Three Phase 660V/690V NB-IoT Wireless Kwh Meter Wifi Power Meter
Three Phase 660V/690V NB-IoT Wireless Kwh Meter Wifi Power Meter
Specifications
Brand Name :
Acrel
Model Number :
ADW300
Certification :
CE
Place of Origin :
Jiangsu, China
MOQ :
1 piece
Price :
$73/ piece
Payment Terms :
T/T
Delivery Time :
2-3 work days
Packaging Details :
carton box
Display Type :
Analog and Digital
Phase :
Three Phase
Measuring Energy Range :
0-99999KWH
Accuracy Class :
0.5S
Output Voltage :
380V/400V/660V/690V
Operating Temperature :
-40℃-+70℃
Dimensions :
72
Product name :
Wireless Electricity Meter
Wireless Solution :
NB-IoT/4G/GPRS/Lora/Lorawan
Installation :
35mm Din Rail
Certificate :
CE/IEC
Type :
WIRELESS
Display :
LCD Display
Communication :
RS485 Port MODBUS-RTU Protocol
Frequency :
45-65Hz
Standard :
IEC62053-21
Rated voltage :
AC 230V/400V/690V
Selling Units :
Single item
Single package size  :
10X10X10 cm
Single gross weight :
1.000 kg
Package Type :
carton box
key word :
wifi power meter
Description

Acrel ADW300 iot wireless energy meter/three phase wireless energy meter/wifi power meter

IoT wireless energy meter

ADW300 wireless meter is mainly used to measure three-phase active power in low-voltage network. It has the functions of RS485 communication,2G,4G,NB-IoT and 868MHZ/923MHZ/433MHZ Lora/Lorawan wireless communication. It is convenient for users to monitor, collect and manage electricity. It can be flexibly installed in the distribution box to realize the measurement, statistics and analysis of individual electric energy in different regions and loads.

Specification

Acrel ADW300 iot wireless energy meter/three phase wireless energy meter/wifi power meter



Input voltage

Nominal voltage

3*220/380V,3*380V,3*57.7/100V,3*100V

Consumption

＜10VA or 2W(A phase),＜0.5VA(B phase,C phase)

Frequency

50-60hz



Input current

Maximun current

6A

Starting current

0.002A

Consumption

＜2VA

Accuracy

Class 0.5S

Temperature accuracy

±2℃



Communication

Infrared

RS485(Modbus-RTU)

868MHz/923MHz/433MHz Lora/Lorawan

2G ,4G GPRS communication

NB-IOT communication



Pulse

Width

80±20ms

Constant

6400imp/kWh

Outline

L*W*H(mm)

72*71.5*92.6



Temperature

Operating

-25~55℃

Storing

-40~70℃

Humidity

≤95%(No condensation)

Altitude

＜2000m

Wireless Solution

NB-IoT : H-FDD B1 B3 B8 B5 B20

4G : LTE-FDD B1 B3 B5 B8
LTE-TDD B34 B38 B39 B40 B41
CDMA B1 B5 B8
GSM 900/1800M

2G : GSM 850
EGSM 900
DCS 1800
PCS 1900

LoRa/Lorawan : 433MHz

470MHz

868MHz

915MHz

923MHz

Dimensions
