12V 100ah Rechargeable Sealed Lead Acid Battery For Power And Solar Storage
12V 100ah Rechargeable Sealed Lead Acid Battery For Power And Solar Storage
Specifications
Brand Name :
FOBERRIA
Model Number :
FBR12-40
Certification :
CE / ISO9001
Place of Origin :
CHINA
MOQ :
50pcs
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
60,000 per month
Delivery Time :
25-30days
Packaging Details :
Cartons with pallet
Battery Size :
12V 100Ah
Battery type :
Lead Acid Battery
Terminal type :
Copper/Lead
Material :
Pure
Terminal :
F14
Dimension :
197*165*175mm
Weight :
12.5kg
Color :
Black/White/Customized
Feature :
Low Self Discharge
Application :
EPS and UPS battery backup
Description

12V 100ah Rechargeable Sealed Lead Acid Battery For Power And Solar Storage ​

General Feature:

1. Long battery life, high capacity, Superior of recovery after discharge.
2. ABS material: increase the strength of battery container. (Flame-retardant ABS is optional)
3. High purity raw material: ensure low self discharge rate.
4. Silver-coated copper terminals, brass insert terminals and lead terminals improve the electric conductivity.
5. Pb CaSn alloy for plate grids: less gassing, less self-discharging high quality.
6. Maintenance-Free Operation
7. Low Self-Discharge

> Specification
Battery Model No. FBR12V40Ah
Nominal Voltage 12V
Capacity 20HR(5.25V) 40Ah
(25ºC) 10HR(5.25V) 35Ah
1HR(4.80V) 24.5Ah
Dimension Length 197±2mm
Width 165±2mm
Height 175±2mm
Total height 175±2mm
Approx. Weight 12.5kg±4%
Terminal type F14
Internal resistance Approx 8.5mΩ
(Fully charged,25ºC)
Capacity affected by 40ºC 102%
Temperature(20HR) 25ºC 100%
0ºC 85%
-15ºC 65%
Self-discharge(25ºC) 3month Remaining Capacity:91%
6month Remaining Capacity:82%
12month Remaining Capacity:65%
Nominal operating temperature 25ºC±3ºC(77ºF±5ºF)
Operating Discharge -15ºC-50ºC(5ºF-122ºF)
temperature range Charge -10ºC-50ºC(14ºF-122ºF)
Storage -20ºC-50ºC(-4ºF-122ºF)
Float charging voltage
(25ºC)		 13.5 to 13.8V
Temperature compensation:-18mV/ºC
Cyclic charging voltage
(25ºC)		 14.5 to 15V
Temperature compensation:-30mV/ºC
Max charging current 12A
Max discharging current 400A(5sec.)
Designed floating life(20ºC) 10years

> Main Features

1. No memory effect

Some Sealed Lead Acid batteries say nickel –cadmium batteries will become conditioned to provide less power offer repetitious

short usage /discharge.

2. Maintenance free

As it is valve-regulated rechargeable sealed lead acid battery.sealed and glass mat is utilized .acid is trapped inside.

so refilling is not needed and is leak proof.

3. Low self discharge

The self –discharge rate for FOBERRIA Sealed Lead Acid Battery is about 2-3% per month at room .temperature compared with 20-30%

for other common battery systems.

4. Longer service life

Used thick and massive calcium grate ensure that FOBERRIA battery has a longer service life over 10years.

5. High discharge rate

Since the internal resistance is low .the battery can provide high rate of discharge.

6. Wide operation temperature range

VRLA Sealed Lead Acid Battery capacity is rated at 25°C , and will operate from 15°C +50°C when it is fly charged Ambient temperature

is 25°C.Service life will be more efficient under 15’C to 25”C .

> Structure and composition
Component Positive plate Negative plate Container Cover Separator Electrolyte Safety valve Terminal
Raw material Lead dioxide Lead ABS ABS AGM Sulfuric acid Rubber Copper
12V 100ah Rechargeable Sealed Lead Acid Battery For Power And Solar Storage
> Application

1. Solar power system(off-grid solar power system, solar street light system, solar garden light system);

2. Wind Power System;

3. UPS and computer backup power;

4. Telecommunication system;

5. Power station System;

6. Railway System;

7. Emergency lighting system;

8. Alarm system for fire protection, security.

12V 100ah Rechargeable Sealed Lead Acid Battery For Power And Solar Storage
> Constant Current Discharge Characteristics(A,25ºC)
F.V/Time 10min 15min 30min 60min 2h 3h 4h 5h 8h 10h 20h
9.6V 87.2 67.2 40.2 24.7 14.6 10.4 8.4 7.18 4.94 4.07 2.16
9.9V 84.6 65.6 39.4 24.3 14.5 10.3 8.36 7.14 4.91 4.06 2.15
10.2V 81.1 63.2 38.2 23.7 14.4 10.3 8.3 7.09 4.87 4.05 2.13
10.5V 77.6 61 37.3 23.2 14.2 10.2 8.24 7.04 4.84 4.03 2.13
10.8V 73.2 57.8 35.9 22.5 13.8 9.89 7.99 6.83 4.69 4 2.12

> Constant Power Discharge Characteristics(Watt,25ºC)

F.V/Time 10min 15min 30min 60min 2h 3h 4h 5h 8h 10h 20h
9.60V 942 738 451 282 169 122 98.8 84.9 58.6 48.6 25.9
9.90V 914 720 442 278 168 122 98.3 84.4 58.3 48.5 25.8
10.2V 876 694 428 271 167 121 97.6 83.8 57.9 48.4 25.8
10.5V 838 670 418 265 164 120 96.9 83.2 57.5 48.1 25.6
10.8V 791 635 403 257 160 116 94 80.7 55.8 47.8 25.4
> Discharge diagram
12V 100ah Rechargeable Sealed Lead Acid Battery For Power And Solar Storage
12V 100ah Rechargeable Sealed Lead Acid Battery For Power And Solar Storage
> Production process
12V 100ah Rechargeable Sealed Lead Acid Battery For Power And Solar Storage
12V 100ah Rechargeable Sealed Lead Acid Battery For Power And Solar Storage
