Electric Greenhouse Roll Up Motor For Plastic Film Greenhouse

Product Description

Film greenhouse is a simple and practical protective cultivation facility, widely be used all over the world because of its easy construction, easy use and low investment for vegetable and flower productions.

Electric Roll Up Motor is used for rolling up the plastic film for ventilation, it could be used for 100m.

The body is made of high quality aluminum alloy,beautiful appearance,the surface is sprayed with plastic, has a good effect of anti-oxidation and anti-corrosion.Use gear steel,high hardness,long life cycle and no rust.Safe voltage,reduce the possibility of accident.Considering the safety of outdoor usage, the machine is water proof.the working conditions are safe and guaranteed.

Feature

1. The shell is made of cast aluminum material, which adopts precision die-casting molding process;

2. With internal self-locking device, can be turned on and off at any position;

3. stainless steel, coating with galvanized inside, and spraying plastics outside, double rust protection;

4. Reduction ratio and torque is designed reasonable, which is more efficient and more convenient;

5. Double limit switch protection;

6. Accurate limit switch and reliable self locking property;

7. Water drain added to protect the safety of circuit diagram;

8. Strengthens processing to output shaft;

9. Five years quality guarantee.

Advangtage

Installation precautions of electric film rolling device:

1. Drive the steel pipe at the end of the greenhouse where the film roll is installed to protrude by about 150mm, and it must not be bent or twisted.

2. Use M8 hex screws to connect the drive shaft joint with the drive steel pipe.

3. The overlap length between the telescopic tube (outer) and telescopic tube (inner) must not be less than 100mm of the roll film width.

4. After the telescopic tube (inner) and the fixed tube are hinged, they should be able to rotate around the fixed steel tube.

5. The side-opening coil climbing steel pipe and driving steel pipe should be at right angles.
