300mm DC AC Motor Horizontal Vertical Drive Wheel Assembly Power Agv Steering Drive Wheel
300mm DC AC Motor Horizontal Vertical Drive Wheel Assembly Power Agv Steering Drive Wheel
300mm DC AC Motor Horizontal Vertical Drive Wheel Assembly Power Agv Steering Drive Wheel
300mm DC AC Motor Horizontal Vertical Drive Wheel Assembly Power Agv Steering Drive Wheel
300mm DC AC Motor Horizontal Vertical Drive Wheel Assembly Power Agv Steering Drive Wheel
300mm DC AC Motor Horizontal Vertical Drive Wheel Assembly Power Agv Steering Drive Wheel
300mm DC AC Motor Horizontal Vertical Drive Wheel Assembly Power Agv Steering Drive Wheel
300mm DC AC Motor Horizontal Vertical Drive Wheel Assembly Power Agv Steering Drive Wheel
300mm DC AC Motor Horizontal Vertical Drive Wheel Assembly Power Agv Steering Drive Wheel
300mm DC AC Motor Horizontal Vertical Drive Wheel Assembly Power Agv Steering Drive Wheel
300mm DC AC Motor Horizontal Vertical Drive Wheel Assembly Power Agv Steering Drive Wheel
300mm DC AC Motor Horizontal Vertical Drive Wheel Assembly Power Agv Steering Drive Wheel
Specifications
Brand Name :
ZHLUN
Model Number :
ZL-B435
Place of Origin :
China
MOQ :
1
Price :
$2500-5000
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
30 per month
Delivery Time :
30 days
Packaging Details :
Wooden box
Warranty :
1 Year
Machinery Test Report :
Provided
Services :
support for custom
Description

DC AC Motor Horizontal Vertical Drive Wheel Assembly Power Agv Steering Drive Wheel

Product Paramenters
Technical parameters of steering wheel for light load damping wheel
Traction motor
Speed Ratio
7-120I
Motor Type
Servo/Brushless
Wheel Diameter
300mm
Rated Power
1000-4000w
Fastest Speed
20-200m/min
Rated Voltage
DC24/48,AC220
Shock Stroke
±10mm
Rated Speed
3000/Customizable RPM
Damping Pressure
1500KG
Rated torque
3.18-16N.m
Temperature
-10to+55
Steering motor
Motor Type
Servo/Brushless
Rated Power
750-1000w
Rated Voltage
DC24/48,AC220
Rated Speed
3000RPM/Customizable
Rated Torque
2.39-3.18N.m
Reducer Speed Ratio
35-120I
Mechanical Limit Range
±120°
Angle Limit
proximity switch
NPN/PNP
Weight
About 110KG

WHY CHOOSE US

Rich industry application experience and reasonable overall layout of AGV plan.

Have strong design and integration capabilities to help projects be easier to implement.

Customized services: we can provide customized development according to project applications, and provide fast and corresponding overall solutions and technical support services before, during and after sales, fully considering customer needs.

Our Services

1. Installation Services: In the period of installation and debugging, we shall offer training about effective operation and maintenance.

2. Technical Services: We can assist our clients to solve all kind of technical problems with our capable technical team, and we own adequate experience for production line transformation project.

3. Warranty Services: We offer free after sale service except the engineers' traveling expense for any quality problem occurs during our 12 months warranty period.

Product Application
Product packaging and Transportation
Company Profile
Guangzhou Wisdom Wheel Science Technology LTD.
Guangzhou Wisdom Wheel Science Technology Ltd. is a high-tech enterprise integrating service research ,design, production,sales,service and system integration.with a number of independent intellectual property rights. According to application requirements, various types of AGV steering wheel drive assemblies with independent intellectual property rights have been developed, including heavy-duty, shock-absorbing. low and Mini ,differential steering drive wheels,etc.,which are suitable for various application fields; Based on the application, the company independently designed and developed heavy-duty AGV,heavy-duty unmanned flatbed truck, omnidirectional forklift, special assembly AGV, service robot, AGV intelligent parking and other products,providing customers with customized AGV customization and wholeheartedly providing technology Support and expand the application field of AGV.
China International Logistiscs Robot Exhibitions.
Asia International AGV Exhibition
Asia International Logistics Exhibition
Certifications
FAQ
Q: Can your company adjust the product according to the customer's situation?
A: Yes. We will send you the steering wheel order configuration table. Customers can fill in the relevant parameters according to their own situation. We can adjust the steering wheel parts according to customer needs
There are speed ratio, speed, walking motor, motor voltage, brake, etc., there are more detailed instructions in the product
parameter table, we welcome customization.

Q: How can I trust the quality of your products ?
A: The AGV steering wheel assembly series products are independently researched and developed by our company. We have variety of international quality certificates, We have our own unique planetary reducer developed and designed, we do a series of product tests before shipping.

Q: How can we make sure about the machine quality after placing the order?
A: Before delivery, we will running half hour of the machine to checking the stability and sending you the testing video until you satisfy. We will setting all the parameters well.

If you want to know more product details outside the picture, please contact us.
