8500m3/h Single Phase Six Pole AC Axial Fan 890rpm 560mm Blade
8500m3/h Single Phase Six Pole AC Axial Fan 890rpm 560mm Blade
8500m3/h Single Phase Six Pole AC Axial Fan 890rpm 560mm Blade
8500m3/h Single Phase Six Pole AC Axial Fan 890rpm 560mm Blade
8500m3/h Single Phase Six Pole AC Axial Fan 890rpm 560mm Blade
8500m3/h Single Phase Six Pole AC Axial Fan 890rpm 560mm Blade
8500m3/h Single Phase Six Pole AC Axial Fan 890rpm 560mm Blade
8500m3/h Single Phase Six Pole AC Axial Fan 890rpm 560mm Blade
8500m3/h Single Phase Six Pole AC Axial Fan 890rpm 560mm Blade
8500m3/h Single Phase Six Pole AC Axial Fan 890rpm 560mm Blade
8500m3/h Single Phase Six Pole AC Axial Fan 890rpm 560mm Blade
8500m3/h Single Phase Six Pole AC Axial Fan 890rpm 560mm Blade
Specifications
Brand Name :
Schniro Fan
Model Number :
AL_560E6
Certification :
CCC ,CE, RoHS, UL
Place of Origin :
Shanghai China
MOQ :
5pcs
Payment Terms :
T/T
Delivery Time :
30 work days
Packaging Details :
Carton，Plywood wooden cases
Blade Material :
AL-alloy
Blade diameters :
560mm
Max air flow :
8500m3/h
Max static pressure :
110Pa
Power :
0.51kw
Voltage range :
3~400V +/-10%
Rotate speed :
890rpm
Ambient temperature :
55°C
Frequency :
50Hz
Protection Class :
IP54
Description

Single phase six pole Axial fan with 560mm Diameter blade

The external rotor axial flow fan adopts high quality aluminum alloy integrated blade and high efficiency external rotor motor. Characterized by large air volume, low noise, low energy consumption, stability, high reliability, widely used. Available with mesh cover, panel mount or cylinder


8500m3/h Single Phase Six Pole AC Axial Fan 890rpm 560mm Blade

Service is the extension of quality,With outstanding quality and loyal service to pursue the most satisfaction of customers.

Pre-sale Services:
· To provide users with pre-sales technical support, and provide users with a personalized selection or design recommendations based on the actual site's needs.
· User jointly develop applied to industry-specific special purpose machinery.

Sale of services:
· In accordance with the order or user requirements, coordination of stocking or production cycle.
· Provide a detailed production schedule or project plan to the user.

After-sale Service:
· To provide a lifetime goods services for all fans, included equipment maintenance, spare parts supply, provide manuals and video,etc.
· To provide remote service support by phone and network freely.
