RS485 Modbus RTU Wireless Energy Meter / Wifi Smart Meter ADW300
RS485 Modbus RTU Wireless Energy Meter / Wifi Smart Meter ADW300
Specifications
Place of Origin :
Jiangsu, China
Brand Name :
Acrel
Model Number :
ADW300
MOQ :
1 Piece
Price :
$100.00/ Piece
Certification :
CE ISO9001
Payment Terms :
T/T
Delivery Time :
2-3 work day
Packaging Details :
It is packed in a crash bag and then put into a cardboard box
Display Type :
Analog and Digital
Phase :
Three Phase
Measuring Energy Range :
0-999999.99 KWh
Accuracy Class :
0.5
Output Voltage :
220V/380V
Operating Temperature :
-25 ~+55℃
Dimensions :
93*72*72mm
Product name :
Three-phase active power in low-voltage network ADW300 Wireless Meter
Display :
LCD Display
Communication :
RS485 Modbus RTU
Frequency :
50~60HZ
Certificate :
CE ISO9001
Accessories :
0.5
Pulse output :
Contant:6400imp/kWh
Power supply :
AC 85~265V
Operation Temperature :
-25 ~+55℃
Dimension :
93*72*72mm
Selling Units :
Single item
Package Type :
It is packed in a crash bag and then put into a cardboard box
Description

ADW300 wireless energy meter

Products Description

ADW300 Wireless Meter

ADW300 wireless meter is mainly used to measure three-phase active power in low-voltage network. It has the functions of RS485 communication and 470MHZ wireless communication. It is convenient for users to monitor, collect and manage electricity. It can be flexibly installed in the distribution box to realize the measurement, statistics and analysis of individual electric energy indifferent regions and loads.

Characteristic

Communication

RS485(Modbus-RTU),Infrared,470MHz wireless transmission,GPRS,NB-IOT

Display

LCD display

Rated U and I

3×220/380V,3×380V,,3×57.7/100V,3×100V,3*1(6)

Function

Accuracy

Active energy: Class 0.5S
Reactive energy: Class 2
Frequency
Range: 50~60HZ
Pulse output
Contant:6400imp/kWh
Consumption
<10VA (Single phase)

Dimension(L*W*H)

72*87.8*71.5mm
Wireless
Transmission on 470MHz and maximum distance in open space is 1km; 2G; NB
Starting current
2‰In

Appearance

Technical Parameters

Input voltage

Nominal voltage

3*220/380V,3*380V,3*57.7/100V,3*100V

Consumption

＜10VA or 2W(A phase),＜0.5VA(B phase,C phase)

Frequency

50-60hz

Input current

Maximun current

6A

Starting current

0.002A

Consumption

＜2VA

Accuracy

Class 0.5S

Temperature accuracy

±2℃

Communication

Infrared

RS485(Modbus-RTU)

470MHz Wireless Transmission

GPRS communication

NB-IOT communication

Pulse

Width

80±20ms

Constant

6400imp/kWh

Outline

L*W*H(mm)

72*71.5*92.6

Temperature

Operating

-25~55℃

Storing

-40~70℃

Humidity

≤95%(No condensation)

Altitude

＜2000m
