mm Working Area

Reference Sample Photos

Economic 1218 Acrylic Wood MDF Engraving Cutting Machine with 1200*1800mm Working Area

Reference Working Videos

https://www.youtube.com/watch?v=yW-gg2VZ7xk&list=PLZ2SG5kTfvfOuC8DN3xJP8Y3dY4-3nG06

https://www.youtube.com/watch?v=TX8MveMxTBI&index=1&list=PLZ2SG5kTfvfNHFThTC-wtoG_74g35X_Yc

For more information, just feel free to contact us!
