4.8GHz 18dBi Long Range WiFi Antenna WiMAX Cell Site Antenna
4.8GHz 18dBi Long Range WiFi Antenna WiMAX Cell Site Antenna
4.8GHz 18dBi Long Range WiFi Antenna WiMAX Cell Site Antenna
4.8GHz 18dBi Long Range WiFi Antenna WiMAX Cell Site Antenna
4.8GHz 18dBi Long Range WiFi Antenna WiMAX Cell Site Antenna
4.8GHz 18dBi Long Range WiFi Antenna WiMAX Cell Site Antenna
4.8GHz 18dBi Long Range WiFi Antenna WiMAX Cell Site Antenna
4.8GHz 18dBi Long Range WiFi Antenna WiMAX Cell Site Antenna
Specifications
Brand Name :
XJS
Model Number :
TDS-4865-18
Certification :
ROHS CE
Place of Origin :
Guangdong, China
MOQ :
2
Payment Terms :
Western Union, L/C, T/T
Frequency :
4800-6500MHz
Gain :
18dBi
H Beamwidth :
120°
V Beamwidth :
4°
Polarization :
±45°
F/B Ratio :
≥26db
Dimensions :
700*157*30 mm
Max. Power :
50W
Lightning Protection :
Dc Ground
Description

4.8-6.5GHz 18dBi 120 Degree WiFi WLAN MIMO Sector Antenna for communication

This 120° mimo sector antenna provides high gain with a wide 120° beam-width making them ideal professional quality antennas designed primarily for service providers in the 4.8-6.5GHz band

This antenna makes an ideal alternative to the Ubiquiti AirMax Sector AM-5G16-120 antenna.

Features

  • Dual Polarity feed system in single enclosure
  • MIMO - Multiple-Input and Multiple-Output
  • Two integral N-Female connectors
  • UV-resistant radome for all-weather operation

Application

  • 4.9/5.1/5.3/5.4/5.8/6.4/6.5 GHz Wireless LAN systems
  • MIMO PtMP 1x2, 2x2 base station
  • Supports IEEE 802.11a/n applications
  • WiMAX, WISP, WiFi, Mobile Communication, Cell-site

Electrical Specifications

Frequency Range 4800-6500 MHz
Gain (dBi) 18 dBi
Horizontal Beamwidth 120°
Vertical Beamwidth 4°
VSWR <1.8
Polarization ±45°
F/B Ratio ≥26db
Impedance 50Ω

Mechanical Specifications

Connector Customized
Dimensions 700*157*30 mm
Weight (Kg) 3.8 kg
Lightning Protection Dc Ground
Rated Wind Speed 126/ms
Mounting Type Pole Mount
Suitable pole diameter Ф30-80mm

RF Antenna Patterns

4.8GHz 18dBi Long Range WiFi Antenna WiMAX Cell Site Antenna

4.8GHz 18dBi Long Range WiFi Antenna WiMAX Cell Site Antenna

4.8GHz 18dBi Long Range WiFi Antenna WiMAX Cell Site Antenna

4.8GHz 18dBi Long Range WiFi Antenna WiMAX Cell Site Antenna

4.8GHz 18dBi Long Range WiFi Antenna WiMAX Cell Site Antenna

This antenna offers high-gain, 120-degree wireless beam performance for broad coverage. Combine with other Sector Antennas to create complete, 360-degree area coverage that can be applied to any variety of point-to-multipoint scenarios.

4.8GHz 18dBi Long Range WiFi Antenna WiMAX Cell Site Antenna
