4800MHz To 6500MHz 33dbi Solid Dish Antenna 720mm Ultra Wideband Antenna
4800MHz To 6500MHz 33dbi Solid Dish Antenna 720mm Ultra Wideband Antenna
4800MHz To 6500MHz 33dbi Solid Dish Antenna 720mm Ultra Wideband Antenna
4800MHz To 6500MHz 33dbi Solid Dish Antenna 720mm Ultra Wideband Antenna
4800MHz To 6500MHz 33dbi Solid Dish Antenna 720mm Ultra Wideband Antenna
4800MHz To 6500MHz 33dbi Solid Dish Antenna 720mm Ultra Wideband Antenna
4800MHz To 6500MHz 33dbi Solid Dish Antenna 720mm Ultra Wideband Antenna
4800MHz To 6500MHz 33dbi Solid Dish Antenna 720mm Ultra Wideband Antenna
Specifications
Brand Name :
XJS
Model Number :
TDD-4865-33
Certification :
ROHS, CE
Place of Origin :
Guangdong, China
MOQ :
2
Price :
USD 72-82
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50000+PCS+month
Delivery Time :
15-20 wroking days
Packaging Details :
carton size 76*76*33cm
Freq. Range :
4800-6500 MHz
Gain :
33dBi
Max. Power :
50W
Lightning Protection :
Dc Ground
Connector :
SMA*2
V Beamwidth :
3.4°
Dimensions :
Ф720*720*195mm
H Beamwidth :
3.4°
Polarization :
±45°
Weight (Kg :
7 kg
F/B Ratio :
≥45dB
Temperature Range :
-35～+50℃
VSWR :
≤1.8
Rated Wind Speed :
126/ms
Impedance :
50Ω
Mounting Type :
Pole Mount
Description

Long range 4.8-6.5GHz 33dBi 720mm WiFi Wlan mimo dish antenna

New Arrival TDD-4865-33 is a ultra performance wideband dual polarized solid dish antenna with ultra electrical performance and mechanical stability, the parabolic dish antenna can be used in a wide variety of 4.8GHz and 6.5 GHz range (4.9/5.1/5.3/5.4/5.8/6.5GHz) wireless applications.

Applications

  • 5 GHz ISM and UNII band
  • 802.11n MIMO and WiMax
  • Long-range applications
  • Point-to-point
  • Backhaul/client antenna

Features

  • Dual polarity feed
  • Aluminum reflector dish
  • UV stable light gray polymer finish
  • All weather operation
  • Includes tilt and swivel mast mount kit

Electrical Specifications

Frequency Range 4800-6500 MHz
Gain (dBi) 33 dBi
Horizontal Beamwidth 3.4°
Vertical Beamwidth 3.4°
VSWR <1.8
Polarization ±45°
F/B Ratio ≥45db
Impedance 50Ω

Mechanical Specifications

Connector 2*SMA
Dimensions Φ720mm
Weight (Kg) 7 kg
Lightning Protection Dc Ground
Rated Wind Speed 126/ms
Mounting Type Pole Mount
Suitable pole diameter Ф30-80mm

RF Antenna Patterns

4800MHz To 6500MHz 33dbi Solid Dish Antenna 720mm Ultra Wideband Antenna

4800MHz To 6500MHz 33dbi Solid Dish Antenna 720mm Ultra Wideband Antenna

Compare With Current Exist Dish Antenna In The Market

Picture 4800MHz To 6500MHz 33dbi Solid Dish Antenna 720mm Ultra Wideband Antenna 4800MHz To 6500MHz 33dbi Solid Dish Antenna 720mm Ultra Wideband Antenna 4800MHz To 6500MHz 33dbi Solid Dish Antenna 720mm Ultra Wideband Antenna
Item Rocket Dish Current exist dish XJS New Design dish
Freq. 4.9-5.8 GHz 4.9-6.4 GHz 4.8-6.5 GHz
Gain 34dBi 32dBi 33dBi
Dimension Φ1050mm Φ900mm Φ720mm
Weight 13kg 12kg 7kg
F/B Ratio ≥42db ≥38db ≥45db

XJS NEW Design Dish Antenna Advantage:

  • Compact in size
  • Ultra high gain
  • Amazing F/B Ratio

Product Details

4800MHz To 6500MHz 33dbi Solid Dish Antenna 720mm Ultra Wideband Antenna

Package Included

4800MHz To 6500MHz 33dbi Solid Dish Antenna 720mm Ultra Wideband Antenna

Packing

  • 1 pcs or 2 pcs in one carton is available.
  • Compact in packing size, save your delivery cost
  • Foam packing, strong protection during delivery.

4800MHz To 6500MHz 33dbi Solid Dish Antenna 720mm Ultra Wideband Antenna

Loading Quantity

4800MHz To 6500MHz 33dbi Solid Dish Antenna 720mm Ultra Wideband Antenna

Installation Guide

4800MHz To 6500MHz 33dbi Solid Dish Antenna 720mm Ultra Wideband Antenna
