Submarine Fiber Optic Cables Under The Ocean Depth 5000 Install 72 96 144 Core
Submarine Fiber Optic Cables Under The Ocean Depth 5000 Install 72 96 144 Core
Submarine Fiber Optic Cables Under The Ocean Depth 5000 Install 72 96 144 Core
Submarine Fiber Optic Cables Under The Ocean Depth 5000 Install 72 96 144 Core
Submarine Fiber Optic Cables Under The Ocean Depth 5000 Install 72 96 144 Core
Submarine Fiber Optic Cables Under The Ocean Depth 5000 Install 72 96 144 Core
Specifications
Brand Name :
ZXOFC
Model Number :
ZXOFC-GHLW-24B1.3
Certification :
CE/ROHS/ISO9001
Place of Origin :
ShenZhen,China
MOQ :
3000 meters
Price :
Negotiable
Payment Terms :
T/T, Western Union,Paypal,Credit card
Supply Ability :
10000KM per month
Delivery Time :
1-2 weeks according to the lengths
Packaging Details :
Plywood drum or Iron wooden drum or Fumigated wooden drum or Cardboard box (mainly for FTTH cable) Optional
Fiber type :
Singlemode,Multimode,om1,om2,om3
Armored :
Steel tape armored
Model number :
GHLW-24B1.3
Fiber count :
2-24 core
Optical fiber :
Corning or YOFC
Outer Sheath material :
PE,HDPE,MDPE
Application :
Aerial,direct buried,duct
Description

GYFXTZY33 Uni-tube Non-metallic Steel Wire Armored underwater/Submarine Fiber Optic Cable

Description

A submarine communications cable is a cable laid on the sea bed between land-based stations to carrytelecommunication signals across

stretches of ocean and sea.

The offered cable is qualified for undersea application down to 5000m ocean depth for burial or surface laid.

This Light Weight cable can be spliced using flexible joint closure or Universal Quick Join .

Feature

Fully waterblocked cable

– All wires interstices are filled with bitumen

Stainless Steel Loose Tube

– Stainless steel central loose tube with thixotropic gel filling as fiber protection

High Density Polyethylene (HDPE)

– Black UV resistant High Density Polyethylene (HDPE) as inner protection

Galvanized Steel Wire Armour

– Provides mechanical protection, the cable can withstand higher stress

– Galvanized steel wire armoured 12 x Ø1.7 mm for inner armouring over the stainless steel central loose tube

– Other armour size and quantity are available upon on request

High Density Polyethylene (HDPE)

– Black UV resistant High Density Polyethylene (HDPE) as outer protection

Cable Cross-section Diagram

Submarine Fiber Optic Cables Under The Ocean Depth 5000 Install 72 96 144 Core

Technique Parameters

Reference Standard ITU-T G.652.D ITU-T G.654.B ITU-T G.654.C
Type Single Mode Cut-Off Shifted Single Mode Cut-Off Shifted Single Mode
Wavelength (nm) 1310 / 1550 1550 1550
Attenuation on Finished Cables (dB/km) 0.35 / 0.20 0.180 0.180
Typical Attenuation (dB/km) 0.35 / 0.19 0.175 0.175
Mode Field Diameter (µm) 9.2 ± 0.4 at 1310 nm 11.4 – 12.4 at 1550 nm 9.4 – 10.4 at 1550 nm
ITEM SPECIFICATION
Fiber Quantity 24
Cable Dimension Cable Diameter (Nominal) 12.8 mm
Cable Weight in the Air (Nominal) 350 kg/km
Cable Weight in the seawater (Nominal) 277 kg/km
Specific Gravity Specific gravity in the air 2.71 g/cm3
Specific gravity in the sea water 2.15 g/cm3

Noted: Other Fiber Type and Fiber Quantity are available upon request.

MECHANICAL CHARACTERISTICS :

ITEM SPECIFICATION
Cable Breaking Load (CBL) 50 kN (minimum)
Nominal Transient Tensile Strength (NTTS) 30 kN
Nominal Operation Tensile Strength (NOTS) 20 kN
Nominal Permanent Tensile Strength (NPTS) 10 kN
Minimum Bending Radius with load (MBR) 800 mm
Minimum Bending Radius without load 600 mm
Operating temperature -10˚C up to +50˚C
Storage temperature -30˚C up to +70˚C
Water depth application 5000 m (maximum)
Hydro dynamic constant 0.7 m/s


Note:
1. Only a part of Tactical Fiber Optic Cables are listed in the table. Cables with other specifications can be inquired.
2. Cables can be supplied with a range of single mode or multimode fibers.
3. Specially designed Cable structure is available on request.


Temperature Rage:

Operating :-20℃ to 60℃

Storage :-20℃ to 60℃

Standards:

The offered fiber optic cable complies to the ITU-T G.976, G.978, ITU-T G.652.D, ITU-T G.654.B, ITU-T G.654.C, IEC 60794, TIA/ EIA standards.


Certificate

Submarine Fiber Optic Cables Under The Ocean Depth 5000 Install 72 96 144 Core

Our services
Submarine Fiber Optic Cables Under The Ocean Depth 5000 Install 72 96 144 Core
Our Certificate
Package and delivery
Submarine Fiber Optic Cables Under The Ocean Depth 5000 Install 72 96 144 Core
Submarine Fiber Optic Cables Under The Ocean Depth 5000 Install 72 96 144 Core
Package:
Standard Wooden Drum With Protection.
Standard reel length:2/3/4/5km/reel,other length is also available
Shipping
For the large order , we usually ship the cable by sea .
For small order , we can ship them by sea (LCL) or by air /by exress
(DHL,UPS,FEDE or TNT..) as your request .

1. Are you the real factory?

Yes,we are the real factory with 20 years’ history.

2. What is your fiber brand?

Fiber brands including :ZXOFC

3. What is your main products?

Outdoor fiber optic cables; indoor fiber optic cables;FTTH Drop cables; ADSS;

Indoor armored patch cords fiber cable; Optical patch cords SC/LC/FC/ST; MTP/MPO optical patch cord.

4. Product quality guarantee period?

25 years’ Guarantee for fiber optic cable

5. Do you have certificate for raw material?

We build long-term relationship cooperation with qualified ISO9001, ROHS raw material suppliers.

6. What is your delivery time?

Within 24 hours for 30KM normal kinds of fiber optic cable;

1 ~2 days for fiber optic patch cords with 10000 connectors.

7. MOQ: what is your minimum quantity?

MOQ for fiber optic cables: 1KM

There is no MOQ required for fiber optic patch cords,as there’s stock for normal kinds.

8. Do you have distributor in other country or domestic?

Until now, we sell our products to customers directly. And factory price could be offered.

9. Payment

For large orders: T/T by advanced deposit

For small orders: T/T,Western Union and Paypal are acceptable.

10. Shipping & Delivery

For large orders: by sea (LCL or FCL)

For small orders: by sea (LCL), by air or by courier services,any of which is optional.
