Clear 5mm 122X244cm Solid PC Sheet UV Stabilized Polycarbonate Panel
Clear 5mm 122X244cm Solid PC Sheet UV Stabilized Polycarbonate Panel
Clear 5mm 122X244cm Solid PC Sheet UV Stabilized Polycarbonate Panel
Clear 5mm 122X244cm Solid PC Sheet UV Stabilized Polycarbonate Panel
Specifications
Brand Name :
Mason
Model Number :
M-000
Certification :
SGS CE
Place of Origin :
China
MOQ :
50 SHEETS
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
10000KGS PER DAY
Delivery Time :
7-15DAYS
Packaging Details :
Max 1500kgs on one pallet
Product name :
Mason Clear 5mm 122*244cm Solid Pc Sheet Uv Stabilized Polycarbonate Panel
Thickness :
1.8-10mm
Size :
1220*2440mm
Material :
100% virgin material
Color :
transparent
Application :
Advertising signs, light box advertisements, exhibitions, greenhouses, ceilings, etc.
Feature :
Impact resistance，Weather resistance
Light transmittance :
>80%
Description

Mason Clear 5mm 122*244cm Solid Pc Sheet Uv Stabilized Polycarbonate Panel

Clear 5mm 122X244cm Solid PC Sheet UV Stabilized Polycarbonate Panel

PC Sheet Advantage:


1. Light Transmission

The light transimission of the sheet is quite good which is up to 89%.


2. Weather Resistance

The weather resistance treatment of anti-UV on the surface of the sheet precents the resin from turning yellow

by causing Ultraviolet ray. The UV agent has chemical bond to change Ultraviolet ray into visable light, which

has a stable effect on the photsynthesis of plants.


3. Temperature Property
Throught the national GV8625-88 test, its fire retardant is identified to be Grade 1, no fire drops nor toxic gas.

In the temperature from -40C to 120C, the product will not deform.


4. Light Weight
It is light weight,easy to handle and drill,convenient for constrsction and procession,when cutting for installatioin,

it is not easy to be broken.

Clear 5mm 122X244cm Solid PC Sheet UV Stabilized Polycarbonate Panel

Item Unit Index Test Method
Proportion g/cm 1.2 D-792
Impact strength(Izod,Gap) J/M 907 D-256
Tensile yield strength Mpa 69 D-638
Tensile breaking strength Mpa 71 D-638
Yield strength rate % 6.5 D-638
Breaking strength rate % 120 D-638
Compressive strength Mpa 86 D-695
Elastic modulus Mpa 2400 D-638
Coefficient of thermal expansion W/m. 6.7x10 D-696
Guidance coefficient W/m.K 0.2 C-177
Thickness(mm) 2.0 3.0 6.0 8.0 10.0
Transparency 89 88 83 82 80

Product Display

Clear 5mm 122X244cm Solid PC Sheet UV Stabilized Polycarbonate Panel

Excellent thickness accuracy.

The thickness tolerance is much higher than the national standard.

Clear 5mm 122X244cm Solid PC Sheet UV Stabilized Polycarbonate Panel

Few foreign matters.
Special multi-layer filter unit and dust-free plant are used to eliminate the possible incorporation of impurities.

Clear 5mm 122X244cm Solid PC Sheet UV Stabilized Polycarbonate Panel

Stable quality
The entire assembly line operates in the fully closed form meeting the pharmaceutical pure standard and
at a constant temperature to ensure quality stability.

Clear 5mm 122X244cm Solid PC Sheet UV Stabilized Polycarbonate Panel
