Top industrial quality Stainless Steel Cutting Discs 125mm 5" Grassland
Products Descriptions:
•Diameter: 125mm (5 inch)
•Thickness: 1.mm
•Hole/Bore: 22.23mm
•Vmax: 80 m/s
•Max RPM: 102500
Key Points:
- Can be used to cut all types of steel
- Suits angle grinders with a 22mm chuck
- Thinner disc means a faster & cooler cutting action. An absolute must for Stainless Steel
- Complies to AS 1788.1-1987 DIN EN 12413
Grassland Metal Inox Thin Cutting Discs enable a very clean quick cut to be achieved with little effort. They are perfect for precise vibration free metal cutting.Manufactured using Aluminium Oxide abrasive grit with fibre glass reinforcing and resin bonded to provide both safety and optimum cutting performance
Grassland cutting discs are made from premium grade materials and offer fast cutting and long blade life in one
Produced to the highest of standards these wheels are designed for fabricators and engineers that need a blade that not only cuts quickly but also has a good blade life.
Field of Application:
Thin sheet metal of the type used in car bodies, tank farms and the tank construction sector, steel cable, thin-walled profile sections and pipes made of stainless steel and non-ferrous metals. Composite materials.
Cutting wheel information: | |||
Product Name | 5” Inox cutting disc | Abrasive | Aluminum oxide SA |
Hardness | R Grade | Net Standard | Reinforced fiberglass |
Max working speed | 80 m/s | OEM Service | Acceptable |
R.P.M | 102500 | Package | Normal Kraft Carton and Pallet |
Grit size | 46#,60# | HS Code | 68042210 |
Certificate | MPA EN12413,ISO9001 | Loading Port | Tianjin or else |
--Big size cutting wheel for inox&stainless steel
Description of goods | Item No | Specification | Unit | PCS/CTN | N.W./G.W.(KGS) | CARTON SIZE(CM) |
Flat cutting disc for inox 80m/s | FSC3003225 | T41-300X3.2X25.4MM | PC | 25 | 13/14 | 30*30*9.5 |
FSC3004025 | T41-300X4.0X25.4MM | PC | 25 | 14/15 | 30*30*11 | |
FSC3503225 | T41-350X3.2X25.4MM | PC | 25 | 17/18 | 35.5*35.5*9.5 | |
FSC3504025 | T41-350X4.0X25.4MM | PC | 20 | 17/18 | 35.5*35.5*9.5 | |
FSC4003225 | T41-400X3.2X25.4MM | PC | 25 | 22/23 | 40*40*9.5 | |
FSC4004025 | T41-400X4.0X25.4MM | PC | 20 | 22/23 | 40*40*9.5 |
---Depressed center rough discs for metal
Description of goods | Item No | Specification | Unit | PCS/CTN | N.W./G.W.(KGS) | CARTON SIZE(CM) |
Depressed grinding disc for metal 80m/s | DAG1004016 | T27-100X4.0X16MM | PC | 200 | 14/15 | 21*21*25 |
DAG1006016 | T27-100X6.0X16MM | PC | 200 | 21/22 | 35.7*22*22 | |
DAG1154022 | T27-115X4.0X22.2MM | PC | 100 | 9.5/10.5 | 24.5*24.5*14.2 | |
DAG1156022 | T27-115X6.0X22.2MM | PC | 100 | 15/16 | 24.5*24.5*19.2 | |
DAG1157022 | T27-115X7.0X22.2MM | PC | 100 | 17.5/16.5 | 24.5*24.5*22.2 | |
DAG1158022 | T27-115X8.0X22.2MM | PC | 100 | 19.5/18.5 | 24.5*24.5*25.2 | |
DAG1254022 | T27-125X4.0X22.2MM | PC | 100 | 11.5/12.5 | 26.5*26.5*14.2 | |
DAG1256022 | T27-125X6.0X22.2MM | PC | 100 | 17.5/18.5 | 26.5*26.5*19.2 | |
DAG1257022 | T27-125X7.0X22.2MM | PC | 100 | 20/19 | 26.5*26.5*22.2 | |
DAG1258022 | T27-125X8.0X22.2MM | PC | 100 | 23/22 | 26.5*26.5*25.2 | |
DAG1504022 | T27-150X4.0X22.2MM | PC | 100 | 18.5/19.5 | 32*32*14.2 | |
DAG1506022 | T27-150X6.0X22.2MM | PC | 100 | 12/13 | 32*32*19.2 | |
DAG1507022 | T27-150X7.0X22.2MM | PC | 60 | 18/17 | 32*32*13.7 | |
DAG1508022 | T27-150X8.0X22.2MM | PC | 60 | 20/19 | 32*32*15.2 | |
DAG1804022 | T27-180X4.0X22.2MM | PC | 60 | 14.5/15.5 | 37.5*19*17.7 | |
DAG1806022 | T27-180X6.0X22.2MM | PC | 60 | 22/23 | 37.5*25*19 | |
DAG1807022 | T27-180X7.0X22.2MM | PC | 30 | 11/12 | 37.5*19*13.5 | |
DAG1808022 | T27-180X8.0X22.2MM | PC | 60 | 28/29 | 37.5*19*29.7 | |
DAG2304022 | T27-230X4.0X22.2MM | PC | 30 | 10.5/11.5 | 24*24*17.7 | |
DAG2306022 | T27-230X6.0X22.2MM | PC | 30 | 18/19 | 24*24*22.7 | |
DAG2307022 | T27-230X7.0X22.2MM | PC | 30 | 19/20 | 24*24*26.7 | |
DAG2308022 | T27-230X8.0X22.2MM | PC | 30 | 21/22 | 25*24.5*29.7 |
