Specifications
Brand Name :
GCL
Model Number :
Gpro P2.5/P3.07/P4/P5.92/P8/P10(DIP)/P16（DIP)
Certification :
EMC/CE/ROHS/CCC/FCC/BIS
Place of Origin :
China
MOQ :
Min. order: 20
Payment Terms :
L/C, T/T
Supply Ability :
2000 Square Meter/Square Meters per Month
Delivery Time :
15-22Days
Packaging Details :
Single package size:120X980X50 cm
Price :
Price to be discussed
Description

Double Waterproof Design
both cabinet and module are waterproof

Waterproof Outdoor Advertising LED Display Customizable P16 LED Display Fixed Installation
Convenient Maintenance
100%Front Maintenance
Rear Maintenance

Waterproof Outdoor Advertising LED Display Customizable P16 LED Display Fixed Installation
47% Lighter
18kg/cabinet
Traditional cabinet :45-55kg/㎡

Waterproof Outdoor Advertising LED Display Customizable P16 LED Display Fixed Installation
High-end Design
Diecasting Aluminum Cabinet
High-end Module
Fan-less,Noiseless

Waterproof Outdoor Advertising LED Display Customizable P16 LED Display Fixed Installation
IP65
Born For All Weathers

Waterproof Outdoor Advertising LED Display Customizable P16 LED Display Fixed Installation
Energy-saying
SMD: Save 30%；DIP: Save 50%
Waterproof Outdoor Advertising LED Display Customizable P16 LED Display Fixed Installation
Right angle&arc stitching
Supports straight edge splicing, arc splicing, and 90 ° right angle splicing

Modular design, ultra strong protection

Waterproof Outdoor Advertising LED Display Customizable P16 LED Display Fixed Installation

Product P5.9 P8 P10 P10D P16
Pitch 5.92mm 8mm 10mm 10mm 16mm
Density(pixels/m²) 28476 15625 10000 10000 3906
LED Type SMD2727 SMD2727 SMD2727 DIP346 DIP346
Brightness 7000nits 7000nits 7000nits 8000nits 8000nits
Scan Method 1/6 1/4 1/2 1/4 静态
Panel Size 640×960mm
Module Size 320×320mm
Panel Material Die-casting Aluminum
Panel Weight 19Kg 19Kg 19Kg 21Kg 21Kg
Protection Level IP65
Maintenance Front/Rear Service
Max Power Consumption 720W/㎡ 720W/㎡ 720W/㎡ 350W/㎡ 350W/㎡
Average Power Consumption 240W/㎡ 240W/㎡ 240W/㎡ 110W/㎡ 110W/㎡
Refresh Rate 3840Hz
Grey Scale 13-16bit
Viewing Angle H160°,V140° H100°,V50°
Voltage AC100~240V(50-60Hz)
Working Temperature -30℃ to 60℃
Working Humidity 10%-90%RH
Color Temperature 3000-9500K
Certifications CE/ROHS/EMC/TUV/UL/CCC/FCC/ISO
