125mm 125x1x22 5 Inch Abrasive Metal Cutting Discs
125mm 125x1x22 5 Inch Abrasive Metal Cutting Discs
Specifications
Brand Name :
Grassland
Model Number :
125X1.0X22.23
Certification :
ISO9001，ISO14001 and MPA EN12413
Place of Origin :
China
MOQ :
10000
Price :
US$0.17-0.18 per piece
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
300 thousand PCS per day
Delivery Time :
30-60 Days
Packaging Details :
shrink wrap-inner box-carton-enhanced pallet
abrasive :
aluminium oxide and other materials
color :
Black
Hardness :
R
Max working speed :
80 M/S
Grit size :
46#,60#
Iterm NO. :
FAC1251022
Application :
Ferrous metal and all steel cutting
Bonding Agent :
Resin
Arbor Size :
7/8 in
Disc type :
Flat type
Description

5 inch metal cutting discs 125mm 125x1x22 abrasive cutting disc


Description :

Multilevel excellent glass fiber mesh and resin as reinforced bonded material. High cutting efficiency.
Ultra-thin cutting piece wear-resistant, no broken edge and low dissipation for processed materials.
High-quality, high-strength fiber materials have strong impact resistance, which can bring higher work efficiency and economic benefits.

Thin Discs with a 1.2mm thickness permit fine cutting where necessary on stainless steel and high grade metals,extremely fast cutting with sharpness ,minimal vibration for more comfortable working,

Easy-to-read labels are incorporated into the manufacturing process and therefore remain intact throughout the life of the wheel.

Technical Specification:
Size - 125mm x 1.0mm x 22.23mm
RPM - 12250rpm 80 m/s
Grade - A60RBF
F41/F42 Flat/DPC - F41 (FLAT)

Applications :

Grinding off Steel, Iron, M.S plates, rods, bars, pipes, angles, squre and other irregular sections Shaping of metal surface, finishing of welding & burrs


Cutting wheel information:
Product Name 125mm 1mm cutting discs Abrasive Aluminum oxide
Hardness R Grade Net Standard Reinforced fiberglass
Max working speed

80 m/s

 OEM Service Acceptable
R.P.M 12250 Package

Kraft Carton and Pallet
Grit size 46#,60# HS Code 68042210

Certificate

MPA EN12413,ISO9001

 Loading Port Tianjin or else

Description of goods Item No Specification Unit PCS/CTN N.W./G.W.(KGS) CARTON SIZE(CM)
Flat cutting disc for metal 80m/s FAC0751095 T41-75X1.0X9.5MM PC 800 9/10 34*17*17
FAC0751695 T41-75X1.6X9.5MM PC 800 14/15 34*20*17
FAC1001016 T41-100X1.0X16MM PC 400 8.5/9.5 22*22*15.7
FAC1002016 T42-100X2.0X16MM PC 400 15/16 27.7*22*22
FAC1151022 T41-115X1.0X22.2MM PC 400 11/12 24.5*24.5*15.7
FAC1151622 T41-115X1.6X22.2MM PC 400 14/15 24.5*24.5*19.2
FAC1152022 T41-115X2.0X22.2MM PC 200 9.5/10.5 24.5*24.5*13.2
FAC1251022 T41-125X1.0X22.2MM PC 400 13/14 26.5*25.6*15.7
FAC1251622 T41-125X1.6X22.2MM PC 400 17/18 26.5*25.6*19.2
FAC1252022 T41-125X2.0X22.2MM PC 200 10.5/11.5 26.5*26.5*13.2
FAC1501622 T41-150X1.6X22.2MM PC 200 12/13 32*32*11.7
FAC1502022 T41-150X2.0X22.2MM PC 200 16.5/17.5 32*32*13.2
FAC1801622 T41-180X1.6X22.2MM PC 200 20/21 37.5*19*22.7
FAC1802022 T41-180X2.0X22.2MM PC 100 10.5/11 37.5*19*13.2
FAC2301622 T41-230X1.6X22.2MM PC 50 8/9 24*24*11.7
FAC2302022 T41-230X2.0X22.2MM PC 100 18.5/19.5 24*24*25.7

Description of goods Item No Specification Unit PCS/CTN N.W./G.W.(KGS) CARTON SIZE(CM)
Flat cutting disc for Mulit 80m/s FMC0751009 T41-75X1.0X9.5MM PC 800 9/10 34*17*17
FMC0751695 T41-75X1.6X9.5MM PC 800 14/15 34*20*17
FMC1001016 T41-100X1.0X16MM PC 400 8.5/9.5 22*22*15.7
FMC1002016 T41-100X2.0X16MM PC 400 15/16 29.7*22*22
FMC1151022 T41-115X1.0X22.2MM PC 400 11/12 24.5*24.5*15.7
FMC1151622 T41-115X1.6X22.2MM PC 400 14/15 24.5*24.5*19.2
FMC1152022 T41-115X2.0X22.2MM PC 200 9.5/10.5 24.5*24.5*13.2
FMC1251022 T41-125X1.0X22.2MM PC 400 13/14 26.5*25.6*15.7
FMC1251622 T41-125X1.6X22.2MM PC 400 17/18 26.5*25.6*19.2
FMC1252022 T41-125X2.0X22.2MM PC 200 10.5/11.5 26.5*26.5*13.2
FMC1501622 T41-150X1.6X22.2MM PC 200 12/13 32*32*11.7
FMC1502022 T41-150X2.0X22.2MM PC 200 16.5/17.5 32*32*13.2
FMC1801622 T41-180X1.6X22.2MM PC 200 20/21 37.5*19*22.7
FMC1802022 T41-180X2.0X22.2MM PC 100 10.5/11 37.5*19*13.2
FMC2301622 T41-230X1.6X22.2MM PC 50 8/9 24*24*11.7
FMC2302022 T41-230X2.0X22.2MM PC 100 18.5/19.5 24*24*25.7

125mm 125x1x22 5 Inch Abrasive Metal Cutting Discs

125mm 125x1x22 5 Inch Abrasive Metal Cutting Discs

125mm 125x1x22 5 Inch Abrasive Metal Cutting Discs
