GYFTY ADSS Single Mode Armored Fiber Cable 72 96 144 Core Customized Color
GYFTY ADSS Single Mode Armored Fiber Cable 72 96 144 Core Customized Color
GYFTY ADSS Single Mode Armored Fiber Cable 72 96 144 Core Customized Color
GYFTY ADSS Single Mode Armored Fiber Cable 72 96 144 Core Customized Color
GYFTY ADSS Single Mode Armored Fiber Cable 72 96 144 Core Customized Color
GYFTY ADSS Single Mode Armored Fiber Cable 72 96 144 Core Customized Color
GYFTY ADSS Single Mode Armored Fiber Cable 72 96 144 Core Customized Color
GYFTY ADSS Single Mode Armored Fiber Cable 72 96 144 Core Customized Color
Specifications
Brand Name :
ZXOFC
Model Number :
GJSFJV
Certification :
CE,ISO9001,ROSH
Place of Origin :
ShenZhen,China
MOQ :
10KM
Price :
Negotiable
Payment Terms :
T/T, Western Union,Paypal,Credit card
Supply Ability :
10000KM per month
Delivery Time :
1-2 weeks according to the lengths
Packaging Details :
Plywood drum or Iron wooden drum or Fumigated wooden drum or Cardboard box (mainly for FTTH cable) Optional
Usage :
Patchcords/MTP/MPO
Color :
Black or Customized
Package :
2km/roll,3km/roll or Customized
Tight Buffer Type :
0.6/0.9mm PVC/LSZH tight buffer
Fiber type :
G652D,G657A,OM1,OM2,OM3,OM4
Outer sheath :
PVC,LSZH.
Fiber count :
2 core
Description

ADSS GYTS GYXTW Armoured Single Mode Fiber Optic Cable 6 8 12 24 36 48 72 96 144 Core

Description

GYTA single-armored cables feature stranded loose tube filled with a water-resistant filling compound. A steel wire, sometimes sheathed with

polyethylene (PE) for cable with high fiber count, locates in the center of core as a metallic strength member. Tubes (and fillers) are stranded

around the strength member into a compact and circular cable core. An Aluminum Polyethylene Laminate (APL) is applied around the cable core,

which is filled with the filling compound to protect it from water ingress. Then, the cable is completed with a PE sheath. It‘s suitable for installation

for long haul communication and LANs, especially suitable for the situation of high requirements of moisture resistance.

Features

0.6/0.9mm tight buffer fiber

Multi fiber armored optical fiber cable has a layer of stainless steel wires enhance the crush resistance of the cable and anti-rodent

High strength aramid yarn,high performance outer sheath

Light weight,flexibility,and friendly installation.

Good mechanical and environmental performance.

Flame retardant outer sheath provide good safety.

Cable complies with Standard YD/T 769-2003

Storage/Operating Temperature: -40°C to + 70°C

Application

Adopted to Outdoor distribution.
Adopted to trunk power transmission system.
Access network and local network in high electromagnetic interfering places.

Optical Characteristics:

G.652D 50/125μm 62.5/125μm
Attenuation (+20℃) @850nm ≤3.0 dB/km ≤3.0 dB/km
@1300nm ≤1.0 dB/km ≤1.0 dB/km
@1310nm ≤0.36 dB/km
@1550nm ≤0.22 dB/km
Bandwidth (Class A) @850nm ≥500 MHz·km ≥200 MHz·km
@1300nm ≥1000 MHz·km ≥600 MHz·km
Numerical Aperture 0.200±0.015NA 0.275±0.015NA
Cable Cut-off Wavelength λcc ≤1260nm

Specifications

Number of fiber 2~144core
Moisture Barrier Water blocking system
Central strength member Material Steel wire/FRP/FRP with PE cover
size 1.5mm~2.0mm
Loose tube material PBT
diameter 2.2(outer/inner)
Tube-filling Tube filling compoun
Armoring Material Corrugated steel tape
Outer sheath material PE,HDPE
diameter 1.70±0.2mm
core Cable diameter weight
2 cores to 60 cores 10.0±0.3mm 115±5kg/km
72 cores 10.5±0.3mm 120±5kg/km
96 cores 12.5±0.3mm 180±5kg/km
144 cores 14.5±0.3mm 245±5kg/km
Min Bending Radius(mm) Long term 10D
Min Bending
Radius(mm)		 Short term 20D
Min allowable
Tensile Strength(N)		 Long term 600
Min allowable
Tensile Strength(N)		 Short term 1500
Crush Load (N/100mm) Long term 300
Crush Load (N/100mm) short term 1000
Operation
temperature (℃)		 -40+70
Installation
temperature(℃)		 -20+60

Packaging Details:

1-2KM per roll. Packed by wooden drum. Other packing available according to client`s Request.

GYFTY ADSS Single Mode Armored Fiber Cable 72 96 144 Core Customized Color

Sheath mark:
The following printing(white hot foil indentation)is applied at 1meter intervals.

a. Supplier: ZXOFC or as customer required;
b. Standard Code(Product Type, Fiber Type,Fiber Count);
c. Year of manufacture: 14 years;
d. Length marking in meters.

Port:

Hongkong/Shenzhen

Lead Time:
Quantity(KM) 1-300 ≥300
Est.Time(Days) 15 To be Negotiated!
Note

The Packing standard and details as above is estimated and final size&weight shall be confirmed before shipment.

GYFTY ADSS Single Mode Armored Fiber Cable 72 96 144 Core Customized Color

The cables are packed in carton, coiled on Bakelite & wooden drum. During transportation, right tools should be used to avoid damaging the package and to handle with ease. Cables should be protected from moisture, kept away from high temperature and fire sparks, protected from over bending and crushing, protected from mechanical stress and damage.
