2000mm 6 Axis Laser Welding Robot Payload 12kg 4.5kVA Power Capacity
2000mm 6 Axis Laser Welding Robot Payload 12kg 4.5kVA Power Capacity
2000mm 6 Axis Laser Welding Robot Payload 12kg 4.5kVA Power Capacity
2000mm 6 Axis Laser Welding Robot Payload 12kg 4.5kVA Power Capacity
2000mm 6 Axis Laser Welding Robot Payload 12kg 4.5kVA Power Capacity
2000mm 6 Axis Laser Welding Robot Payload 12kg 4.5kVA Power Capacity
2000mm 6 Axis Laser Welding Robot Payload 12kg 4.5kVA Power Capacity
2000mm 6 Axis Laser Welding Robot Payload 12kg 4.5kVA Power Capacity
2000mm 6 Axis Laser Welding Robot Payload 12kg 4.5kVA Power Capacity
2000mm 6 Axis Laser Welding Robot Payload 12kg 4.5kVA Power Capacity
Specifications
Brand Name :
AIDA
Model Number :
ZGRB-06-2000-010-W-MK
Certification :
CE
Place of Origin :
China
MOQ :
1 unit
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
100 Units/Month
Delivery Time :
20 work days as per order volume
Packaging Details :
Wooden Case Package
Model NO. :
ZGRB-06-2000-010-W-MK
Radius of Motion :
2000mm
Number of Axis :
6 Axis
Type :
Laser Welding Robot
Payload :
12kg
Power Capacity :
4.5kVA
Function :
Welding workpieces
Transport Package :
Wooden Case Package
Trademark :
AIDA
Origin :
China
HS Code :
85158010
After-sales Service :
Video Technical Support, Online Support
Warranty :
1 Year
Customization :
Available | Customized Request
Description

6-Axis Arc Welding Arm Payload 10kg Range 1400mm Welding Robot
The 6-axis arc welding robot is a type of industrial robot specifically designed for arc welding applications. Arc welding is a welding process that uses an electric arc to create a fusion of metals. These robots are equipped with a 6-axis articulated arm that provides flexibility and precision in maneuvering the welding torch to perform welding tasks.

The six axes of motion in a 6-axis arc welding robot allow for a wide range of movement and positioning capabilities, enabling the robot to reach different points within its work envelope and adjust its orientation as needed. This flexibility is crucial in arc welding applications where welding may need to be performed on complex geometries or in hard-to-reach areas.

Robotic welding is a highly advanced version of automated welding, in which machines conduct the welding, but welders still control and supervise the process. The use of robotic technology allows for precise and quick results, less waste, and greater safety.

2000mm 6 Axis Laser Welding Robot Payload 12kg 4.5kVA Power Capacity

Product Description
2000mm 6 Axis Laser Welding Robot Payload 12kg 4.5kVA Power Capacity

Product Features


2000mm 6 Axis Laser Welding Robot Payload 12kg 4.5kVA Power Capacity

2000mm 6 Axis Laser Welding Robot Payload 12kg 4.5kVA Power Capacity

Product Specification
Model ZGRB-06-2000-012-W-MK
Performance Installation method Ground, hoisting, wall
Freedom of movement 6-axis
Payload 12 kg
Maximum reach 2000 mm
Repeat positioning accuracy 0.05 mm
Self weight 313kg
Temperature 0-45°C
Humidity 20%-80%
Power capacity 4.5 KVA
Max. Working Range Swivel J1 ± 160º
J2 -55º ~ +170º
J3 -75º ~ +145º
J4 ± 190º
J5 ± 130º
J6 ± 220º
Max. Speed J1 179º/s
J2 179º/s
J3 162º/s
J4 315º/s
J5 276º/s
J6 1356º/s
Allowable Moment Bending J4 103.5Nm
J5 51.84Nm
J6 32.64Nm

Product Specification

It is widely used in Automotive Industry, Aerospace Industry, Railway Industry, Metal Fabrication,Shipbuilding,
Construction,Oil and Gas Industry,Heavy Machinery Manufacturing, etc.

2000mm 6 Axis Laser Welding Robot Payload 12kg 4.5kVA Power Capacity

2000mm 6 Axis Laser Welding Robot Payload 12kg 4.5kVA Power Capacity

Blue tooth printer (optional)

2000mm 6 Axis Laser Welding Robot Payload 12kg 4.5kVA Power Capacity

2000mm 6 Axis Laser Welding Robot Payload 12kg 4.5kVA Power Capacity
AIDA is a high-tech enterprise integrating R&D, production and service, as a solution provider of professional material
handling equipment and flexible intralogistics system for all scenarios.

Offer products including series of electric pallet truck, electric stacker and a series of hand pallet truck, semi electric
stacker and reach stacker and other material handling equipment and device. Widely used in logistics and warehousing, retail
and wholesale, medicine, food, chemical, electronics, machinery, automobile and other industries.

AIDA have established a strict quality assurance system and have passed ISO9001,ISO14001,SGS,and CE certification.
It is a national high-tech enterprise with more than 40 national patents, which has been rated as "Small giant enterprise in
Hunan Province", "The first batch of pilot enterprises for the integration of advanced manufacturing and modern service
industries in Hunan Province","Demonstration enterprise of intelligent manufacturing in Changsha City"," Hunan Enterprise
Technology Center".

"Energy saving, environmental protection, high efficiency and intelligence" is the design concept of AIDA products, and it is
committed to becoming a smart digital expert for intralogistics.
2000mm 6 Axis Laser Welding Robot Payload 12kg 4.5kVA Power Capacity

2000mm 6 Axis Laser Welding Robot Payload 12kg 4.5kVA Power Capacity
2000mm 6 Axis Laser Welding Robot Payload 12kg 4.5kVA Power Capacity
