Specifications
Brand Name :
SY
Model Number :
MVP901
Certification :
FCC/CE/ROSH
Place of Origin :
China
MOQ :
1
Price :
US$39-US$45/PC
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
3000 pieces per week
Delivery Time :
5-8 working days
Packaging Details :
Standard color box or customized design color box packaging
Antenna :
2x External Antennas
Button :
Reset/WPS Button
Encryption :
WPA2/WPA/WEP
Frequency Band :
2.4GHz/5GHz
Interface :
4x 10/100/1000Mbps LAN Ports, 1x 10/100/1000Mbps WAN Port
LED Indicator :
Power/WAN/LAN/WLAN/WPS
Name :
5G Wireless Router
Operating Temperature :
0-40℃
Power Supply :
12V/1A
Signal Range :
Up to 150m
Storage Temperature :
-40-70℃
Transmission Rate :
Up to 1200Mbps
Wireless Standard :
802.11ac/n/a/g/b
Description

MT7975DN+MT7915DAN 5G WiFi Router: Dual Band 802.11ax/ac/a/b/g/n, 4*5dBi AntennaMT7975DN MT7915DAN 5G WiFi Router Dual Band 802.11ax / AC / A / B / G / N

MT7975DN MT7915DAN 5G WiFi Router Dual Band 802.11ax / AC / A / B / G / NMT7975DN MT7915DAN 5G WiFi Router Dual Band 802.11ax / AC / A / B / G / N

MT7975DN MT7915DAN 5G WiFi Router Dual Band 802.11ax / AC / A / B / G / N

Product Description
CPU/Memory
CPU: MT7621A, MT7975DN+MT7915DAN
RAM: 128M
ROM: 16M

5G/4G
Platform: UniSoC
Standard: 3GPP R15
Compatibility: 5G / 4G / 3G
5G architecture: NSA / SA
Frequency(optional):
CN - WCDMA/HSPA+: Band 1/2/5/8, LTE FDD: Band 1/2/3/5/7/8, LTE TDD: Band 34/38/39/40/41, NR: n1/n281/n41/n78/n79
AE - WCDMA: Band 1/2/5/8, FDD-LTE: Band 1/2/3/5/7/8, TDD-LTE: Band 34/39/40/41,
FDD - NR: n1/28, TDD-NR: n41/77/78/79, GNSS: GPS/GLONASS/Galileo/BDS/QZSS
EAU6 - 5G Sub-6: n1/3/5/7/8/20/28/38/40/41/75/76/77/78, LTE FDD: B1/3/5/7/8/20/28/32
LTE TDD: B38/40/41/42/43, WCDMA: B1/5/8, 5G NR DL 4*4 MIMO: n1/3/5/7/20/28/38/40/41/75/76/77/78 UL 2*2MIMO: n41/77/78, LTE : DL 4*4 MIMO: B1/3/5/7/20/28/32/38/40/41/42/43
5G rate: 2.2Gbps / 766Mbps Max(Region dependent)
4G rate: 487Mbps / 150Mbps Max(Region dependent)

WLAN
Standard: WiFi 6, compatible with IEEE 802.11 ac/n/b/g/a
Frequency: 2.4 Ghz / 5.8G
Radio mode: MiMo dual 2x2
Transmit Power: 18dBm(5.8G), 18dBm(2.4G)
Data rate: 1201Mbps(5.8G)+574Mbps(2.4G)
Concurrent Clients: 120
Sensitivity:
11ax: -60dBm@10% PER, 11ac: -62dBm@10% PER, 11n: -68dBm@10% PER,
11g: -70dBm@10% PER, 11a: -68dBm@10% PER, 11b: -88dBm@8% PER
Antenna
5G/4G: Integrated 5G/4G main/diversity antenna
WiFi: Integrated 2 x 2.4 Ghz 5dBi omni, Integrated 2 x 5.8 Ghz 5dBi omni

Interfaces
Wire: 3 x 10/100/1000M ETH port RJ45
Card slot: 1 x Nano SIM
LED: 1 x PWR, 1 x WPS, 1 x Internet, 1 x WiFi
Other: 1 x Reset Button, 1 x WPS button, 1 x PWR button

Software
Operating system: Customized Linux or Openwrt, Feature customizing
Operating mode: Router, Wireless station, Wireless repeater, 5G/4G mode
Internet method: 5G/4G, WAN(Static IP, DHCP client, PPPoE client)
Services: DHCP Server, DHCP Relay, DDNS
Network techniques: Port forwarding, DMZ, UPnP, VPN(L2TP/PPTP, IPSec under OpenWrt, Static routing
Security: IP filtering, MAC filtering, URLfiltering, Port-scanning / SYN flooding attack defense
QoS: Speed limitting based on IP
5G/4G: IMEI code modifying, Frequency locking, Multi-SIM card, Data usage management, Manual APN,.etc.
Other: Internet status detecting, Network switching

Physical
Dimension: 215 mm x 98 mm x 98 mm
Weight: 825g
Power
Power supply: 12V/1.5A DC
Power source: 100 – 240V AC, 50/60Hz
Power consumption (max): 16 W

Environmental
Operating temperature: -30°C ~ +55°C
Humidity: 0 ~ 90 % (non-condensing)

Package contains
Router: 1
12V 1.5A DC: 1
Other: 1 x User Manual, 1 x Warranty card
Company Profile
Hunan Sanyi Technology Co., Ltd. located at Changsha, China. Professional in R&D and producing network devices, specially for processing OEM/ODM. Products include openWRT WiFi router, 4G/5G router, Mesh
Router, WiFi 6 Router, Industrial&Enterprise Router, Vehicles Router, AP, Outdoor CPE and LTE CPE.
Sayi is also a Wi-Fi coverage service provider, provides the solution for hotel, school, hospital, enterprise, airport and vehicle field. We have built a long term cooperation with Mediatek, Broadcom and Qualcomm, capably offering good quality products and fast after-sale service to our clients. Our main customers are China Mobile, Vivacom in
Bulgaria, Sprint, T-Mobile, AT&T in USA and Smart in Philippine.
Sanyi warmly welcome everybody joining in and build win-win cooperation.
FAQ

Can you printing Customer logo on products?
Yes, we can printing your logo on products.

Do you provide PCBA board order only?
Of course, as a OEM/ODM manufacturer, we can provide PCBA in a short time with good quality.

Can you desin products as per customer's requirements?
Yes, of course. We have our own R&D department, we have ability to design and produce at same time.

How do you ship the goods and how long does it take to arrive?
A. It usually takes 5-7 days to arrive. Airline and sea shipping is also optional.

How to proceed with an order?
A. Firstly let us know your requirements or application. Secondly, We quote according to your requirements or our
suggestions.Thirdly customer confirms the samples and places a deposit for formal order. Fourthly We arrange the production.
