Single Mode OPLC Hybrid Fiber Power Cable 1-12 Cores Underground Optical Cable
Single Mode OPLC Hybrid Fiber Power Cable 1-12 Cores Underground Optical Cable
Specifications
Brand Name :
Unique-Tel
Model Number :
NWGL18
Certification :
CE/ROHS/ISO9001/TUV/ROSH
Place of Origin :
China
MOQ :
1000 meters
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
100000 meters/month
Delivery Time :
within 10 days
Packaging Details :
wooden drum
Color :
Black
Jacket sheath :
HDPE,MDPE
Fibre optical :
Single mode
Packing :
Wooden Drum
Core :
G652D, G657A1, G657A2
Jacket :
PVC LSZH LSOH PE HDPE
Layout ways :
underground/buried/pipeline
Description

OPLC Hybrid Optical Fiber Power Cable 1-12 Core Fiber Optic Cable

Characteristic of hybrid fiber cable

1. The composite cable provides the equipment electricity and single transmission, and improves central monitoring and maintenance for equipment power.

2. To reduce the coordination and maintenance of power supply.

3. Combines optical fiber (multimode or single mode) and copper conductor for DC power in a single light weight aluminum corrugated cable.

Hybrid Fiber Cable Parameter

Cable Type Fiber Counts Cable Diameter(mm) Weight(KG/KM) Tensile Strength(N) Crush Resistance(N/100mm)
Long term Short term Long term Short trem
GDTS- 2*1.5 2-24 11.2 132 600 1500 300 1000
GDTS-2*2.5 2-24 12.3 164 600 1500 300 1000
GDTS- 2*4.0 2-24 13.4 212 600 1500 300 1000
GDTS-2*5.0 2-24 14.6 258 600 1500 300 1000
GDTS- 2*6.0 2-24 15.4 287 600 1500 300 1000
GDTS-2*8.0 2-24 16.5 350 600 1500 300 1000

Note:

1. 2*1.5/2*2.5/2*4.0/2*6.0 is the number of specification of the conductor.

2. Different conductor specification can be make as required.

3. Different fiber specification can be make as required.

Our Service

1. Free samples are available

2. Fast Delivery, normally 5 Days after payment

3. Strictly quality control system

4. Quality Certificate ISO9001 is available

Application

1. hybrid of fiber cable Suitable the filed where needs to transmit light single and electric single.

2. Mobile operator deploying an RRU architecture to standardize the RRU.

Specifications

Jacket PVC LSZH LSOH PE HDPE
Certification CE/ROHS/ISO9001/TUV/ROSH
Color Black
Packing Wooden Drum
fiber optical core G652D, G657A1, G657A2
Layout ways underground/buried/pipeline
Fibre optical Single mode
Jacket sheath HDPE,MDPE

Single Mode OPLC Hybrid Fiber Power Cable 1-12 Cores Underground Optical Cable

Single Mode OPLC Hybrid Fiber Power Cable 1-12 Cores Underground Optical Cable
