6.3t 140kw Truck Mounted Telescopic Crane SQ6.3ZK3Q
6.3t 140kw Truck Mounted Telescopic Crane SQ6.3ZK3Q
6.3t 140kw Truck Mounted Telescopic Crane SQ6.3ZK3Q
6.3t 140kw Truck Mounted Telescopic Crane SQ6.3ZK3Q
6.3t 140kw Truck Mounted Telescopic Crane SQ6.3ZK3Q
6.3t 140kw Truck Mounted Telescopic Crane SQ6.3ZK3Q
Specifications
Brand Name :
XCMG
Model Number :
SQ6.3ZK3Q
Certification :
ISO
Place of Origin :
China
MOQ :
1 unit
Price :
USD39500
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
200 UNIT PER Month
Delivery Time :
30days
outside dimension (L×W×H)mm :
9000×2500×3460
Max. power/rotated speed :
140(KW) /2500(rpm)
Max Lifting Moment :
13.23t.m
Overall Dimension :
9000×2470×3560
Max Lifting Capacity :
6300kg
Oil Tank Capacity :
90L
Description

XCMG SQ6.3ZK3Q Truck Mounted Crane General Feature

The unique design of three-floating bridge structure reduces the stress which equipment added to truck crane.

All rotation technology, smooth and high-speed rotary, efficient and convenient operation.

The key components of the hydraulic system are manufactured by introduce new technology which makes the operation’s safety and reliability

XCMG SQ6.3ZK3Q Truck Mounted Crane Technique Specifications

Model SQ6.3ZK3Q Unit
Max Lifting Moment 13.23 t.m
Max Lifting Capacity 6300 kg
Recommend Power Needed At Recommend Oil Flow 18 kw
Max Oil Flow of Hydraulic System 25 L/min
Rated Pressure Of Hydraulic System 28 MPa
Oil Tank Capacity 90 L
Rotation Angle (360°)All Rotation °
Crane Weight 2226 kg
Installation Space 1050 mm
Overall Dimensions Specification
Overall Dimension 9000×2470×3560, mm
Container Dimension 5800/5300×2294×550 mm
Chassis Specification:
Model of Chassis EQ5161GFJ7
Manufacture Dongfeng Automobile
Emission Standard Europe 3
Fuel Type Diesel
Engine Type Cummins 190HP
Tyre Wheel Base Specification:
Number of Chassis Axle 2
Number of Tyre 6
Chassis Wheel Base 4550,5000 mm
Chassis Wheel Track 1940/1860 mm

SQ6.3ZK3Q Lifting capability diagram

Working radius (m) 2.1 4.54 6.3 8.11 9.92
Lifting capacity (kg) 6300 2700 1700 1200 850
