Specifications
Brand Name :
ADO
Model Number :
AD-AG-PAL-12W
Certification :
ROHS CE FCC 3C
Place of Origin :
China(mainland)
MOQ :
One Carton
Price :
Negotiation
Payment Terms :
PayPal, Western Union, T/T, L/C
Delivery Time :
5 - 8 work days
Packaging Details :
20 pieces in one carton
Market :
Europe, USA
Shape :
Round
Power :
12w
Emitting :
Back Lit
Feature :
Anti-Glare
Material :
Aluminum
Color :
3000K
Description

BackLit 12W Anti-Glare LED Panel Light 3000K Aluminum 80Ra 125mm Round

1. BackLit 12w Anti-Glare LED Panel Light introduction:

LED Panel Lght normally have 2 different emitting, one is side lighting, such as the slim led panel light, it is a flexiable led strips around the aluminum inner housing ring.

Another is back lighting, it is our backlit anti-glare led panel light. The led chips is on the aluminum PCB board, without the light guide plate,

by using the light diffuser, the light lumious efficiency is much higher that side lighting.

For example, 12w side lighting led panel light lumen is about 700-800LM, but back lighting led panel light lumen is about 840-960LM. Same power but higher lumen, which can save much energy bill.

2. 12W Technical Data Sheet:

Model AD-AG-PAL-12W Finish White
Input Voltage AC85-265V Beam Angle 120 degree
Power 12W LED Brand Epistar
Dimension(L*D*H) 145mm*145mm LED Driver Isolated IC Constant smart driver
Cutout Size 125*125mm IP Grade IP20
Lumens 960LM Material Aluminum+PC
Luminous Flux 80-90LM/W Shape Round
LED chip SMD2835*60pcs Installation Recessed Mounted
CRI 80Ra Lifespan 50000hours
CCT 6500K 4000K 3000K Certificate CE RoHS
Finish White Warranty 2 Years
Beam Angle 120 degree Market Europe

3. Application:

Our Anti-glare backlit led panel light can be widely used for many different places. There are some application scenarios, they are:

1. Home Lighting: living room could choose 6500k, reading room could choose 4000K, and 3000K for bedroom is nice.

2. Office Lighting: the meeting room and reception room can select 4000K or 6500K, 6500K will be much brighter.

3. Commercial Lighting: such as shop, supermarket, hospital, all these commercial places can choose 6500K.

4. Features:

A. Long life span

B. Green environment

C. Energy Saving

D. High Brightness

E. Easy Installation

F. Top technology

G. High configuration

5. How to choose a right product:

To all customers who want to buy good quality led products, please tell us your quality requirements, then we recommend the suitable product for you from our website, because we have many different types led panel lights, also many other series led lamps, indoor lighting or outdoor lighting. Please feel free to contact us at any time, we will do our best to meet your needs and reply you within 24 hours.

6. Trade Terms:

1. Sample can be delivered in 3 days

2. Private labeling and distributorships are offered.

3. Our own design and product development is without any patent problem.

4. Payment: 30% deposits before production, 70% balance to be paid before deliver

5. You are welcome to visit our lighting showroom and factory.

6. Discount are offer base on quantity.
