Surface Mounted Led Slim Panel Light Square Shape 100lm / W Pmma 6w 12w 18w 24w
Surface Mounted Led Slim Panel Light Square Shape 100lm / W Pmma 6w 12w 18w 24w
Surface Mounted Led Slim Panel Light Square Shape 100lm / W Pmma 6w 12w 18w 24w
Surface Mounted Led Slim Panel Light Square Shape 100lm / W Pmma 6w 12w 18w 24w
Surface Mounted Led Slim Panel Light Square Shape 100lm / W Pmma 6w 12w 18w 24w
Surface Mounted Led Slim Panel Light Square Shape 100lm / W Pmma 6w 12w 18w 24w
Surface Mounted Led Slim Panel Light Square Shape 100lm / W Pmma 6w 12w 18w 24w
Surface Mounted Led Slim Panel Light Square Shape 100lm / W Pmma 6w 12w 18w 24w
Specifications
Brand Name :
ADO
Model Number :
AD-EPS-PAL-6W
Certification :
ROHS CE FCC 3C
Place of Origin :
China(mainland)
MOQ :
One Carton
Price :
Negotiation
Payment Terms :
PayPal, Western Union, T/T, L/C
Delivery Time :
5 - 8 work days
Packaging Details :
100 pieces in one carton
Power :
6W 12W 18W 24W
Installation :
Surface Mounted
LGP :
PMMA
Shape :
Round Square
Color :
White Black
Luminous efficiency :
100LM/W
Description

Surface Mounted Slim LED Panel Light 6W 12W 18W 24W Square 100LM/W PMMA

1. Description:

Slim LED Panel Light big advantage is that using Japan Mitsubishi brand light guide plate, the light guide plate is PMMA material, thickness is 3mm, technology is laser dot, the light is more soft and uniform, there is no dark area at all. Lighting effect is pretty good. And can bring 90% light transmittance, which is very helpful for led slim panel light luminous efficiency. Other supplier use NANO or PS light guide plate, the cost is cheaper, but the light transmittance is not good, and after one years using, the color of light guide plate will become yellow, which is not good for slim led panel light quality. Maybe our products is a little higher cost, but the quality is much better than many suppliers. Only good quality with reasonable price can win the market.

2. Specification:

Model AD-EPS-PAL-12W
Input Voltage AC85-265V
LED Brand Taiwan Epistar
Lumen 960LM ± 50 LM
Color Rendering Index 80RA
Material Aluminum(fixture)+PMMA(LGP)
Beam angle 120°
Operation temperature -20℃~+60℃
Mounting height 1-4 meters
Lighting Distance 2-3meters
Warranty 2 years
IP rank IP20

3. Production Features:

A. The construction of this item is nice, 18mm thickness, it is easy installed, can be used in house, hotel, supermarket, restaurant etc. It totally replaced traditional down light.
B. This products is using SMD2835 chips, lighting is soft and equally/uniform/average. Higher CRI.
C. The Light Guide Plate is using PMMA material, the transmittance is higher than acrylic panel.

4. Advantages:

1. Thick housing, means better heat dissipation, means chip has long lifespan
2. Lifetime more than 50000hrs, providing 3 years warranty.
3. High lumen 80lm per watt ,low light decay.
4. High light transmittance>90% ,more soft light.
5. Saving 80% electricity than ordinary panel lights.

6. Certificates:CE Rosh EMC LVD

5. 6W Packing Information:

Packing Size: 65*20*34cm
Packing Qty: 100pcs
Packing Net Weight:14.3kg
Packing Gross Weight:15.8kg
6. Delivery & Shipping:
1. Samples Delivery Time: 3-5 days
2. Official Order Delivery Time: 16 work days
3. Shipping method: DHL / Fedex / TNT / Air Shipping / Sea Shipping
4. Shipping time: 3-7 days for express/air shipping, one month by sea
7. Quality Control Capacity:

A. QC Team: 8 persons.
B. Integrated QC system is implemented in every aspect of production for 4 times strictly check. Raw materials-during productive process-finished products-after aging before pack( one by one)
C. More than 200square meters aging room for each goods aging 24hours

8. FAQ

Q1. How to procee an order for led light?
A1: Firstly, let us know your requirements or application.
Secondly, We quote according to your requirements or our suggestions.
Thirdly, customer confirms the samples and arrange deposit for official order.
Fourthly, factory arrange the production.

Q2: How to deal with the faulty?
A2: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For
defective batch products, we will repair them and resend them to you or we can discuss the solution

including re-call according to real situation.
