FTTH GJFJH Fiber Optic Drop Cable Single Mode G657A2 Circle / Round 2 Core
FTTH GJFJH Fiber Optic Drop Cable Single Mode G657A2 Circle / Round 2 Core
FTTH GJFJH Fiber Optic Drop Cable Single Mode G657A2 Circle / Round 2 Core
FTTH GJFJH Fiber Optic Drop Cable Single Mode G657A2 Circle / Round 2 Core
FTTH GJFJH Fiber Optic Drop Cable Single Mode G657A2 Circle / Round 2 Core
FTTH GJFJH Fiber Optic Drop Cable Single Mode G657A2 Circle / Round 2 Core
FTTH GJFJH Fiber Optic Drop Cable Single Mode G657A2 Circle / Round 2 Core
FTTH GJFJH Fiber Optic Drop Cable Single Mode G657A2 Circle / Round 2 Core
FTTH GJFJH Fiber Optic Drop Cable Single Mode G657A2 Circle / Round 2 Core
FTTH GJFJH Fiber Optic Drop Cable Single Mode G657A2 Circle / Round 2 Core
Specifications
Brand Name :
ZXOFC
Model Number :
ZXOFC-GJFJH
Certification :
CE,ISO9001,ROSH
Place of Origin :
ShenZhen,China
MOQ :
2KM
Price :
Negotiable
Payment Terms :
T/T, Western Union,Paypal,Credit card
Supply Ability :
10000KM per month
Delivery Time :
1-2 weeks according to the lengths
Packaging Details :
Plywood drum or Iron wooden drum or Fumigated wooden drum or Cardboard box (mainly for FTTH cable) Optional
Fiber type :
G.657A2
Fiber count :
1,2,4 core optional
Application :
outdoor or indoor FTTH Cable
Length :
Customized
Package :
1KM OR 2KM per Roll
Strength member :
Kevlar
Description

FTTH GJFJH Drop Fiber Optic Cable Single Mode G657A2 Circle/Round 2 Core Fiber Optic Cable

Description


The optical cable laid in the buildings is used in horizontal area and main trunk and is used to connect pigtail or connector, and it's used for gigabit or ten-gigabit optical fiber communication.

Product Features:
1. Peripheral strengthening of high modulus aramid yarn
2. Use single core cable as basic unit
3. Small out diameter, terminal direct physical protection is provided
4. Soft, small bending radius and good stress and strain performance
5. Flame retardant or non combustible outside protection can be chosen and LSZH sheath can be provided

Application Standard
ISO/IEC11801 : 2008,YD/T1258-2005

Optical Properties

Attenuation(dB/km) 1310≤0.36, 1550≤0.22
Fiber Type B1.3(9/125um)



Physical Properties

Product model GJFJH GJFBH GJPFH
Dynamic / Static bending radius 20D/10D 20D/10D 20D/10D
Allowable Short/Long term crush resistance
(N/100mm)		 100/500 100/500 100/500
Allowable Short/Long term drawing force
of optical cable (N) 		60/100 100/200 100/200
Number of core Single/double core Double core two-twenty four cores
Jacket color Yellow
Suitable temperature -20°C~60°C

FTTH GJFJH Fiber Optic Drop Cable Single Mode G657A2 Circle / Round 2 Core

FTTH GJFJH Fiber Optic Drop Cable Single Mode G657A2 Circle / Round 2 CoreFTTH GJFJH Fiber Optic Drop Cable Single Mode G657A2 Circle / Round 2 Core
