Specifications
Model Number :
STGG12-4
Place of Origin :
Shandong, China
Packaging Details :
Steel frame will load into container directly.
Small accessories are packed by cartoon or bags.
Glass sheet is packed by wooden case.
Supply Ability :
50000 Square Meter/Square Meters per Month
MOQ :
200 square meters
Price :
$25.00 - $49.00/square meters
Manufacturer :
Shine-tech
Instruction for use :
Installation Drawing
Size :
Large
Type :
Multi-Span Agricultural Greenhouses, Venlo
Cover Material :
Glass
Product name :
Glass Greenhouse
Application :
Vegetable Fruits Flowers
Span Width :
8m/9.6m/12m
Bay width :
4m
Height :
4.0-8.0M
Frame Material :
Hot Galvanized Steel Frame Structure
Covering :
Tempered glass
Advantage :
Super Strong Resistance
Optional system :
Cooling System.irrigation System.ventilation.heating systemetc
Port :
Qingdao Port
Description
Product Description
8m 9.6m 12m Span Width Multispan Greenhouse With Hydroponic System And Glass Structure
Large Intelligent Agriculture Glass Greenhouse with Hydroponic System
Commercial Venlo Glass Greenhouse has the characteristics of high light transmittance, beautiful appearance, simple and stable structure, and strong anti-corrosion.
It is suitable for plants with high requirements for sunlight. Each span of the glass multi-span greenhouse has 3 roofs, and each span has two slopes. The skeleton material of the greenhouse is generally made of galvanized steel material, which is connected by anti-rust bolts.greenhouses can be used in all areas of agriculture such as breeding, kinds of economic plants growing,commercial
ecological sightseeing park and scientific research ect.
1.Agricultural Glass Greenhouse provides ideal environment for plants growth. It can resist heavy and strong snow/wind, and very easy to clean and maintain.
2.The light transmittance is more than 90%.
3. Glass Greenhouse is Venlo shape with modern and novel apperance, stable structure, The life time of the greenhouse structure is more than 20years.
4. It can be equipped with inside and outside shading system, top and side window ventilation system, wet curtain and fan cooling system, heating system, automatic system and so on.
5.Other equipments can be applied according to the user's planting needs.
Specification
Large Intelligent Agriculture Glass Greenhouse with Hydroponic System
Product Name
Venlo Glass Greenhouse
Span width
8m/9.6m/12m(customization)
Bay width
4m (customization)
Height of Greenhouse
4-8m (customization)
Roof Covering
5mm tempered glass or PC sheet
Side covering
5+6+5mm double layer glass
Wind load
45~55km/m2
Snow load
0.40~0.5KN/m2
Max. rainfall
140mm/h
Hanging load
25~30kg/m2
Optional system
Side ventilation, roof ventilation, Outside shading system, Inside shading system, cooling system, heating system, drip irrigation system, fogging system, aotomatic control system, hydroponic system and so on.
Details Images
8m 9.6m 12m Span Width Multispan Greenhouse With Hydroponic System And Glass Structure

Frame

The Frame Materials of greenhouse are hot dip galvanized steel and accessories.The structure is strong and durable.
The warranty period of frame is 15~25 years
8m 9.6m 12m Span Width Multispan Greenhouse With Hydroponic System And Glass Structure

Covering

Thickness: 120/150/200 microns. It has function of anti-UV, anti-aging and anti-drip.
Light transmission:>89%
Diffusion≤20%
UV transmission 300%-390%
Warranty: 4-5 years
8m 9.6m 12m Span Width Multispan Greenhouse With Hydroponic System And Glass Structure
Ventilation System
The greenhouse has both side ventilation and top ventilation system.
Good ventilation can constantly supplement the carbon dioxide needed by plants, promote the growth of plants, and also regulate the temperature to provide a good living environment for plants
8m 9.6m 12m Span Width Multispan Greenhouse With Hydroponic System And Glass Structure

Outside Shading System

Shading net: black round wire shade net with 75% shading rate.
Function: Electric control, adjust the light intensity to
improve the ecological environment in the greenhouse and lower the temperature.
8m 9.6m 12m Span Width Multispan Greenhouse With Hydroponic System And Glass Structure

Inside Shading System

Shading net: white aluminum foil shade net with 45% shading rate.
Function: Electric control, avoid direct sunlight to crops in summer, reduce the loss of indoor moisture; slow down heat loss in winter.
8m 9.6m 12m Span Width Multispan Greenhouse With Hydroponic System And Glass Structure

Cooling System

The cooling system including exhaust fan, cooling pad, and water pimp system.
The exhaust fans eject the air from the greenhouse , negative pressure formed in the greenhouse. The air enters the greenhouse through the cooling pads, resulting in the effects of temperature down.
8m 9.6m 12m Span Width Multispan Greenhouse With Hydroponic System And Glass Structure

Heating System

The most popular system is electric heating fan, and water boiler with heating blower.
We recommend electric heating fan for small greenhouse. water boiler and heating blower for large commercial greenhouse.
Wide Application
8m 9.6m 12m Span Width Multispan Greenhouse With Hydroponic System And Glass Structure
Wide application
Venlo Glass Greenhouse is Widely for fruit(strawberry, cherry, grape, watermelon, and so on), vegetable(tomato, cucumber, potato, eggplant, pepper, bean, celery, onion and so on), flowers, poultry farming, mushroom cultivation and so on.
Project Case
8m 9.6m 12m Span Width Multispan Greenhouse With Hydroponic System And Glass Structure
8m 9.6m 12m Span Width Multispan Greenhouse With Hydroponic System And Glass Structure
8m 9.6m 12m Span Width Multispan Greenhouse With Hydroponic System And Glass Structure
8m 9.6m 12m Span Width Multispan Greenhouse With Hydroponic System And Glass Structure
Company Profile
8m 9.6m 12m Span Width Multispan Greenhouse With Hydroponic System And Glass Structure
8m 9.6m 12m Span Width Multispan Greenhouse With Hydroponic System And Glass Structure
8m 9.6m 12m Span Width Multispan Greenhouse With Hydroponic System And Glass Structure
Packing & Delivery
8m 9.6m 12m Span Width Multispan Greenhouse With Hydroponic System And Glass Structure
8m 9.6m 12m Span Width Multispan Greenhouse With Hydroponic System And Glass Structure
8m 9.6m 12m Span Width Multispan Greenhouse With Hydroponic System And Glass Structure
Why Choose Us
Q1:Can you design for us?
A: As we are manufacturer,we have our own research and development group,we can design the greenhouse according to your request or
drawing.
Q2:How to ensure the quality of the products ?
A: Before delivery, our inspection department will examine and test the products thoroughly and carefully. Necessary test and certification can be obtained as your request.
You can let your friend or Third-party testing company to come for check product.
Q3:How can you ensure the legality and security during transaction?
A: We are a member of Alibaba Trade Assurance which is safeguarding buyer's payment to supplier to ensure supplier fulfill their obligations regarding delivery and product quality.
Q4:Do you provide installations and training service?
A: It is easy to install. We send install video or drawing to you. Or welcome visiting our factory. We will guide you how to install it in our factory
Q5:How long is delivery time?
A: 7-30days after getting deposit, it according to your order quantity.
