Specifications
Brand Name :
AE
Model Number :
AE100
Certification :
ISO9001 SGS
Place of Origin :
Guangdong, China
MOQ :
10 Square Meter
Price :
USD 80-108 Per Square Meter
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 SQUARE METER PER MONTH
Delivery Time :
20-30days for 10-100㎡, if more than 100㎡need to be negotiated
Packaging Details :
foam layer and hard cardboard with plywood case or steel pallet
Name :
Sound Insulation Partition Wall
Sound Insulation :
Max 56dB
Feature :
Sound Insulation
Finish :
Melamine
Finishing option :
Customer-supplied Materials
Height :
Up to18M
Design :
OEM & ODM
Description

Operable Sliding Acoustic Partition Wall For Classroom 105mm Thickness

AE Acoustic Partition Walls are ideal for projects where precise space delineation is crucial. Their flexibility and cost-effectiveness make them perfect for subdividing large rooms, enhancing space utilization. Common applications include office environments, meeting rooms, sports and leisure facilities, educational institutions, places of worship, conference and function suites, exhibition centers, banks, and restaurants


Acoustic partition walls features

1. Soundproof acoustic partition movable walls interlocking male / female trapezoidal vertical aluminium profiles, for soundproof connection between elements.


2. Acoustic partition wall to ensure additional friction connection, shall be integrated with magnetic strip.


3. Acoustic partition movable wall is easy element adjustment after installation.

4. Acoustic partition walls track system shall be Extruded aluminium, maintenance free with heavy-duty ball bearing steel rollers.


5. Acoustic partition walls customized support and welcome.


Roller Option & Feature


1. Dupont POM roller

2. 304 stainless steel heavy duty roller with safety device & CNC machining

3. Unique and patented wheel surface and shape make the whole movable partition easy to use

Panel Option & Feature


1. Thickness: 68mm & 89mm & 105mm

2. Wide variety of acoustical and decorative finishes available

3. 6061-T6 profile and inside Q235 steel frame for superior durability

4 Top & bottom jack lifting mechanism seal are with power of 800N. Magnetic seal in concave & convex profile has magnetic attraction of 40N/m.

SPECIFICATION:

GEMMAN PARTITION TECHNOLOGY GLOBAL PROFESSONAL SPACE SOLUTIONS
　 Dimensions in mm* Design
Series Element thickness Element width* (min./max.) Clear height* (min./max.) Framed construction Panel fixing Element interconnection/design of
the vertical profiles
AE65 68 600/1,250 2,000/4,500 Aluminium-steel Freely oscillating Aluminium profile
with magnetic strip
and sealing lips
AE85 89 600/1,250 2,000/5,500 Aluminium-steel Freely oscillating Aluminium profile
with magnetic strip
and sealing lips
AE100 105 600/1,250 2,000/18,000 Aluminium-steel Freely oscillating Aluminium profile
with magnetic strip
and sealing lips
Technology:
Weighted sound reduction value determined per GB/T19889.3-2005 in Rw (dB):52/56
Positive and frictional locking of the vertical element connections: Convex-concave profile form, force of attraction of the magnetic strip 40 N/m
* Larger widths possible on application. Provisional details regarding the element heights/element
widths indicated can only be confirmed following consultation with the Design Department.
** Depending on the sound insulation/weight
