5Kw 10Kw 48V 50Ah 100Ah 200Ah Lifepo4 Battery Pack Deep Cycle
5Kw 10Kw 48V 50Ah 100Ah 200Ah Lifepo4 Battery Pack Deep Cycle
Specifications
Brand Name :
FOBERRIA
Model Number :
48V100
Certification :
CE / ISO9001
Place of Origin :
CHINA
MOQ :
10pcs
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
60,000 per month
Delivery Time :
25-30days
Packaging Details :
Cartons with pallet
Name :
Lifepo4 battery cell
Model :
48V100
Type :
Pack
Accept :
Customized
Range :
Lithium battery
Application :
storage system
Description

Deep cycle 48V Solar Inverter Battery 5Kw 10Kw 48V 50Ah 100Ah 200Ah lifepo4 Battery pack

>Manufacturing techniques

1. Top quality battery cell, with brand new A grade prismatic LFP aluminum shell battery cells,high energy density,6000+ long cycle life. Every battery cell was with a Unique QR code, can be traceable.

2. There have a BMS to protect the battery, the BMS can provide the protection functions as Cell balance control, Over-charge protection, Over-discharge protection, Short circuit protection, High/Low temperature protection.

3. Laser welding, the battery pole and the busbar was welded by laser, more reliable and efficient .

4. 100% tested before packing, every battery pack passed the aging test and charge/discharge test, to ensure that all the products we produced accord with the highest quality standards.

>Features

1. Long service life. 6000+ cycle times.More than 10 years lifespan.

2. Composed by lithium iron phosphate cells, the safest li ion material.

3. Intergrated with BMS protection:overcharge, over discharge,temperature protection, short circuit and balance function

4. Easy installation.Wall mounted design.

5. Compatible with many brands inverters (Growatt, Victron, Goodwe etc)

6. Support maximum 16pcs in parallel connection.

7. Can work with off grid system or hybrid system.

8. LCD monitoring screen to show the battery status

9. RS485&RS432 communication ports to connect with PC

>Application area

1. House, hospital, hotel, office space...

2. Solar/wind energy storage system

3. UPS, backup power

4. Telecommunication

>Energy storage battery advantages:

♦High Inverter Compatibility, can be compatible with 90% inverter brand;

♦Max.15pcs Parallel Supported;

♦High energy efficiency: Energy efficiency (charge and discharge)>99%;

♦High Rate Charge & Discharge, 0.5C charge and 1C discharge;

♦Safe and Reliable Smart BMS, take protections against over-charge, over-discharge, over-current, over-temperature, low-temperature, and short circuit, etc;

♦Long Life, reliable A+ grade LFP cells, Cycle life >6000 cycles;

♦More Smart, can supply customized upper computer software for BMS communication to set parameters and read monitoring data;


♦Smart Design & Easy installation:Plug in & off;

♦More Quiet: Without fan,more quiet and reduce the fan failure risk;

♦Superior Safety, Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact overcharging or short circuit situation;

♦Multiple communication protocals: RS485, RS232, CAN;

♦Customized solutions can be acceptable.

>Specification

​
MODEL: ESS-4810
Normal voltage: v-15 s
Capacity: 4.8KWh
Working voltage range: 40.0v-57.6 v
Charging current: 20A
Maximum continuous charging current: 100A
Standard discharge current: 20A
Maximum continuous discharge current: 100A
Protection voltage: 55V
Float voltage: 55.2V
Temperature protection: 65 ° c
Charging temperature: 0 ~ 45 ° c
Working temperature: -20 ~ 60 ° c
Overcurrent fuse: 120A
Cycle life: 6000 times
(80% dod cut-off voltage: about 48v)
Communication: RS232/485/ /CAN
Size: 482 * 420 * 133mm
Weight (kgs): 40kg
>Workshop scene
5Kw 10Kw 48V 50Ah 100Ah 200Ah Lifepo4 Battery Pack Deep Cycle
>FAQ
Q1: How to choose the right battery?

A1: Tell us your demand, then our sales will recommend a suitable battery for you.

Q2. Do you have any MOQ limit?

A2: Yes, we have MOQ for mass production, it depends on the different model numbers. 50-500pcs sample order is available.
for sample checking is available.

Q3. Is it OK to print my logo on the product?

A3: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.


Q4: How to solve the technical problem?

A4: 24 hours after-service consultancy just for you and to make your problem to solve easily.

Q5:. What certificate your company have?

A5: ISO 9001, ISO 14001, OHSAS 18001, CE, UL, IEC 61427 test report, Patent for gel technology and other Chinese honor.
