Outdoor ODF Optical Distribution Frame 24 / 48 Port Corning Fiber SC MPO Panel
Outdoor ODF Optical Distribution Frame 24 / 48 Port Corning Fiber SC MPO Panel
Specifications
Brand Name :
Unique-Tel
Model Number :
PXX02
Certification :
CE RoHS
Place of Origin :
China
MOQ :
10 Pieces
Price :
Negotiation
Payment Terms :
T/T, L/C
Supply Ability :
100 Pieces/Month
Delivery Time :
5 work days
Packaging Details :
carton packaging
Height :
1U 2U 3U 4U
Adapter :
SC/FC/LC/ST
Material :
cold-rolled sheet
Type :
Sliding or Rotary
Installation :
19" rack mounted
Function :
Splice and Distribution
Color :
White/Black/Gray/Others
Application :
FTTH FTTB FTTX Network,Telecommunication
Description

19 Inch Outdoor 24 48 Port Corning Fiber SC MPO Preloaded Optic Patch Panel

Features

1. The shell is high intensified & insulated material, thus having excellent mechanic performance and

2. it is solid and durable

3. strength core and insulated shell, add with grounding lead

4. Wall mount available

5. Full accessories for convenient operations

Performance

1. excellent design

2. fiber lead grounding and perfect fix-up reliable

3. pigtail fix-up reliable and perfect protection

4. Apply to extensive field

5. convenient operations and maintenance

Specifications

1. Environment temperature -25~+45℃

2. Relative humidity ≤ 85%30

3. Atmosphere pressure70106KPa

4. Insulated Resistance ≥ 2×10MΩ / 500VDC

5. Intensity ≤ 15KV(DC) / 1minno spark-over and no flying arc

6. Fiber bending radium guaranteed more than 40mm ≥ 40mm

Application: It is applicable for straight-through connection and diverged connection in aerial layout , duct and direct buried. It can protect fiber connectors.

Patch panels can be loaded with adapters, splice cassettes and pigtails.

Order Information:

Type L×W×H Port Configuration Capacity (core) Connector
SC24 485mm×305mm×1U 4 24 SC
FC24 485mm×305mm×1U 4 24 FC
ST24 485mm×305mm×1U 4 24 ST
SC48 485mm×305mm×2U 4 48 SC
FC48 485mm×305mm×2U 4 48 FC
ST48 485mm×305mm×2U 4 48 ST
SC72 485mm×305mm×3U 4 72 SC
FC72 485mm×305mm×3U 4 72 FC
SC96 485mm×305mm×4U 4 96 SC
FC96 485mm×305mm×4U 4 96 FC

12, 24, 48, 96, 144, 288 port available;

SC, FC, ST port available;

OEM acceptable.
