405mm Mild Steel 46# 16 Inch Cut Off Saw
405mm Mild Steel 46# 16 Inch Cut Off Saw
405mm Mild Steel 46# 16 Inch Cut Off Saw
405mm Mild Steel 46# 16 Inch Cut Off Saw
Specifications
Brand Name :
JZX
Model Number :
400X3.0X25.4
Certification :
ISO9001，ISO14001 and MPA EN12413
Place of Origin :
China
MOQ :
10000
Price :
US$1.2-1.5 per piece
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
300 thousand PCS per day
Delivery Time :
30-60 Days
Packaging Details :
shrink wrap-inner box-carton-enhanced pallet
abrasive :
aluminium oxide and corundum
color :
Black
Hardness :
R
Max working speed :
80 M/S
Grit size :
46#,60#
Iterm NO. :
FAC4053225
Application :
Ferrous metal and all steel metal cutting
Bonding Agent :
Resin
Arbor Size :
1 in
Disc type :
T41 type
Description

16 inch cut off saw 405mm Cutting off Slitting Discs For Stainless steel & Mild Steel

Description

. Diameter: 405mm (16 inch)
. Thickness 3.2 mm
. Bore Size 25.4mm
. High Preformance thin fiber cutting wheel
. 2 Layers of Reinforcing

. Optimum angle for use 90°

Cut-off Wheels are manufactured in accordance with MPA safety requirement and ISO 9001 standard.

This series of products adopt high-quality glass fiber and resin as the reinforced material of chelating agent, feature high tensile strength and shock strength and are used for production of precious metal including stainless steel.
The excellent materials and exquisite technology guarantee the good protection of stainless steel work pieces, high cutting efficiency and the best economic effects.

Applications


For general purpose metal and steel and applications –structural steel cross sections, pipes, and tubing.


Cutting wheel information:
Product Name Chop saw wheel 16" Abrasive Aluminum oxide and corundum
Hardness R Grade Net Grade Reinforced fiberglass
Max working speed

80 m/s

 OEM Service Acceptable
R.P.M 3850 Package

Kraft Carton and Pallet
Grit size 46#,24#,30# HS Code 68042210

Certificate

MPA EN12413,ISO9001

 Loading Port Tianjin or else

1.Thin cutting disc for multi purpose 3in1

Description of goods Item No Specification Unit PCS/CTN N.W./G.W.(KGS) CARTON SIZE(CM)
Flat cutting disc for Mulit 80m/s FMC0751009 T41-75X1.0X9.5MM PC 800 9/10 34*17*17
FMC0751695 T41-75X1.6X9.5MM PC 800 14/15 34*20*17
FMC1001016 T41-100X1.0X16MM PC 400 8.5/9.5 22*22*15.7
FMC1002016 T41-100X2.0X16MM PC 400 15/16 29.7*22*22
FMC1151022 T41-115X1.0X22.2MM PC 400 11/12 24.5*24.5*15.7
FMC1151622 T41-115X1.6X22.2MM PC 400 14/15 24.5*24.5*19.2
FMC1152022 T41-115X2.0X22.2MM PC 200 9.5/10.5 24.5*24.5*13.2
FMC1251022 T41-125X1.0X22.2MM PC 400 13/14 26.5*25.6*15.7
FMC1251622 T41-125X1.6X22.2MM PC 400 17/18 26.5*25.6*19.2
FMC1252022 T41-125X2.0X22.2MM PC 200 10.5/11.5 26.5*26.5*13.2
FMC1501622 T41-150X1.6X22.2MM PC 200 12/13 32*32*11.7
FMC1502022 T41-150X2.0X22.2MM PC 200 16.5/17.5 32*32*13.2
FMC1801622 T41-180X1.6X22.2MM PC 200 20/21 37.5*19*22.7
FMC1802022 T41-180X2.0X22.2MM PC 100 10.5/11 37.5*19*13.2
FMC2301622 T41-230X1.6X22.2MM PC 50 8/9 24*24*11.7
FMC2302022 T41-230X2.0X22.2MM PC 100 18.5/19.5 24*24*25.7

2-Type 42 depressed center grinding discs wheel.

Description of goods Item No Specification Unit PCS/CTN N.W./G.W.(KGS) CARTON SIZE(CM)
Depressed Cutting disc for metal 80m/s DAC1002516 T42-100X2.5X16MM PC 200 8/9 22*22*20.2
DAC1152522 T42-115X2.5X22.2MM PC 200 12/13 24.5*24.5*20.2
DAC1252522 T42-125X2.5X22.2MM PC 200 14/15 26.5*26.5*20.2
DAC1502522 T42-150X2.5X22.2MM PC 150 15/16 34*26*17
DAC1802522 T42-180X2.5X22.2MM PC 150 19.5/20.5 40*20*26
DAC2302522 T42-230X2.5X22.2MM PC 50 11.5/12.5 24*24*20.7
DAC2502522 T42-250X2.5X22.2MM PC 50 11.5/12.5 25*25*19
Depressed Cutting disc for metal 80m/s DAC1003216 T42-100X3.2X16MM PC 400 21.5/20.5 22X22X19.7
DAC1153222 T42-115X3.2X22.2MM PC 200 14/15 24.5*24.5*22.2
DAC1253222 T42-125X3.2X22.2MM PC 200 16/17 26.5*26.5*22.2
DAC1503222 T42-150X3.2X22.2MM PC 200 25/26 32*32*22.2
DAC1803222 T42-180X3.2X22.2MM PC 100 18/19 37.5*19*23.7
DAC2303222 T42-230X3.2X22.2MM PC 50 14/15 24*24*23.7
DAC2503222 T42-250X3.2X22.2MM PC 50 17.5/16.5 25*25*21
