4mm Bearing Bar And Cross Bar Thickness Steel Walkway Grating For Stair Tread
4mm Bearing Bar And Cross Bar Thickness Steel Walkway Grating For Stair Tread
4mm Bearing Bar And Cross Bar Thickness Steel Walkway Grating For Stair Tread
4mm Bearing Bar And Cross Bar Thickness Steel Walkway Grating For Stair Tread
Specifications
Brand Name :
ZhongTeng
Model Number :
ZT--016
Place of Origin :
China
Certification :
ISO9001
MOQ :
1000 M2
Price :
USD3.2-8.5/M2
Packaging Details :
Steel Pallets, Then Plastic Film In The Surface.
Delivery Time :
8-10 Days
Payment Terms :
TT/LC
Supply Ability :
1600m2/Days
Cross Bar Thickness :
3mm, 4mm, 5mm, 6mm
Bearing Bar Thickness :
3mm, 4mm, 5mm, 6mm
Surface Treatment :
Galvanized, Painted, Untreated
Color :
Black, Silver, Yellow, Blue
Bearing Bar Spacing :
30mm, 40mm, 60mm
Application :
Industrial Platforms, Walkways, Stair Treads, Drainage Covers, Etc.
Bearing bar size :
25x3, 25x4, 30x3, 30x4, 30x5, 32x5
Cross Bar Shape :
Twisted Square, Round, Rectangular
Description

Product Description:

Steel grating is produced by welding flat steel and bars together with specific distances between them. This process is typically followed by additional processes including cutting, opening, and edging, among others. The finished product boasts several features such as high strength, light structure, high bearing, convenience, and more. To make the product anti-corrosive, it is given a hot dipped zinc coating.

Given its multiple positive features, steel grating is widely used in various locations including platforms, corridors, bridges, well covers, stairs, and fences in the industry sectors of petroleum, chemical, power plant, waste treatment plant, as well as in civil engineering and environmental projects.

Features of Steel Grating
  • High strength
  • Light structure
  • High bearing capacity
  • Convenience for loading and unloading materials
  • Anti-corrosive properties due to hot dipped zinc coating
Applications of Steel Grating

The widespread use of steel grating owes to its versatility in various industrial and civil engineering projects, such as:

  • Platforms
  • Corridors
  • Bridges
  • Well covers
  • Stairs
  • Petroleum sectors
  • Chemical sectors
  • Power plants
  • Waste treatment plants
  • Environmental projects

Features:

Light weight,great load-bearing capacity,non-slip and safe,easy installation,material-economic,sturdy and durable, ventilated,easy to clean and attractive appearance.

Technical Parameters:

Common Specification of Steel Grating
Remarks: Special Material, Special High Zinc Coating and New Style can be Customized.
Material Standar ASTM A36, A1011, A569, Q235, S275JR, Stainless steel 304/316.
Mild steel & Low carbon steel, etc
Bearing Bar 25*3, 25*4, 25*4.5, 25*5, 30*3, 30*4, 30*4.5, 30*5, 40*5, 50*5, 65*5, 75*6, 75*10...100*10mm etc
(Width × Thickness) I bar: 25*5*3, 30*5*3, 32*5*3, 40*5*3 etc
US standard: 1"×3/16", 1 1/4"×3/16", 1 1/2"×3/16", 1"×1/4", 1 1/4"×1/4", 1 1/2"×1/4", 1"×1/8", 1 1/4"×1/8",1 1/2"×1/8" etc
Bearing Bar Pitch 12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 32.5, 34.3, 35, 38.1, 40, 41.25, 60, 80mm etc.
US standard: 19-w-4, 15-w-4, 11-w-4, 19-w-2, 15-w-2 etc
Twisted Cross Bar Pitch 38.1, 50, 60, 76, 80, 100, 101.6, 120mm,2" &4" etc.
Surface Treatment Untreated(black), Hot-dipped galvanized, Power coated, Electroplate, Painting or as per customers' requirement.
Grating Style Plain / Smooth, Serrated / Teeth, I bar, Serrated I bar

Applications:

The application of this material is extensive and can serve a variety of purposes. Specifically, it is frequently utilized in settings such as factories, workshops, and motor rooms. It can also be used in heavy loading areas, boiler equipment and heavy equipment areas.

Some of the primary uses for this material include flooring and catwalks. Additionally, it is commonly used for mezzanines and decking, as well as stair treads and ramp construction. It can even be utilized for fencing and drainage systems, including trench covers and drainage pit covers.

In addition to the above applications, this material can also be used for various types of maintenance platforms and pedestrian walkways. This is particularly useful in crowded factory settings, as well as on trolley channels or other surfaces that require durability and slip resistance.

Packing and Shipping:

Product Packaging:

Our Steel Bar Grating product is securely packed in bundles, wrapped with plastic sheeting and strapped with steel strips to ensure safe transportation and delivery to our customers.

Shipping:

We offer a variety of shipping options for our Steel Bar Grating product, including ground, air and sea transportation. Our logistics team will work with you to determine the best shipping method for your specific needs and location. We strive to provide timely and efficient delivery to ensure your project stays on schedule.

FAQ:

Q1: What is the Brand Name of the Steel Bar Grating?

A1: The Brand Name of the Steel Bar Grating is ZhongTeng.

Q2: What is the Model Number of the Steel Bar Grating?

A2: The Model Number of the Steel Bar Grating is ZT--016.

Q3: What is the Place of Origin of the Steel Bar Grating?

A3: The Place of Origin of the Steel Bar Grating is China.

Q4: Is the Steel Bar Grating certified?

A4: Yes, the Steel Bar Grating is certified with ISO9001.

Q5: What is the Minimum Order Quantity of the Steel Bar Grating?

A5: The Minimum Order Quantity of the Steel Bar Grating is 1000 M2.

Q6: What is the Price of the Steel Bar Grating?

A6: The Price of the Steel Bar Grating is USD3.2-8.5/M2.

Q7: How is the Steel Bar Grating packaged?

A7: The Steel Bar Grating is packaged in Steel Pallets, Then Plastic Film In The Surface.

Q8: What is the Delivery Time of the Steel Bar Grating?

A8: The Delivery Time of the Steel Bar Grating is 8-10 Days.

Q9: What are the Payment Terms for the Steel Bar Grating?

A9: The Payment Terms for the Steel Bar Grating are TT/LC.

Q10: What is the Supply Ability of the Steel Bar Grating?

A10: The Supply Ability of the Steel Bar Grating is 1600m2/Days.
