Specifications
Place of Origin :
Guangdong, China
Model Number :
P15.6 mesh led screen
Brand Name :
GCL
Packaging Details :
plywood,flight case,paper board
Supply Ability :
2000 Square Meter/Square Meters per Month
Price :
Price to be discussed
MOQ :
Min. order: 20
Certification :
EMC/CE/ROHS/CCC/FCC/BIS
Application :
Outdoor
Type :
LED
Color :
Black, Silver, White
Panel Size :
500*1000mm
LED chip :
DIP346
Module size :
250*500mm
Brightness :
8500nits
Refresh rate :
1920Hz-3840Hz
Life span :
10000hours
Viewing angle :
120/120 Degree
Warranty :
3 Years
Material :
waterproof diecasting cabinet
IP rate :
IP65/IP65
Voltage :
110-240V/50-60HZ
Pixel Pitch :
15.6
Port :
Yantian(Shenzhen) Shekou(Shenzhen)
Description

IP65/IP65 Silver P10 P15.6 Transparent Flexible Curtain Digital Signage and Displays

Gmesh Product Introduction:

High Light Transmittance


Light transmittance:20%-60%
Low wind resistance
Great heat dissipation

Light and Slim


Cabinet weight: 9.5kg(P10 SND)
11kg(P15.6 DIP)
Cabinet Thickness:45mm

Front &Rear Maintenance


All parts be dismounted from the front;
Both front and rear maintenance;

Easy Maintenance


Loose 8 screws to dismount each module
Loose 8 screws to dismount the front cover,
then dismount the power supply, receiving card and HUB card


Seamless 90°Splicing

Optional Curve Lock
Concave and convex curve;
Curve degree:-15° to+15°

Integrated Power and Signal Cable
Save 50% of the cable connecting time

Parameters of Gmesh Series:

Product P10 P16-A P16-B P16-C P25 P31.25
Pitch 10.4mm 15.625mm 15.625mm 15.625-31.25mm 25-31.25mm 31.25mm
Density(pixels/m²) 9216 4096 4096 2048 1280 1024
LED Type SMD2727 SMD3535 DIP346 DIP346 DIP346 DIP346
Brightness 5500nits 6000nits 10000nits 10000nits 10000nits 10000nits
Scan Method 1/3 Static Static Static Static Static
Panel Size 500×1000mm
Module Size 250×500mm
Panel Material Die-casting Aluminum
Panel Weight 9kg 9kg 10.5kg 10.5kg 10.5kg 10.5kg
Protection Level IP65
Maintenance Front&Rear Service
Max Power Consumption 680W/㎡ 680W/㎡ 350W/㎡ 350W/㎡ 350W/㎡ 350W/㎡
Average Power Consumption 220W/㎡ 220W/㎡ 110W/㎡ 110W/㎡ 110W/㎡ 110W/㎡
Refresh Rate 3840Hz
Grey Scale 16bit
Viewing Angle H140°,V120° H140°,V120° H100°,V50° H100°,V50° H100°,V50° H100°,V50°
Voltage AC100~240V(50-60Hz)
