MDF Soundproof Wood Operable Partition Wall System For Conference Center
MDF Soundproof Wood Operable Partition Wall System For Conference Center
MDF Soundproof Wood Operable Partition Wall System For Conference Center
MDF Soundproof Wood Operable Partition Wall System For Conference Center
Specifications
Brand Name :
AE
Model Number :
AE100
Certification :
ISO9001 SGS
Place of Origin :
Guangdong, China
MOQ :
10 Square Meter
Price :
USD 80-108 Per Square Meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 SQUARE METER PER MONTH
Delivery Time :
20-30days for 10-100㎡, if more than 100㎡need to be negotiated
Packaging Details :
foam layer and hard cardboard with plywood case or steel pallet
Product Name :
Acoustic Partition Walls,soundproof Partition Walls
Material :
Commercial Building And Residential House
Finishing option :
Customer-supplied Materials
Height :
Up to18M
Design :
OEM & ODM
Sound Insulation :
Max 56dB
Description
MDF Soundproof Wood Operable Partition Wall System For Conference Center


Introducing our MDF Soundproof Wood Operable Partition Wall System, ideal for conference centers seeking flexibility and acoustic privacy. This system combines elegant wood finishes with advanced soundproofing technology to ensure uninterrupted meetings and events. Easily adjustable, it offers seamless integration with any space, allowing for quick reconfiguration between rooms. The durable MDF construction provides both aesthetic appeal and long-lasting performance. Elevate your conference center's functionality and style with a partition wall system that balances sophistication with practicality. Discover how our solution can transform your space today.


Our Advantages:

1.Superior Soundproofing: Our partition wall system utilizes interlocking trapezoidal aluminum profiles to create a robust soundproof barrier between panels, ensuring privacy and quiet in any space.

2.Secure Magnetic Connection: Integrated magnetic strips provide a firm and reliable friction connection between panels, preventing gaps and enhancing acoustic performance.

3.Flexible Panel Adjustment: Panels can be easily adjusted after installation to achieve perfect alignment and adaptability, accommodating various room configurations.

4.Durable Track System: Featuring a track system crafted from extruded aluminum and heavy-duty ball bearing steel rollers, our partition wall ensures smooth, maintenance-free operation and long-lasting durability.


Roller Option & Feature


1. Dupont POM roller

2. 304 stainless steel heavy duty roller with safety device & CNC machining

3. Unique and patented wheel surface and shape make the whole movable partition easy to use

Panel Option & Feature


1. Thickness: 68mm & 89mm & 105mm

2. Wide variety of acoustical and decorative finishes available

3. 6061-T6 profile and inside Q235 steel frame for superior durability

4 Top & bottom jack lifting mechanism seal are with power of 800N. Magnetic seal in concave & convex profile has magnetic attraction of 40N/m.

SPECIFICATION:

GEMMAN PARTITION TECHNOLOGY GLOBAL PROFESSONAL SPACE SOLUTIONS
　 Dimensions in mm* Design
Series Element thickness Element width* (min./max.) Clear height* (min./max.) Framed construction Panel fixing Element interconnection/design of
the vertical profiles
AE65 68 600/1,250 2,000/4,500 Aluminium-steel Freely oscillating Aluminium profile
with magnetic strip
and sealing lips
AE85 89 600/1,250 2,000/5,500 Aluminium-steel Freely oscillating Aluminium profile
with magnetic strip
and sealing lips
AE100 105 600/1,250 2,000/18,000 Aluminium-steel Freely oscillating Aluminium profile
with magnetic strip
and sealing lips
Technology:
Weighted sound reduction value determined per GB/T19889.3-2005 in Rw (dB):52/56
Positive and frictional locking of the vertical element connections: Convex-concave profile form, force of attraction of the magnetic strip 40 N/m
* Larger widths possible on application. Provisional details regarding the element heights/element
widths indicated can only be confirmed following consultation with the Design Department.
** Depending on the sound insulation/weight
