Acrel AKH-0.66-40I Series Split Core Current Transformer Ac Current Transmitter Current Sensor 600/1A
Acrel AKH-0.66-40I Series Split Core Current Transformer Ac Current Transmitter Current Sensor 600/1A
Specifications
Brand Name :
Acrel
Model Number :
AKH-0.66
Certification :
CE
Place of Origin :
China
MOQ :
1pc
Payment Terms :
T/T
Supply Ability :
5000pc/day
Delivery Time :
5-8 work days
Packaging Details :
carton
Input current :
600A
Output current :
1AAKH-0.66 40I current transformer
Description

AKH-0.66 40I current transformer

They are patented and flip designed. The appearance is nice and the wiring is convenient. The transparent polycarbonate material is selected for the flip. We can clearly see the secondary lead wiring. It has square round hole for both cable and bus passing through. As an alternating current signal acquisition element, it is generally matched with measuring instruments and widely used in electrical sets. This product meet the requirements of GB20840.2-2014(Equivalent IEC61869-2:2012,MOD), and have achieved CE certificate.

Spec. and size

Size (mm)

Type		 Outline size Through size Mounting size Tolerance
(mm)
W H D a e Φ M N
30 I 60 78 36 31 11 22 34 57.5 ±1
40 I 75 95 45 40 11 31 40 57.5
60 I 102 130 45 61.5 21 45 42 57.5
80 I 118 140 45 82 11 52 60 57.5

Type selection

Specification Rated current
ratio (A)		 Precision degree and
corresponding rated load
(VA)		 Straight-
through
tums		 Bus
spec(mm)
/number		 Max. cable
outer
diameter
(mm)		 Install
ation
0.2 0.5 1

30I

Acrel AKH-0.66-40I Series Split Core Current Transformer Ac Current Transmitter Current Sensor 600/1A

 15/5(1) 1.5 5 / Ф22 A
20/5(1) 1.5 4
25-30/5(1) 1.5 3
40-60/5(1) 1.5 2
75-100/5(1) 1.5 1 30×10/1 A,B
150-200/5(1) 2.5 1
250/5(1) 3.75 1
300-450/5(1) 5 1
500/5(1) 10 1
600/5 10 1

40I

Acrel AKH-0.66-40I Series Split Core Current Transformer Ac Current Transmitter Current Sensor 600/1A

 10/5(1) 1.5 10 / Ф30 A
15/5(1) 1.5 8
20/5(1) 1.5 5
25-30/5(1) 1.5 4
40/5(1) 1.5 3
50-75/5(1) 1.5 2
100/5(1) 1.5 1 40×10/1 A,C
150/5(1) 2.5 1
200/5(1) 2.5 1
250/5(1) 3.75 1
300-450/5(1) 5 1
500-800/5(1) 10 1
1000/5(1) 10 1
60I 150/5(1) 2.5 1 60×10/1 Ф44 A,C
Acrel AKH-0.66-40I Series Split Core Current Transformer Ac Current Transmitter Current Sensor 600/1A 200-250/5(1) 2.5 1 60×6/1-2
300-450/5(1) 5 1
500-800/5(1) 10 1
1000-1250/5(1) 10 1
1500-2000/5(1) 20 1
2500/5(1) 30 1

80I

Acrel AKH-0.66-40I Series Split Core Current Transformer Ac Current Transmitter Current Sensor 600/1A

 150/5(1) 2.5 1 80×10/1 Ф50 A,C
200-250/5(1) 2.5 1
300-400/5(1) 5 1
500-800/5(1) 10 1
1000-1250/5(1) 10 1
1500-2000/5(1) 20 1
2500-3000/5(1) 30 1

Acrel AKH-0.66-40I Series Split Core Current Transformer Ac Current Transmitter Current Sensor 600/1A

Instllation

Acrel AKH-0.66-40I Series Split Core Current Transformer Ac Current Transmitter Current Sensor 600/1AAcrel AKH-0.66-40I Series Split Core Current Transformer Ac Current Transmitter Current Sensor 600/1AAcrel AKH-0.66-40I Series Split Core Current Transformer Ac Current Transmitter Current Sensor 600/1A
