Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
Acrel
Model Number :
ADL300-EY
MOQ :
1 Piece
Price :
$120.00 / Piece
Display Type :
Analog and Digital
Phase :
Three Phase
Measuring Energy Range :
0-999999.9kWh
Accuracy Class :
Class 0.5S
Output Voltage :
AC 3*220/380V
Operating Temperature :
-25 ~+55℃
Dimensions :
144*88*70mm
Product name :
ADL300-EY Three Phase Prepaid Energy Meter
Display :
LCD Display
Communication :
RS485 Modbus RTU
Frequency :
50/60Hz
Certificate :
CE ISO9001
Installation :
35mm Din Rail
Rated current :
AC 3*220/380V
Power consumption :
<4VA
Operation Temperature :
-25 ~+55℃
Dimension :
144*88*70mm
Selling Units :
Single item
Single package size  :
14.4X8.8X7.0 cm
Single gross weight :
0.800 kg
Package Type :
It is packed in a crash bag and then put into a cardboard box.
Description

HOT SALE Din rail RS485 (Modbus-RTU) Accuracy kWh Class 0.5s Frequency 50/60HZ( ADL300-EY Prepaid Energy Meter

Products Description
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
ADL3000-E Three Phase Multi-Function Energy Meter
● AC 3×220/380V
● 1(6)A,10(80)A
● Prepaid mode
● Alarm for dump energy
● LCD display
● Historical records
● kWh Class 0.5S
● DIN 35 mm
Characteristic
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY

Communication
RS485
(Modbus-RTU)
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY

Display
8 digits LCD display U, I, P, Q, PF, kWh and other energy consumption, Power measure (999999.99kWh)
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY

Rated U and I
3*220/380V
3*10(80)A
3*1(6)A
Technical Parameters
Voltage
Nominal voltage
3*220/380V
Nominal frequency
50/60Hz
Consumption
＜4VA(Each phase)
Current
Maximum current
6A,80A
Starting current
Connect directly:0.04A
Connect via CT:0.002A
Consumption
＜4VA(Maximum current)
Measurement performance
Accuracy of active kWh
Class 0.5S
Clock
Accuracy
Error≤0.5s/d
Active pulse
Width
80+20ms
Constant
400imp/kWh
6400imp/kWh
Communication
Interface
RS485
Protocol
MODBUS-RTU
Outline
L*W*H(mm)
144*88*70
Environment
Temperature
Operating:-25~55℃,Storage:-40~70℃
Humidity
≤95%(No Condensation)
Altitude
≤2000m
LCD Display
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
Function
Accuracy
kWh Class 0.5s
Frequency
50/60HZ(Optional), Range:45~65HZ
Auxiliary power supply(self supply):
220Vac(L-N),range:154~264Vac
Pulse output:
Pulse output kWh
Consumption
<4VA(Each phase)
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
Installation:
DIN 35mm
Dimension(L*W*H):
144*88*70mm
Active pulse:
Constant: 6400imp/kWh,400imp/kWh
Clock:
≤0.5s/d
Starting current:
Connect directly:0.04A,connect via CT:0.002A
Appearance
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
Wiring
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
Product Application
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
Company Profile
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
Jiangsu Anke Ruiwei Grid Research Institute Co., Ltd., the manufacturer base located in Jiangyin, Wuxi City, is a pioneer enterprise integrates the informatization and industrialization of Jiangsu province. It has a multiple function product test center(CNAS certified), which can carry out a variety of tests on environment, electromagnetic compatibility, safety and reliability. The production relies on the advanced information management system and strictly follow the ISO9001 management standard, which provide a guarantee for industrialization and large-scale implementation of the products. The annual capacity of the electrical meter is 2 million sets, 1.5 million power transformers and 10,000 sets of energy-saving cabinets. Acrel Co., Ltd.[stock code: 300286.sz] is a high-tech enterprise integrates R&D, production, sales and service, since its establishment, it committed to provide users with energy efficiency management and power security system solutions. Acrel Electric has a complete production line from cloud platform software to sensors. At present, more than 8,000 sets of various solutions are running all over the country, help users to realize the visual management of energy consumption, provide users the energy data services, and escort users an efficient and safe energy consumption.
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
Jiangsu Anke Ruiwei Grid Research Institute Co., Ltd.
baojingjun@email.acrel.cn
Address:No.5,Dongmeng Road,Nanzha Town,Jiangyin City,Jiangsu Province.
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
After-sales Service
Class 0.5s Din Rail Kwh Meter , 50Hz/60HZ Prepaid Energy Meter ADL300-EY
FAQ

1. Q: Where is your factory located ? How can I visit here ? Can your factory arrange transportation for me?

A: Our production base is located in Jiangyin City, Jiangsu Province, China; Which will take about 2 hours by car from Shanghai to our factory. We can arrange our driver to pick you up from your hotel when you arrive Shanghai.

2. Q: Does your factory have the design and development capabilities, can you factory accept customized products?

A: The staffs in our R&D department are well experienced in the Electric industry, with more than 10 years’ experience. We can make customized products especially for you; please kindly contact us for more

3. Q: How long could I get my order?

A: Stock Products: shipping within 5 days.
B: Customized products: usually 10-15 days. It depends on your design and quantity.

4. Q: How is your production management and quality control system?

A: All our product process follows up ISO9001. The strict implementation of ISO9001 assures to provide error–free products to our customers. We will show you these in our workshop during your visiting.

5. Q: How can I get a sample to check the quality?

A: We are glad to offer you samples for test. Leave us message of the item you want and your city address. We will offer you detail sample packing information, and select the best way to deliver it.
