12v 150ah Agm Battery FT Sealed Deep Cycle Lead Acid For Solar System
12v 150ah Agm Battery FT Sealed Deep Cycle Lead Acid For Solar System
12v 150ah Agm Battery FT Sealed Deep Cycle Lead Acid For Solar System
12v 150ah Agm Battery FT Sealed Deep Cycle Lead Acid For Solar System
12v 150ah Agm Battery FT Sealed Deep Cycle Lead Acid For Solar System
12v 150ah Agm Battery FT Sealed Deep Cycle Lead Acid For Solar System
12v 150ah Agm Battery FT Sealed Deep Cycle Lead Acid For Solar System
12v 150ah Agm Battery FT Sealed Deep Cycle Lead Acid For Solar System
Specifications
Brand Name :
FOBERRIA
Model Number :
FBR12-150FT
Certification :
CE / ISO9001
Place of Origin :
CHINA
MOQ :
50pcs
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
60,000 per month
Delivery Time :
25-30days
Packaging Details :
Cartons with pallet
Name :
UPS battery
Model :
FBR12-150FT
Voltage :
12V
Capacity :
150AH
Terminal :
F13
Dimension :
551*110*297mm
Weight :
48.5kg±4%
Color :
Black
Feature :
Low Self Discharge
Application :
UPS,Solar system
Size :
552*238*221mm
Long life :
10 years/12 years
Type :
Front terminal battery series
Description

12v 150ah agm battery FT sealed Deep Cycle Lead acid Battery Solar Battery

What are the characteristics of the front terminal battery?

The simple safety factor is easy to maintain and maintain. The output resistance and output resistance of the amplifier can also be applied randomly, which can be handled reasonably, reduce the difficulty coefficient of multi structure single series processing of single connected terminal battery, improve the total area and quality of single connected battery, and improve the reliability of single connected cell combination process.

> Main Features

1. Excellent safety performance:No electtolyte leakage,battery swelling and cracking under normal use.


2. Good discharging performance : with smooth discharging voltage and mild discharging platform.


3. Good resistance to overdischarge:In temperature of 25 degrees celsius, the fully charged battery discharges with fixed resistance which is equivalent to the one required by 1ca discharge of the battery for three weeks, and it can restore capacity over 75%.


4. Good resistance to overcharge:The fully charged battery is proved to maintain normal open circuit voltage and be without leakage or batteries swelling or cracking in temperature of 25 degrees celsius after charging at 0.1ca for 48 hours, and the capacity maintain over 95%.


5. Good resistance to high current:The fully charged battery is proved to be without conductive part melted or any appearance deformation after discharging at 2ca for 5 minutes or 10ca for 5 seconds.

