Wholesale sealed lead acid battery 12v 100ah 10Hr vrla sealed lead acid battery For UPS back up System
Wholesale sealed lead acid battery 12v 100ah 10Hr vrla sealed lead acid battery For UPS back up System
Wholesale sealed lead acid battery 12v 100ah 10Hr vrla sealed lead acid battery For UPS back up System
Wholesale sealed lead acid battery 12v 100ah 10Hr vrla sealed lead acid battery For UPS back up System
Specifications
Brand Name :
FOBERRIA
Model Number :
FBR12-100
Certification :
CE / ISO9001
Place of Origin :
CHINA
MOQ :
50pcs
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
60,000 per month
Delivery Time :
25-30days
Packaging Details :
Cartons with pallet
Name :
Sealed Lead Acid Battery
Model :
FBR12-100
Voltage :
12V
Capacity :
100AH
Weight :
29.5kg
Dimension :
330*171*220mm
Terminal :
F14
Color :
Gray
Feature :
Low Self Discharge
Application :
EPS and UPS battery backup
Electrolyte :
acid battery
Battery Type :
Deep Cycle, Sealed Gel
Rechargeable :
Chargeable
Origin :
Made in China
Description

Wholesale sealed lead acid battery 12v 100ah 10Hr vrla sealed lead acid battery For UPS back up System

> Specification
Battery Model No. FBR12V100Ah
Nominal Voltage 12V
Capacity 20HR(5.25V) 100Ah
(25ºC) 10HR(5.25V) 35Ah
1HR(4.80V) 24.5Ah
Dimension Length 197±2mm
Width 165±2mm
Height 175±2mm
Total height 175±2mm
Approx. Weight 12.5kg±4%
Terminal type F14
Internal resistance Approx 8.5mΩ
(Fully charged,25ºC)
Capacity affected by 40ºC 102%
Temperature(20HR) 25ºC 100%
0ºC 85%
-15ºC 65%
Self-discharge(25ºC) 3month Remaining Capacity:91%
6month Remaining Capacity:82%
12month Remaining Capacity:65%
Nominal operating temperature 25ºC±3ºC(77ºF±5ºF)
Operating Discharge -15ºC-50ºC(5ºF-122ºF)
temperature range Charge -10ºC-50ºC(14ºF-122ºF)
Storage -20ºC-50ºC(-4ºF-122ºF)
Float charging voltage
(25ºC)		 13.5 to 13.8V
Temperature compensation:-18mV/ºC
Cyclic charging voltage
(25ºC)		 14.5 to 15V
Temperature compensation:-30mV/ºC
Max charging current 12A
Max discharging current 400A(5sec.)
Designed floating life(20ºC) 10years
> Main Features

Foberria Battery is a professional Manufacturer of lead-acid batteries. specializes in AGM GEL OPZV/OPZS series storage battery,

The products are mainly used in communications equipment Bank, emergency systems, solar power systems, wind power generation systems,household off-qrid power generation.

The company products through the ISO system, CE, IEC, MSDS and other quality certification, detection of TUV, SGS, and has received three-party, once again proved that FOBERRIA brand is trustworthy.

Our products are exported to Latin America,South America, Africa, Australia, Southeast Asia, dozens of countries around the world and regions, and has been recognized by the majority of customers.we welcome all customers to make inquiries and establish long-term cooperative relations.
> Structure and composition
Component Positive plate Negative plate Container Cover Separator Electrolyte Safety valve Terminal
Raw material Lead dioxide Lead ABS ABS AGM Sulfuric acid Rubber Copper
> Application

1. Solar power system(off-grid solar power system, solar street light system, solar garden light system);

2. Wind Power System;

3. UPS and computer backup power;

4. Telecommunication system;

5. Power station System;

6. Railway System;

7. Emergency lighting system;

8. Alarm system for fire protection, security.

Wholesale sealed lead acid battery 12v 100ah 10Hr vrla sealed lead acid battery For UPS back up System
> Constant Current Discharge Characteristics(A,25ºC)
F.V/Time 10min 15min 30min 60min 2h 3h 4h 5h 8h 10h 20h
9.6V 87.2 67.2 40.2 24.7 14.6 10.4 8.4 7.18 4.94 4.07 2.16
9.9V 84.6 65.6 39.4 24.3 14.5 10.3 8.36 7.14 4.91 4.06 2.15
10.2V 81.1 63.2 38.2 23.7 14.4 10.3 8.3 7.09 4.87 4.05 2.13
10.5V 77.6 61 37.3 23.2 14.2 10.2 8.24 7.04 4.84 4.03 2.13
10.8V 73.2 57.8 35.9 22.5 13.8 9.89 7.99 6.83 4.69 4 2.12

> Constant Power Discharge Characteristics(Watt,25ºC)

F.V/Time 10min 15min 30min 60min 2h 3h 4h 5h 8h 10h 20h
9.60V 942 738 451 282 169 122 98.8 84.9 58.6 48.6 25.9
9.90V 914 720 442 278 168 122 98.3 84.4 58.3 48.5 25.8
10.2V 876 694 428 271 167 121 97.6 83.8 57.9 48.4 25.8
10.5V 838 670 418 265 164 120 96.9 83.2 57.5 48.1 25.6
10.8V 791 635 403 257 160 116 94 80.7 55.8 47.8 25.4
> Discharge diagram
Wholesale sealed lead acid battery 12v 100ah 10Hr vrla sealed lead acid battery For UPS back up System
Wholesale sealed lead acid battery 12v 100ah 10Hr vrla sealed lead acid battery For UPS back up System
> Production process
Wholesale sealed lead acid battery 12v 100ah 10Hr vrla sealed lead acid battery For UPS back up System
