HE Rectifier Module 5G Network Equipment 53.5V DC Voltage 48 / 3000 HE 241119.105
HE Rectifier Module 5G Network Equipment 53.5V DC Voltage 48 / 3000 HE 241119.105
HE Rectifier Module 5G Network Equipment 53.5V DC Voltage 48 / 3000 HE 241119.105
HE Rectifier Module 5G Network Equipment 53.5V DC Voltage 48 / 3000 HE 241119.105
HE Rectifier Module 5G Network Equipment 53.5V DC Voltage 48 / 3000 HE 241119.105
HE Rectifier Module 5G Network Equipment 53.5V DC Voltage 48 / 3000 HE 241119.105
HE Rectifier Module 5G Network Equipment 53.5V DC Voltage 48 / 3000 HE 241119.105
HE Rectifier Module 5G Network Equipment 53.5V DC Voltage 48 / 3000 HE 241119.105
Specifications
Brand Name :
ELTEK
Model Number :
Flatpack2 48/3000 HE
Certification :
CE, RoHS
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
1000 sets/month
Delivery Time :
within 10 days of payment
Packaging Details :
carton box
Part No. :
241119.105
Efficiency :
>95.5% at 25~75% load
Output Power :
3000 W at nominal input
Maximum Current :
62.5 Amps at 48V DC and nominal
DC Output voltage :
53.5V DC (adj. range: 43.5-58.0V DC)
AC Input voltage :
85-300V AC (Nominal 185 – 275V AC)
Description

Flatpack2 Eltek Valere 48V 3000W HE Rectifier Module 48/3000 HE 241119.105

Technical Specification:


AC Input:
Voltage :85-300V AC (Nominal 176 – 275V AC)
Frequency :45 to 66Hz
DC Output:
Voltage: 53.5V DC (adj. range: 43.5-58.0V DC)
Output Power : 3000 W at nominal input
Maximum Current: 62.5 Amps at 48 VDC and nominal
Output Protection: Overvoltage shutdown, Short circuit proof, High temperature protection
Efficiency:> >95.5% at 25~75% load
Operating Temp.:-40 to +75°C (-40 to +158°F)
MTBF :> 350, 000 hours


Mechnical Specification:


Dimensions- 109 x 41.5 x 327mm (wxhxd)
Weight- 1.95 kg (4.31lbs)


Ordering Information:


Part No.: 241115.105 Flatpack2 Rectifier Module 48/3000
