LED track light heads 10W Bridgelux LED Chip 97Ra 100LM/W 4-wire 3-phase flicker free Dimmable Black for shop
LED track light heads 10W Bridgelux LED Chip 97Ra 100LM/W 4-wire 3-phase flicker free Dimmable Black for shop
LED track light heads 10W Bridgelux LED Chip 97Ra 100LM/W 4-wire 3-phase flicker free Dimmable Black for shop
LED track light heads 10W Bridgelux LED Chip 97Ra 100LM/W 4-wire 3-phase flicker free Dimmable Black for shop
LED track light heads 10W Bridgelux LED Chip 97Ra 100LM/W 4-wire 3-phase flicker free Dimmable Black for shop
LED track light heads 10W Bridgelux LED Chip 97Ra 100LM/W 4-wire 3-phase flicker free Dimmable Black for shop
Specifications
Brand Name :
ADO
Model Number :
AD-TL-OR-10W
Certification :
ENEC, GS,TUV-CE,RoHS,CB,SAA,C-tick
Place of Origin :
China
MOQ :
100pcs
Price :
USD
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
2000pcs
Delivery Time :
3-7 days
Packaging Details :
including white/brown box, brown carton
CCT :
2700/3000/4000K
Power :
10W 15W 20W 25W 30W 35W
Led driver :
Power gear
Voltage :
AC200-240V
Size :
D62*H140mm
Track adapter :
4-wire 3-phase
Beam Angle :
15/24/38/60°
Dimmable :
DALI, TRIAC, 0/1-10V, BLE, ZigBee,RF
CRI :
CRI80+/90+/97
LED Chip :
Bridgelux COB
Description


LED track light heads 10W Bridgelux LED Chip 97Ra 100LM/W 4-wire 3-phase flicker free Dimmable Black for shop


1. LED track light heads 10W Bridgelux LED Chip 97Ra 100LM/W 4-wire 3-phase Specification:

1. Body materials: ADC12 Die cast aluminum
2. CCT&CRI: 2000K, 2700K, 3000K, 3500K, 4000K, 5000K, 6500K, Ra>80/90/97
3. Optics & Beam angle: Lens and Reflector, 15/24/38/60°
4. Size & Wattage: D62X140mm(10w, 15w), D90x108mm(20w, 25w, 30w), D110x150mm(35w, 40w, 45w)
5. Track adapter: 2/3/4 wire 1 phase, 4/6 wire 3 phase
6. Dimmable solution: DALI, TRIAC, 0/1-10V, BLE, ZigBee,RF
7. Finish color: Matt White, Matt Black, Matt Grey and other customized color
8. Warranty: 5 years from the delivery time Lens version Reflector version
9. Certificates: CE ROHS, SAA


2. LED track light Techinical Data :

LED brandBridgelux COBDriver brandPower gear +OsramHousing materialsDie-casting Aluminum AlloyDriver in track
CCT2700/3000/4000KOutput VoltageDC36VIP RatingIP44Powergear flicker free
CRI80/90/97Current250mAFinish colorWhite / BlackGlobal flicker free
Lamp efficiency90-100lm/W @CRI80 /90/97Input VoltageAC200-240VTHD<15%Lifud flicker free
Beam angle15°/24°/38°/60°PF>0.9DimmableYesOsram flicker free
Track adapter4-wire 3-phaseSystem wattage9.58WWarranty5 yearsPowergear TCI DALI




3. LED track light heads 10W Bridgelux LED Chip 97Ra 100LM/W 4-wire 3-phase Introduction:

This track light is an elegant design. High lumen COB chip and PMMA lens and Aluminum reflflector offffer a uniform
lighting output. Die-casing aluminum lamp body provides excellent heat dissipation.
Lens and reflflector design meet difffferent customer needs, and creates a comfortable visual experience. Multiple
beam angle lens and reflflector optional,Easy installation, recreational for various application.


4. Packing Details:

CodeDimension(mm)Size(mm)Produce
Weight(kg)		Carton
Weight(kg)		Carton
Size(CM)		Qty/
CTN
ABCN.W/PCG.W/PC

N.W/
CTN

G.W/
CTN

AD-TL-OR-10WL140D62L160D62*L1400.450.5513.516.544*37*4230
AD-TL-OR-15W
AD-TL-OR-20WL108D90L160D90*L1080.850.95171954*39*4020
AD-TL-OR-25W
AD-TL-OR-30W
AD-TL-OR-35WL150D110L160D110*L1501.071.1717.1218.7259*43*4016
AD-TL-OR-40W
AD-TL-OR-45W



4. LED track light heads 10W Bridgelux LED Chip 97Ra 100LM/W 4-wire 3-phase Features:

-Lens & reflflector design.
-CRI 80/90/97Ra available.
-Modular lens and reflflector design: 15°/24°/38°/60°
-Flicker free internal driver.
-Dimming way: Non-dim, triac dim, DALI dim.


5. Application:

Applicable for residential lighting in bedroom, living room, corridor etc, also suitable for commercial lighting in office, hotel, restaurant etc.

LED track light heads 10W Bridgelux LED Chip 97Ra 100LM/W 4-wire 3-phase flicker free Dimmable Black for shop

6. Installation Procedure​:

LED track light heads 10W Bridgelux LED Chip 97Ra 100LM/W 4-wire 3-phase flicker free Dimmable Black for shop

7. Dali Driver Installation:

LED track light heads 10W Bridgelux LED Chip 97Ra 100LM/W 4-wire 3-phase flicker free Dimmable Black for shop

8. Track installation:CEILING MOUNTED:

LED track light heads 10W Bridgelux LED Chip 97Ra 100LM/W 4-wire 3-phase flicker free Dimmable Black for shop

9. Mechanical drawing D60*H140mm:

LED track light heads 10W Bridgelux LED Chip 97Ra 100LM/W 4-wire 3-phase flicker free Dimmable Black for shop
11. Pictures:

LED track light heads 10W Bridgelux LED Chip 97Ra 100LM/W 4-wire 3-phase flicker free Dimmable Black for shop
