4.4kg High Precision Mobile LiDAR System PM-1500 PRR100-2000kHz
4.4kg High Precision Mobile LiDAR System PM-1500 PRR100-2000kHz
4.4kg High Precision Mobile LiDAR System PM-1500 PRR100-2000kHz
4.4kg High Precision Mobile LiDAR System PM-1500 PRR100-2000kHz
Specifications
Brand Name :
Hi-Cloud
Model Number :
PM-1500 Mobile LiDAR System
Certification :
ISO, others upon the requests
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
15 sets/month
Delivery Time :
20-30 working days
Packaging Details :
Transport Case
Maximum Measurement Range :
1500m@60% reflectivity
Accuracy :
5mm@50m
FoV :
75°
Angular Resolution :
0.001°
Camera Resolution :
42.4MP
PRR :
100-2000Khz
Operation Temperature :
-40℃~60℃
Storage Temperature :
-45℃~70℃
Description

4.4kg 5mm@50m high precision 1500m@60% long range mobile LiDAR system PM-1500 with 2million points/s frequency

Independently developed by Wuhan Hi-Cloud Technology Co.,Ltd., the high-precision and long-range mobile LiDAR system PM-1500 integrates high-precision laser scanner, high-precision POS (GPS, IMU) and other sensors based on a new generation of core technology framework. The core component of the system is the laser scanner with multi-echo technology function.

It can be applied to multi rotor UAV, VTOL fixed wing UAV, small aircraft and helicopter to obtain dense high-precision laser point cloud data on the ground on a fast flying mobile platform. It can synchronously obtain 3D laser point cloud and POS data, quickly generate DSM, DEM and DOM and produce DLG and 3D models through a complete set of data processing and application software. The system is widely used in new basic surveying and mapping, digital 3D modeling, topographic surveying and mapping, cadastral survey, traffic survey, power line inspection, forestry survey, disaster monitoring and other fields.

Parameter specification of mobile LiDAR system PM-1500

Items Indicators Parameters
System Performance Dimension 293×165×164mm
Absolute Accuracy horizontal <5cm
vertical <5cm
Weight 4.4kg

Multi Echo

 4 times
Temperature and Humidity Operation: -40℃~60℃, Humidity 85%
Storage: -45℃~70℃, Humidity 85%
Items Indicators Parameters
Laser Scanner Wave Band Near Infrared (Class 1 )
PRR 100-2000Khz
Maximum Measurement Range 1000m@20% reflectivity
1500m@60% reflectivity
Range Accuracy 5mm@50m
Angular Resolution 0.001°
Scan Speed 40-400 scans/s
FoV 75°
Items Indicators Parameters
Camera Camera Resolution 42.4MP
Focal Length 28mm
Items Indicators Parameters
POS System Position Accuracy(post-processing) Horizontal 0.01m
Elevation 0.02m
Orientation Accuracy(post-processing) Heading 0.009°
Pitch/Roll 0.005°
Main advantages of mobile LiDAR system PM-1500
1. High precision: The ranging accuracy of PM-1500 mobile LiDAR system can reach 5mm@50m, and the comprehensive accuracy of the system is better than 5cm, meeting various high-precision application scenarios.
2. High frequency: The PM-1500 mobile LiDAR system with super high frequency of up to 2 million points per second can be equipped with UAV with faster cruising speed, and more data can be obtained in the same time.
3. Long measurement range: The ultra long ranging of 1500 meters greatly ensures the operation safety in the environment of large topographic fluctuation.
4. Lightweight body: The overall weight of the system is less than 4.4kg. Even if you go out to work with UAVs and other accessories, an ordinary vehicle can load all of them, which is very convenient.
5. Integration: The overall structure of PM-1500 airborne laser measurement system has been innovatively optimized. It highly integrates sensors such as laser scanner, GPS, IMU and aerial survey camera, etc. It is lightweight and easy to install.
6. Multi echo technology: The PM-1500 mobile LiDAR system applies multi echo technology. It can obtain up to 4 echo signals, and can penetrate trees and feed back the most real surface information even in densely vegetated areas.
Practical applications:
1. Topographic survey by PM-1500
4.4kg High Precision Mobile LiDAR System PM-1500 PRR100-2000kHz4.4kg High Precision Mobile LiDAR System PM-1500 PRR100-2000kHz
2. Digital 3D city model by PM-1500
4.4kg High Precision Mobile LiDAR System PM-1500 PRR100-2000kHz
4.4kg High Precision Mobile LiDAR System PM-1500 PRR100-2000kHz4.4kg High Precision Mobile LiDAR System PM-1500 PRR100-2000kHz
3. Inspection of 500kV DC transmission line by PM-1500
4.4kg High Precision Mobile LiDAR System PM-1500 PRR100-2000kHz
