Thickness 68mm 89mm 105mm Acoustic Partition Wall For Hall / Hotel Spaces
Thickness 68mm 89mm 105mm Acoustic Partition Wall For Hall / Hotel Spaces
Thickness 68mm 89mm 105mm Acoustic Partition Wall For Hall / Hotel Spaces
Thickness 68mm 89mm 105mm Acoustic Partition Wall For Hall / Hotel Spaces
Specifications
Brand Name :
AE
Model Number :
AE100
Certification :
ISO9001 SGS
Place of Origin :
Guangdong, China
MOQ :
10 Square Meter
Price :
USD90-135Per Square Meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 SQUARE METER PER MONTH
Delivery Time :
20-30days for 10-100㎡, if more than 100㎡need to be negotiated
Packaging Details :
foam layer and hard cardboard with plywood case or steel pallet
Model :
Acoustic Partition Wall
Compliance :
Banquet Hall , Conference Room
Base board :
Customer-supplied Materials
Dimensions :
Customization (Height: up to 18M, Width per Panel: up to 1.2M)
Design :
OEM & ODM
Sound Insulation :
Max 56dB
Description

Expertly Designed Movable Acoustic Partition Wall For Hall and Hotel Spaces

Professionally Crafted Acoustic Movable Partition Walls for Hall and Hotel Spaces. Our solutions combine elegant design with superior sound insulation, creating versatile and private environments tailored to your needs.

With its focus on manual operability, this partition system is both practical and efficient. The panels can be quickly adjusted to create different space configurations, without the need for complex tools or machinery. The use of a simple operating handle to manage the top and bottom seals highlights the system’s emphasis on ease of use, ensuring that spaces can be effectively partitioned while maintaining excellent acoustic sealing.

Advantages:

1) Comprehensive OEM & ODM services tailored to your specific needs.

2) Experience in doing project with heavy customers

3) Product specifications and value-engineered alternatives

4) Provide submittal drawings

5) German Partition Technology Global Professional Space Solutions

6) Highly competitive prices

7) Fast response and flexibility to construction related issues

8) state-of-art technology products

Roller Option & Feature

1. Dupont POM roller

2. 304 stainless steel heavy duty roller with safety device & CNC machining

3. Unique and patented wheel surface and shape make the whole movable partition easy to use

Panel Option & Feature

1. Thickness: 68mm & 89mm & 105mm

2. Wide variety of acoustical and decorative finishes available

3. 6061-T6 profile and inside Q235 steel frame for superior durability

4 Top & bottom jack lifting mechanism seal are with power of 800N. Magnetic seal in concave & convex profile has magnetic attraction of 40N/m.

SPECIFICATION:

GEMMAN PARTITION TECHNOLOGY GLOBAL PROFESSONAL SPACE SOLUTIONS
　 Dimensions in mm* Design
Series Element thickness Element width* (min./max.) Clear height* (min./max.) Framed construction Panel fixing Element interconnection/design of
the vertical profiles
AE65 68 600/1,250 2,000/4,500 Aluminium-steel Freely oscillating Aluminium profile
with magnetic strip
and sealing lips
AE85 89 600/1,250 2,000/5,500 Aluminium-steel Freely oscillating Aluminium profile
with magnetic strip
and sealing lips
AE100 105 600/1,250 2,000/18,000 Aluminium-steel Freely oscillating Aluminium profile
with magnetic strip
and sealing lips
Technology:
Weighted sound reduction value determined per GB/T19889.3-2005 in Rw (dB):52/56
Positive and frictional locking of the vertical element connections: Convex-concave profile form, force of attraction of the magnetic strip 40 N/m
* Larger widths possible on application. Provisional details regarding the element heights/element
widths indicated can only be confirmed following consultation with the Design Department.
** Depending on the sound insulation/weight
