OEM ODM Acoustic Sliding Wall Movable Banquet Partition Walls With Fire Resistance Panel
OEM ODM Acoustic Sliding Wall Movable Banquet Partition Walls With Fire Resistance Panel
OEM ODM Acoustic Sliding Wall Movable Banquet Partition Walls With Fire Resistance Panel
OEM ODM Acoustic Sliding Wall Movable Banquet Partition Walls With Fire Resistance Panel
Specifications
Brand Name :
AE
Model Number :
AE85
Certification :
ISO9001 SGS
Place of Origin :
Guangdong, CHINA
MOQ :
10 Square Meter
Price :
USD 70-98Per Square Meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 SQUARE METER PER MONTH
Delivery Time :
20-30days for 10-100㎡, if more than 100㎡need to be negotiated
Packaging Details :
Foam layer and hard cardboard with plywood case or steel pallet
Model :
Acoustic Sliding Wall
Compliance :
School, Hospital, Hotel, Laboratory
Finishing option :
68mm High pressure laminate board
Dimensions :
Customization (Height: up to 4.5M, Width per Panel: up to 1.2M)
Design :
OEM & ODM
STC Rating :
42-56dB
Description

Acoustic Sliding Walls Banquet Hall Movable Partition with Fire Resistance Panel

AE Partition is your trusted global partner for intelligent room management solutions. We specialize in the expert planning, design, and installation of durable movable partition wall systems. Our commitment extends beyond installation, offering high-value services that maintain the performance and longevity of our partitions, adapting to the changing demands of your space.

One of the key features of this operable partition is its ease of use. No special apparatus or tools are required to operate the partition—only a simple operating handle is needed. This handle is used to engage the top and bottom mechanical seals, which are essential for acoustically sealing off the panels. This straightforward process ensures that the partition provides effective sound insulation when in place.

Advantages:

With a focus on fast response times and flexibility in handling construction-related challenges, we ensure seamless project execution. Our advanced technology products are designed to meet the highest standards, making us your reliable partner for innovative space management solutions."

Roller Option & Feature

1. Dupont POM roller

2. 304 stainless steel heavy duty roller with safety device & CNC machining

3. Unique and patented wheel surface and shape make the whole movable partition easy to use

Panel Option & Feature

1. Thickness: 68mm & 89mm & 105mm

2. Wide variety of acoustical and decorative finishes available

3. 6061-T6 profile and inside Q235 steel frame for superior durability

4 Top & bottom jack lifting mechanism seal are with power of 800N. Magnetic seal in concave & convex profile has magnetic attraction of 40N/m.

SPECIFICATION:

GEMMAN PARTITION TECHNOLOGY GLOBAL PROFESSONAL SPACE SOLUTIONS
　 Dimensions in mm* Design
Series Element thickness Element width* (min./max.) Clear height* (min./max.) Framed construction Panel fixing Element interconnection/design of
the vertical profiles
AE65 68 600/1,250 2,000/4,500 Aluminium-steel Freely oscillating Aluminium profile
with magnetic strip
and sealing lips
AE85 89 600/1,250 2,000/5,500 Aluminium-steel Freely oscillating Aluminium profile
with magnetic strip
and sealing lips
AE100 105 600/1,250 2,000/18,000 Aluminium-steel Freely oscillating Aluminium profile
with magnetic strip
and sealing lips
Technology:
Weighted sound reduction value determined per GB/T19889.3-2005 in Rw (dB):52/56
Positive and frictional locking of the vertical element connections: Convex-concave profile form, force of attraction of the magnetic strip 40 N/m
* Larger widths possible on application. Provisional details regarding the element heights/element
widths indicated can only be confirmed following consultation with the Design Department.
** Depending on the sound insulation/weight

PROJECT:

OEM ODM Acoustic Sliding Wall Movable Banquet Partition Walls With Fire Resistance Panel

OEM ODM Acoustic Sliding Wall Movable Banquet Partition Walls With Fire Resistance Panel

ABOUT US:

OEM ODM Acoustic Sliding Wall Movable Banquet Partition Walls With Fire Resistance Panel

OEM ODM Acoustic Sliding Wall Movable Banquet Partition Walls With Fire Resistance Panel

OEM ODM Acoustic Sliding Wall Movable Banquet Partition Walls With Fire Resistance Panel
