29dBi High Gain PtP Dual Polarized Parabolic Antenna 2x2 MIMO Dish Antenna
29dBi High Gain PtP Dual Polarized Parabolic Antenna 2x2 MIMO Dish Antenna
29dBi High Gain PtP Dual Polarized Parabolic Antenna 2x2 MIMO Dish Antenna
29dBi High Gain PtP Dual Polarized Parabolic Antenna 2x2 MIMO Dish Antenna
29dBi High Gain PtP Dual Polarized Parabolic Antenna 2x2 MIMO Dish Antenna
29dBi High Gain PtP Dual Polarized Parabolic Antenna 2x2 MIMO Dish Antenna
29dBi High Gain PtP Dual Polarized Parabolic Antenna 2x2 MIMO Dish Antenna
29dBi High Gain PtP Dual Polarized Parabolic Antenna 2x2 MIMO Dish Antenna
29dBi High Gain PtP Dual Polarized Parabolic Antenna 2x2 MIMO Dish Antenna
29dBi High Gain PtP Dual Polarized Parabolic Antenna 2x2 MIMO Dish Antenna
29dBi High Gain PtP Dual Polarized Parabolic Antenna 2x2 MIMO Dish Antenna
29dBi High Gain PtP Dual Polarized Parabolic Antenna 2x2 MIMO Dish Antenna
29dBi High Gain PtP Dual Polarized Parabolic Antenna 2x2 MIMO Dish Antenna
29dBi High Gain PtP Dual Polarized Parabolic Antenna 2x2 MIMO Dish Antenna
Specifications
Brand Name :
XJS
Model Number :
TDD-4865-29
Certification :
ROHS CE
Place of Origin :
Guangdong, China
MOQ :
2
Price :
$45~55/piece
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
3000 pcs per month
Delivery Time :
5~15 work days
Packaging Details :
carton packaging, 47*44*25cm/2pcs, 48.5*45.5*52cm/4pcs
Frequency :
4800-6500MHz
Gain :
29dBi
H Beamwidth :
6.5°
V Beamwidth :
6.5°
Polarization :
±45°
F/B Ratio :
≥30dB
Dimensions :
420*420*120 mm
Max. Power :
50W
Lightning Protection :
Dc Ground
Description

5 GHz 29dBi High Gain PtP Antenna Dual Polarized 2x2 MIMO Parabolic Dish Antenna

This is a High Gain PtP Antenna Dual Polarized 2x2 MIMO Parabolic Dish Antennas.

It is a perfect match for 802.11a MIMO access points and bridges. It also supports the new 6.2 GHz and 6.4 GHz radios now available. Both ports support 4.8 GHz - 6.5 GHz operation.

Radios Supported:

  • Ubiquiti RocketM5®, RocketM5® GPS, Rocket® Prism 5AC
  • Mimosa C5c
  • MikroTik BaseBox® 5, NetMETAL® 5
  • TP-Link WBS510
  • Cambium ePMP™
  • Mimosa B5c (requires optional cable kit)

Features

  • Expanded Coverage: 4800 MHz to 6500 MHz
  • 2 ports, Suits for Radio like RocketM5, Mimosa C5c
  • Cross Polarized, ±45° Polarization (Polarization Diversity)
  • All-Weather Outdoor Operation
  • MIMO Applications
  • 5 GHz 802.11a
  • Wi-Fi Hotspots
  • WISP Base Station
  • WiMAX

Electrical Specifications

Frequency Range 4800-6500 MHz
Gain (dBi) 29 dBi
Horizontal Beamwidth 6.5°
Vertical Beamwidth 6.5°
VSWR <1.8
Polarization ±45°
F/B Ratio ≥30 dB
Impedance 50Ω

Mechanical Specifications

Connector Customized
Dimensions 420*420*120 mm
Weight (Kg) 6kg/2pcs
Lightning Protection Dc Ground
Rated Wind Speed 126/ms
Mounting Type Pole Mount
Suitable pole diameter Ф30-80mm

RF Antenna Patterns

29dBi High Gain PtP Dual Polarized Parabolic Antenna 2x2 MIMO Dish Antenna

29dBi High Gain PtP Dual Polarized Parabolic Antenna 2x2 MIMO Dish Antenna

29dBi High Gain PtP Dual Polarized Parabolic Antenna 2x2 MIMO Dish Antenna

Package Included

29dBi High Gain PtP Dual Polarized Parabolic Antenna 2x2 MIMO Dish Antenna