>Application

1. Used for communication power supply (access network, micro cellular base station, mobile, 3G technology, etc.)

2. Power supply system of private or local area network

3. Access network equipment of communication system

4. UPS, EPS and other standby power supplies

12v 150ah Agm Battery FT Sealed Deep Cycle Lead Acid For Solar System
> Specification
Battery Model No. FBR12-150FT
Nominal Voltage 12V
Capacity 20HR(10.5V) 150Ah
(25ºC) 10HR(10.5V) 132Ah
1HR(9.6V) 90Ah
Dimension Length 551±2mm
Width 110±2mm
Height 297±2mm
Total height 297±2mm
Approx. Weight 48.5kg±4%
Terminal type F13
Internal resistance(Fully charged,25ºC) Approx 4.2mΩ
Capacity affected by 40ºC 102%
Temperature(20HR) 25ºC 100%
0ºC 85%
-15ºC 65%
Self-discharge(25ºC) 3month Remaining Capacity:91%
6month Remaining Capacity:82%
12month Remaining Capacity:65%
Nominal operating temperature 25ºC±3ºC(77ºF±5ºF)
Operating Discharge -15ºC-50ºC(5ºF-122ºF)
temperature range Charge -10ºC-50ºC(14ºF-122ºF)
Storage -20ºC-50ºC(-4ºF-122ºF)
Float charging voltage
(25ºC)		 13.6 to 13.8V
Temperature compensation:-18mV/ºC
Cyclic charging voltage
(25ºC)		 14.5 to 15V
Temperature compensation:-30mV/ºC
Max charging current 45A
Max discharging current 1200A(5sec.)
Designed floating life(20ºC) 12years
12v 150ah Agm Battery FT Sealed Deep Cycle Lead Acid For Solar System
12v 150ah Agm Battery FT Sealed Deep Cycle Lead Acid For Solar System
12v 150ah Agm Battery FT Sealed Deep Cycle Lead Acid For Solar System
>Structure and composition
Component Positive plate Negative plate Container Cover Separator Electrolyte Safety valve Terminal
Raw material Lead dioxide Lead ABS ABS AGM Sulfuric acid Rubber Copper
12v 150ah Agm Battery FT Sealed Deep Cycle Lead Acid For Solar System
>Constant Current Discharge Characteristics(A,25ºC)
F.V/Time 10min 15min 30min 60min 2h 3h 4h 5h 8h 10h 20h
9.6V 262 202 121 74.2 43.8 31.2 25.2 21.5 14.8 12.2 6.47
9.9V 254 197 118 73 43.6 31 25.1 21.4 14.7 12.2 6.46
10.2V 243 190 115 71.2 43.2 30.8 24.9 21.3 14.6 12.2 6.44
10.5V 233 183 112 69.7 42.6 30.6 24.7 21.1 14.5 12.1 6.4
10.8V 220 173 108 67.6 41.5 29.7 24 20.5 14.1 12 6.36

>Constant Power Discharge Characteristics(Watt,25ºC)

F.V/Time 10min 15min 30min 60min 2h 3h 4h 5h 8h 10h 20h
9.60V 2825 2214 1353 845 508 367 297 255 176 146 77.7
9.90V 2741 2160 1326 833 505 365 295 253 175 146 77.5
10.2V 2628 2081 1285 812 500 362 293 251 174 145 77.3
10.5V 2514 2010 1254 795 493 360 291 250 172 144 76.9
10.8V 2373 1904 1208 770 480 349 282 242 167 143 76.3
>Discharge diagram
12v 150ah Agm Battery FT Sealed Deep Cycle Lead Acid For Solar System
12v 150ah Agm Battery FT Sealed Deep Cycle Lead Acid For Solar System
>Production process
12v 150ah Agm Battery FT Sealed Deep Cycle Lead Acid For Solar System
>Workshop scene
12v 150ah Agm Battery FT Sealed Deep Cycle Lead Acid For Solar System
>FAQ
Q1: How to choose the right battery?

A1: Tell us your demand, then our sales will recommend a suitable battery for you.

Q2. Do you have any MOQ limit?

A2: Yes, we have MOQ for mass production, it depends on the different model numbers.
50-500pcs sample order is available. for sample checking is available.

Q3. Is it OK to print my logo on the product?

A3: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q4: How to solve the technical problem?

A4: 24 hours after-service consultancy just for you and to make your problem to solve easily.

Q5:. What certificate your company have?

A5: ISO 9001, ISO 14001, OHSAS 18001, CE, UL, IEC 61427 test report, Patent for gel technology and other Chinese honor.

Q6. What is your warranty time for VRLA battery ?

A6: It depends on battery capacity, depth of discharge, and battery usage. Please kindly contact us for accurate information based on detailed requirements.

Q7. Why battery has different capacity at different hour rate?

A7: The capacity of a battery, in Ahs, is a dynamic number that is dependent on the discharge current.
For example, a battery that is discharged at 10A will give you more capacity than a battery that is discharged at 100A.
With the 20-hr rate, the battery is able to deliver more Ahs than with the 2-hr rate because the 20-hr rate uses a lower discharge current than the 2-hr rate.

Q8. Are you a battery manufacturer, and do you produce the plate by yourself ?

A8: Yes, we are a professional battery manufacture in Fujian Province, China. And we produce plates by ourselves.
