10 Feet OM4 Fiber Optic Patch Cable ST To LC Duplex Plenum Armored PVC Material
10 Feet OM4 Fiber Optic Patch Cable ST To LC Duplex Plenum Armored PVC Material
10 Feet OM4 Fiber Optic Patch Cable ST To LC Duplex Plenum Armored PVC Material
10 Feet OM4 Fiber Optic Patch Cable ST To LC Duplex Plenum Armored PVC Material
10 Feet OM4 Fiber Optic Patch Cable ST To LC Duplex Plenum Armored PVC Material
10 Feet OM4 Fiber Optic Patch Cable ST To LC Duplex Plenum Armored PVC Material
Specifications
Brand Name :
Unique-Tel
Model Number :
GXTX03
Certification :
CE RoHS
Place of Origin :
China
MOQ :
100 Meters
Price :
Negotiation
Payment Terms :
T/T, L/C
Supply Ability :
10000 Meters/Month
Delivery Time :
5 work days
Packaging Details :
carton & PVC packaging
Color :
Aqua
Material :
PVC
Connector :
ST - LC
Length :
Customized
Cable type :
Drop cable
Fiber type :
Multimode OM4
Application :
FTTH FTTB FTTX Network
Wavelength :
1310nm/1550nm/850nm/1300nm
Description

10 Feet Multimode OM4 ST to LC Duplex Plenum Armored Fiber Patch Cable​

Overview

Unique-Tel Patch Cords provide the interface between distribution cables and active optical equipment. Patch cords are offered in simplex and duplex cable types in both singlemode and multimode fibers. Bend insensitive fibers meeting G.657-A2/B2 provide low light loss and tight bend radius

in enterprise office applications. Factory-terminated connectors are designed to meet stringent mechanical and environmental

specifications for most interconnect applications. Unique-Tel patch cords are designed especially for building back bone and passive optical LAN installations.

Unique-Tel Armored (Formerly Light Armored) Plenum Armored Fiber Patch Cable is specifically designed for light to medium duty indoor/outdoor applications. Its rugged shell with steel and kevlar is 10 times stronger than regular Fiber Optic Cable and has a 40% higher rated range of operating temperature. Custom configurations available. It is ROHS compliant according to ROHS2011/65/EU and come with a 10 year warranty.

NOTE: Non-cancellable special order item. Please call to confirm stock. Images are for illustrative purposes only.

Features

ST/LC Plenum Armored Fiber Patch Cable

Ideal for 40G/100G networks

3.0mm 50/125µm Aqua OM4 Cable

Ceramic Ferrules to Ensure Consistent Low Loss

Complete Test Report

Serialized for Quality Tracking

Complies with TIA-604-10 and IEC 61754-20

Custom Configurations Available

Bend insensitive fiber

UPC and APC polishes

1.6 mm and 2.0 mm jacketing

Low light loss in tight bend radius (7.5 mm)

Industry intermateability

Small size high density applications

Specifications

Specification Fiber Type (Each Connector) SC/APC SC/UPC LC/UPC
Attenuation (dB) Typical Singlemode Multimode 0.3 0.3 0.3
0.2 0.2 0.2
Reflection (dB) Typical Singlemode Multimode (50 µm) -65 -45 -45
N/A -30 -30
Operating temperature Singlemode Multimode -40° to 85°C -40° to 85°C -40° to 85°C
-40° to 85°C -40° to 85°C -40° to 85°C
Storage temperature Singlemode Multimode (50 µm) -40° to 85°C -40° to 85°C -40° to 85°C
-40° to 85°C -40° to 85°C -40° to 85°C
Cable rating Singlemode Multimode

Riser

Riser

Riser

Riser

Riser

Riser

10 Feet OM4 Fiber Optic Patch Cable ST To LC Duplex Plenum Armored PVC Material
